Farm Supplies Machinery & Equipment

2.4m Shear Grab (18 tines in base). Made in New Zealand.
Through the combination of the clean cut obtained from the unique serrated knife edge and rounded front design, the implement leaves a sealed pit face, eliminating secondary fermentation. The side walls and closely spaced cranked tines minimise silage/maize loss during transport.
High tensile steel
Robust frame
Powerful rams
Conserving feed with a Rata Silage Shear Grab.
Model (Code) SHG240
Width (m) 2.4m
Weight (kg) 830kg
Capacity (m³) 1.10
Number of Tines 18
Min Tractor HP 160
All Rata Silage Shear Grabs feature a serrated knife cutting edge. Serrated teeth cut the silage faster, stay sharper for longer, serrated teeth along with rounded grab face also help keep the stack sealed which prevents secondary fermentation.
Hydraulic rams on Grabs are large and powerful to cut through the most dense silage stacks. Models under 2.1m wide have 2 Rams. Models 2.1m wide and above come with 3 hydraulic rams.
Rata Grabs are designed and built heavy duty to cope with a long, hard working life. Heavy steel plate, bushes and bosses ensure maximum strength and support. Particularly around pivot points and high stress load areas.
Hydraulic hoses are routed to keep away from the working area of the Shear Grab. This ensures they are kept out of harms way whilst remaining easy to access.
An optional bucket insert is available upon request. This effectively turns the shear grab into a bucket shear grab for use on fine materials and feeds.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

RATA 2.4M SHEAR GRAB (ALSO SUITABLE FOR TELEHANDLERS)

400MM 4 Series auger up to 5T for Ramdrill PHD -Hydraulic Driver.
Price inclusions: Auger, teeth, pilot, pin and clip.
A4 earth
Drill holes in light earth conditions and clay. Numerous teeth options are available for most ground conditions. Available in Earth, Tungsten, or MFT for general drilling. Easy PADLOC knock in and out teeth require no special tools.
Our 4 Series augers boast effective cutting heads for efficient drilling, and suit mini loaders, skid steer loaders, and excavators up to 5T. Depending on ground conditions, you can choose a bladed or tapered cutting head, or rotating rock picks. For deeper holes, a full range of auger extensions are available for your specific requirement.
Features:
- True cut design ensures a 300mm Auger drills a 300mm hole.
- Drive adaptors & extensions to maximise drilling depth.
- Shallow pitch flights for optimum removal of spoil
- Robust Auger body construction for long life
- Heavy duty tube with highest grade steel
- Variety of hub options.
Specifications:
- Drilling Conditions: General & Clay
- Standard Hub: 65mm Round
- Hub Options: 50.8 mm Round / 57 mm
Square / 75 mm Square
- Overall Length: 1200 mm
- Flights (Lead): 8 mm
- Flights (Carry): 8 mm
- Teeth: TS
- Pilot: PM-SQ
- Ideal Drives: ML / PDD - PD4
Optimum Drilling Speeds - RPM:
- Earth: 55-65
- Clay: 45-55
- Shale (Fracturable Rock): 25-45
- Heavy Rock: N / A
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

DIGGA 400MM AUGER (LIGHT EARTH & CLAY) FOR RAMDRILL PHD - HYDRAULIC DRIVE

The award winning range of Cyclone Mowers has been designed to do the work of a flail mower but requires a fraction of the power and fuel that a flail mower would consume.
These machines are strong, rugged and robust; specifically designed for use in set-aside, forestry margin management and sensitive environmental scrubland control. This machine easily copes with the toughest of conditions including shrub, saplings, gorse and brush.
It is ideal for the clearance of arable stubble, maize and rapeseed crops.
Strenx 700 MC high-strength steel is used in the manufacture of these machines. This material is stronger than steel traditionally used in machinery manufacturing.
The undersole discs are produced from Hardox 450, a wear and abrasion resistant steel.
An optional side shift unit is available which allows the operator.
Features:
Can be front or rear mounted (to be specified when ordering)
Patented blender double chop blade system
25 percent less power and fuel consumption required than a similar sized flail machine Impact shock reducing swinging hardened spring steel blades
Low maintenance machine with less wearing parts than a flail mower
Heavy duty rear roller
Model:
MJ30-350 - 3.50m (11ft 5in) - 1,120kg - 90-140HP - 5 Rotors
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

MAJOR 3.5M MJ30 CYCLONE RANGE ROTARY SLASHER/MULCHER - SINGLE WING,90-140HP

Stick rake 6ft or 1.8m.
The Daken Stick Rake is a very handy tool for cleaning up sticks and leaves around your property or reducing fire hazards.
It easily mounts to a tractors 3 point linkage with a comb that can be angled and spring steel tines.
If it is collecting too much material every second tine can be removed to allow for smaller objects to clear.
Features:
- Fits Cat 1 tractors
- Spring steel Tines
- Easy to use
- Suits Cat 1 or 2
- Weight: 100kg
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

DAKEN STICK RAKE 6FT - 61020DC

Standard Bucket 3000 series - 1.2m

The standard or general purpose (GP) bucket is suitable for routine operations such as earth moving and scooping. The standard bucket is fitted with the following to ensure that the bucket stays durable under intense conditions:

Features:

- Stiffening rib
- Wear plates
- Reinforced ends
- Optional teeth upgrade to enhance loading or material handling applications.

Specifications:

- Width (m): 1.20m
- HP Range: 20-45
- Struck Capacity (m3): 0.17
- Rated Capacity (m3): 0.21
- Dimensions LxWxH (mm): 1260X630X550
- Weight (kg): 70

BURDER BUCKET STANDARD 3000 SERIES 1.20M - 20-45 HP RANGE

Murray 53020, Series 53 Tow Hitch Hayman Reece style - 3PL.
Strong robust design to assist with hooking up trailers to your tractor. Available in four different styles.
Manufactured from global materials.
Features:
- All steel construction
- Hayman Reese compatibility
- Four different styles available
- Preassembled ready for use
- Upgraded specifications and steel wall thicknesses
Specifications:
- Tow Hitch Hayman Reece style Cat I & II.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

MURRAY TOW HITCH HAYMAN REECE STYLE- 3 POINT LINKAGE

Top Grabs for Standard Bucket 9000 series - 2.10m.
Price is for grabs only does not include bucket.

Two Grab types available:
Profile Cut Grabs:

The top grab for bucket is an additional feature that makes picking objects off the ground easier.

Activating the hydraulic cylinder for the grab will result in a grabbing action.

Forges Tines Grabs:

The tines on the top grab can be easily removed if replacement tines are needed. With the added grab with tines, transporting loose silage is much easier.

Specifications:

- Width (m): 2.1m
- HP Range: 100+
- Struck Capacity (m3): 0.71
- Rated Capacity (m3): 0.85
- Dimensions LxWxH (mm): 2160X850X740
- Weight (kg): 310

BURDER TOP GRAB FOR BUCKET STANDARD 9000 SERIES 2.10M - 100+ HP RANGE

4 in 1 Bucket 3000 series - 1.20m

The 4 IN 1 bucket has many advantages over the standard bucket:

Features:

- Allows the operator to open the bucket to release material instead of dumping the material.
- When the bucket is opened, the exposed blades on the rear and front end of the bucket can be used for earthmoving activities.
- Allows the clamping of objects and is ideal for picking items like broken branches.

Specifications:

- Width (m): 1.20m
- HP Range: 20-45
- Struck Capacity (m3): 0.14
- Rated Capacity (m3): 0.18
- Dimensions LxWxH (mm): 1260X630X550
- Weight (kg): 135

BURDER 4 IN 1 BUCKET 3000 SERIES 1.20M - 20-45 HP RANGE

AHM Mulcher 160CM - Australian designed and manufactured to suit a wide variety of farming and local government requirements. Ranging in size from 155cm to 900cm cutting width.
The AHM series is a heavy-duty mulcher best suited to typical farming applications such as:
- Wheat, Maize, Sorghum, Rice and Cotton stubble. - Tobacco, Potato haulms, Sweet Potato, Pineapple tops, pasture topping.
- Prunings: Macadamia, Grapes, Banana plants & Avocados
- The Forestry model is suitable for scrub clearing, forest trails and under powerline regrowth control. These models are also fitted with a heavy duty Rotor and additional body panels
Features:
- 50HP
- Excavator Mount
- Double skin body construction
- Cast hammers pivoting on hardened bushes
- SPBX Section American V Belts
- Taperlock Rotor Bearings 55mm capacity
- 220mm diameter Rotor Tube
- Suitable for 12-20 ton excavators
- Requires minimum 100lt/min flow, minimum 200 bar pressure.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

AGRIFARM EXCAVATOR MULCHER AHM HYDRAULIC 160CM (100+LPM)

Loader Tine specifications shown in images.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SHW LOADER TINE - STRAIGHT, 980MM LENGTH (SQUARE)

LE Series Slashers. 1.8M, suits 45-75HP.
Features:
5mm galvanised deck
Cat I & II
Adjustable skids
Pivoting headstock with chain backstays
PTO driveshaft
Friction clutch
Front & rear chain guards
Standard to suit 45-75 HP tractors
Gearbox available in red or yellow.
Specifications:
Working width: 1.8m (6')
Weight: 420kg
HP: 45-75
Finish: Galvanised deck
Options:
Combination Friction & Overrun Clutch
Wheelkit (adjustable)
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

FIELDQUIP LE SERIES SLASHERS 1.8M - SUIT 45-75HP

4ft Stick Rake - Ideal for light grading, levelling, and general raking of sticks, leaves and stones.
Great for fire hazard reduction.
Includes 24 spring steel tines, rake rotates 360 degrees allowing for angular and reverse settings.
Recommended for tractors less than 90HP. Heat treated and 5/16 x 1 spring steel tines.
Other sizes include:
5ft Stick Rake
6ft stick rake
7ft stick rake
Please Note: 6ft featured in image.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SOUTHERN CROSS AG MACHINERY 4FT STICK RAKE, 24 TINES- 4LR - SUIT UP TO 90HP
