This range of mulcher is ideal for all mowing and mulching with small and compact tractors of 12 to 35 hp from cutting fine lawns to high grass or light vegetation. The MU-C mulchers display their overall versatility, their good cutting and mulching quality and their robust construction.
Features:
Manufactured from High Quality QSt/E Steel with centre mounted Cat. I Headstock for rear mounting.
Rear mounting: Gearbox with integrated over run clutch for 540 / 1000 r.p.m. (distance of the ground to P.T.O. shaft cc. 50 cm).
Front mounting: Low positioned gearbox with integrated over run clutch for 1000 r.p.m. (2000 r.p.m. possible as option) (distance of the ground to P.T.O. shaft cc. 25 cm).
Belt protection with tension measuring slot.
Shackle M Carbide flails to ensure long life, clean cut and maximum shredding using less power.
Spiral Rotor with specially formed flail lugs to protect against damage from obstacles; bearings protected against dirt, wear and tear.
Roller with rounded edges to preserve the soil and turf and to carry the flail with variable height adjustment.
High tempered spring steel one way protection flaps in front of the mower hood.
Skids
Optimised distance between the outer rotor circle and the roller guarantees perfect contour following and an even quality of cut.
Purposely designed hood in conjunction with high rotor and cutting speeds and removable shredding bar spreads the shredded material evenly behind the roller giving an excellent Mulching and Shredding Quality.
Patented removable shredding bar System: Shark Fin.
P.T.O. shaft and Guarding to ISO Standards.
Options:
2 point Linkage parts to original mower deck linkages for Front Mowers (Iseki SF 230 etc.) instead of Head Stock Cat.I (only for MU-C 100 and
MU-C 120 available).
Special Carbide wearing skids, removable (Rear mounting only).
Height adjustable rubber wheels, 360º swivel in front of the mulcher.
Hydraulic Weight Transfer MU-SOFA, for Front mounting recommended.
Mount for municipal quick-coupling triangle (installed on implement) for front mounting.
3-point trestle (Cat 1) Alpine for converting rear-mounted MU-C to front mounting for carrier vehicles, 540 rpm or 1000 rpm (MU-C 140-160)
Linkage parts for Shibaura CM 214
Modification to different RPM
Second screw-type short chopping bar system with "shark fin" design-a Muthing patent (only for front mounting)
Hood wear plate (factory mounted)
Models:
MU-C080 WW-800mm Overall width-970mm Max hp-35 Weight 140kg Flails 12
MU-C100 WW-1000mm Overall width-1170mm Max hp-35 Weight 160kg Flails 16
MU-C120 WW-1200mm Overall width-1370mm Max hp-35 Weight 180kg Flails 20
MU-C140 WW-1400mm Overall width-1570mm Max hp-35 Weight 200kg Flails 24
MU-C160 WW-1600mm Overall width-1770mm Max hp-35 Weight 220kg Flails 28
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

MUTHING 160CM MULCHER SUITS UP TO 35HP MU-C160

Loader Tine specifications shown in images.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SHW LOADER TINE - CRANKED, 820MM LENGTH, M24 X 1.5 THREAD (SQUARE)

350mm -3 Series Auger up to 5T for 3 point linkage. Heavy conditions - (MFT) Multi Facet Tungsten-Hard ground.
Price inclusions: Auger drive with 50.8mm round hub, teeth, pilot, pin and clip.
The A3 is constructed for efficient post hole digging.
Drill holes in light earth conditions and clay. Numerous teeth options are available for most ground conditions.
Constructed for fast efficient post hole digging, even in extreme conditions. Available in earth or multi-facet tungsten (MFT) braised onto the face of the teeth, providing longer wear life and greater cutting performance. Not suited to harder fracturable rock.
Features:
- True cut design ensures a 300mm Auger drills a 300mm hole.
- Drive adaptors & extensions to maximise drilling depth.
- Shallow pitch flights for optimum removal of spoil
- Robust Auger body construction for long life
- Heavy duty tube with highest grade steel
Specifications:
- Drilling Conditions: General & Clay
- Standard Hub: 50.8mm Round
- Overall Length: 1200 mm
- Flights (Lead): 8 mm
- Flights (Carry): 8 mm
- Teeth: TS
- Pilot: PM-SQ
- Ideal Drives: ML / PDD - PD4
Optimum Drilling Speeds - RPM:
- Earth: 55-65
- Clay: 45-55
- Shale (Fracturable Rock): 25-45
- Heavy Rock: N / A
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

DIGGA 350MM AUGER (HEAVY-HARD GROUND) FOR 3 POINT LINKAGE

350MM 4 Series Auger (Heavy conditions-(MFT) Multi Facet Tungsten-Hard ground) up to 5T for Ramdrill PHD -Hydraulic Driver.
Price inclusions: Auger, teeth, pilot, pin and clip.
A4 earth
Drill holes in light earth conditions and clay. Numerous teeth options are available for most ground conditions. Available in Earth, Tungsten, or MFT for general drilling. Easy PADLOC knock in and out teeth require no special tools.
Our 4 Series augers boast effective cutting heads for efficient drilling, and suit mini loaders, skid steer loaders, and excavators up to 5T. Depending on ground conditions, you can choose a bladed or tapered cutting head, or rotating rock picks. For deeper holes, a full range of auger extensions are available for your specific requirement.
Features:
- True cut design ensures a 300mm Auger drills a 300mm hole.
- Drive adaptors & extensions to maximise drilling depth.
- Shallow pitch flights for optimum removal of spoil
- Robust Auger body construction for long life
- Heavy duty tube with highest grade steel
- Variety of hub options.
Specifications:
- Drilling Conditions: General & Clay
- Standard Hub: 65mm Round
- Hub Options: 50.8 mm Round / 57 mm
Square / 75 mm Square
- Overall Length: 1200 mm
- Flights (Lead): 8 mm
- Flights (Carry): 8 mm
- Teeth: TS
- Pilot: PM-SQ
- Ideal Drives: ML / PDD - PD4
Optimum Drilling Speeds - RPM:
- Earth: 55-65
- Clay: 45-55
- Shale (Fracturable Rock): 25-45
- Heavy Rock: N / A
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

DIGGA 350MM AUGER (HEAVY-HARD GROUND) FOR RAMDRILL PHD- HYDRAULIC DRIVE

The heavy MU-H Vario series is the robust universal mulcher for green area maintenance for tractors and special system vehicles up to 90 hp.
This work horse for daily use in the widest possible range of mowing and mulching work has side shift, front and rear mounting, heavy fully proven universal M-Hammer flails and the patented "Shark fin" shredding bar system as standard.
Consequently this mulcher is not only capable of working perfectly on lawns, meadows and overgrown areas but also on fallow surfaces with woody growth and light scrub. The biomass is heavily shredded and spread evenly over the surface behind the roller.
Features:
Manufactured from High Quality QSt/E Steel with multi position Headstock Cat. I + II for Front or Rear mounting with mechanical side shift; MUL 180 280: 56 cm (as shown)
Gearbox with integrated over run clutch and through drive for 540 / 1000 r.p.m.
Belt protection with tension measuring slot
High tempered M Hammer flails to ensure clean cut and maximum shredding using less power
Spiral Rotor with specially formed flail lugs to protect against damage from obstacles and internal bearings protecting against dirt, wear and tear
Roller with internal bearings System Starinth and well rounded edges to preserve the soil and turf and to carry the flail, adjustable to different heights; Wearing skids, High tempered spring steel one way protection flaps in front
Optimised distance between the outer rotor circle and the roller guarantees perfect contour following and an even quality of cut
Purposely designed hood in conjunction with high rotor and cutting speeds and removable shredding bar spreads the shredded material evenly behind the roller giving an excellent Mulching and Patented removable shredding bar System: Shark Fin.
P.T.O. shaft and Guarding to ISO Standards
Carbide wearing skids (removable)
Adjustable Vario cutting bar for adjusting the shredding rate
Options:
Hydraulic side shift (MU-H 220 Vario: 56cm)
Shock absorbing linkage springs (for front mount recommended)
MU-SOFA weight transfer system, recommended for font-mounted machines
Double free wheel gear box for PTO rotational direction
Modification of r.p.m/rotation direction
Rotor with triple Y-blades - additional charge
Rotor with triple M shackle flails - additional charge
Dust protection for front mounting MU-H 180 -220 Vario
Second patented removable shredding bar system: "Shark Fin"
Hood wearing plate (factory mounted)
Model:
MU-H 120 WW 1200mm Overall width 1370mm Max hp 90 Weight 380 kg Flails 10
MU-H 140 WW 1400mm Overall width 1570mm Max hp 90 Weight 400 kg Flails 12
MU-H 150 WW 1500mm Overall width 1670mm Max hp 90 Weight 415 kg Flails 12
MU-H 160 WW 1770mm Overall width 1770mm Max hp 90 Weight 430 kg Flails 14
MU-H 180 WW 1970mm Overall width 1970mm Max hp 90 Weight 530 kg Flails 16
MU-H 200 WW 2200mm Overall width 2370mm Max hp 90 Weight 505 kg Flails 18
MU-H 220 WW 2200mm Overall width 2370mm Max hp 90 Weight 575 kg Flails 18
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

MUTHING MU-H VARIO 180 MULCHER (35-90HP) - FRONT OR REAR

SPAREX LOADER TINE - STRAIGHT, 1,100MM LENGTH (FLUTED)

100mm - 3 Series Auger up to 5T for 3 point linkage. Standard conditions - Tungsten Carbide.
Price inclusions: Auger drive with 50.8mm round hub, teeth, pilot, pin and clip.
The A3 is constructed for efficient post hole digging.
Drill holes in light earth conditions and clay. Numerous teeth options are available for most ground conditions.
Constructed for fast efficient post hole digging, even in extreme conditions. Available in earth or multi-facet tungsten (MFT) braised onto the face of the teeth, providing longer wear life and greater cutting performance. Not suited to harder fracturable rock.
Features:
- True cut design ensures a 300mm Auger drills a 300mm hole.
- Drive adaptors & extensions to maximise drilling depth.
- Shallow pitch flights for optimum removal of spoil
- Robust Auger body construction for long life
- Heavy duty tube with highest grade steel
- Variety of hub options.
Specifications:
- Drilling Conditions: General
- Standard Hub: 50.8mm Round
- Overall Length: 1200 mm
- Flights (Lead): 8 mm
- Flights (Carry): 8 mm
- Teeth: TS
- Pilot: PM-SQ
- Ideal Drives: ML / PDD - PD4
Optimum Drilling Speeds - RPM:
- Earth: 55-65
- Clay: 45-55
- Shale (Fracturable Rock): 25-45
- Heavy Rock: N / A
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

DIGGA 100MM AUGER (STANDARD- TUNGSTEN) FOR 3 POINT LINKAGE

Bigfoot XD Trencher 900mm dig - 150mm earth chain with crumber bar. - 2 inch chain - Front mounted.
Price inclusions: 450 to 900mm dig trencher, chain, standard frame, 2.2m hoses & couplers.
Suits 4.5 tonne to 8 tonne machines.
Tractor requires Hydrostatic / Vario Transmission.
Ideal for excavators up to 8 tonne, skid steer loaders, backhoes, and tractors, the Bigfoot XD Trencher can be used for pipe laying for irrigation, underground power & communications, road repairs, general construction.
An evolution from our Bigfoot Trencher with a greater trench digging depth of up to 1500mm.
Fitted with a patent pending Head Start Crumber system, quality Digga Planetary Drive & Eaton Hydraulic Motor, adjustable skid foot and single spoil removal auger for consistent digging depth.
Our unique design promotes efficient spoil removal and finely crumbled spoil for effective compaction back into the trench.
This provides minimal ground disturbance to surrounding conditions and results in a cleaner finish.
Earth Chain:
Earth Tooth on every Second Station.
An EARTH tooth configuration is best suited for soft clean ground with no floaters or tree roots like earth and clay.
Chain sizes available:
- 150mm
- 200mm
- 250mm
- 300mm
Features:
- Head Start Crumber System (patent pending) with steel scraper shoe begin trenching with the crumber down and save time by not having to get out of your machine
- Adjustable skid foot features 4 preset digging depths. Highly visible and can be seen from the cab. No spotter required
- Up to 1500mm dig depth & 300mm digging width with a 50.8mm chain 3 different chain options available: Earth, Combo, and Diggatac
- Standard Flow XD range features a compact, yet powerful Digga planetary drive High flow XD models come with a 6K Eaton hydraulic motor
- Frame can be side shifted for digging close to permanent structures
Ideal Use:
- Can be used for pipe laying for irrigation, underground power / communications, road repairs and general construction.
Specifications:
- Cutting Width: 150 / 200 /250 / 300 mm
- Foot Depth Presets: 450 / 600 / 750 / 900 mm
- Recommended Flow (lpm) 60-115
- Motor Size: 2K Bell EATON
- Max Pressure - Do not exceed 240 bar @ 60 lpm
- Max Flow - Do not exceed 95 lpm @ 200 bar
- Max Continuous Power 25 Kw (34 hp)
- Length: 2225 mm
- Horizontal Height: 777 mm
- Width: 1212 mm
- Weight - With a 150mm Combo Chain 388 kg
See photos for more information and specifications.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

DIGGA BIGFOOT XD TRENCHER 900MM DIG - 150MM EARTH CHAIN WITH CRUMBER BAR

Galvanised ACS Slasher. Extra heavy duty slasher for contractors, local government bodies and farm clearing work.
Features:
- 150cm cutting width
- Italian Manufactured High Ration Gearboxes (125HP)
- 8 series drive shaft with 4 plate friction clutch.
- High ratio gearbox produces optimum blade tip speed.
- Heavily reinforced 5mm body, galvanizing option.
- Swing back blades
- 300mm underbody clearance to handle the heaviest crop.
- Floating headstock slasher follows ground profile.
- Laminated Bisalloy blade beam offset suction lift blades.
- Front & rear chain curtains standard
- Cat 1 & 2 Clevis Hitch 3PL
- Pivoting RHS Tube Headstock with Chain Backstays (150,180)
Optional Extras:
- Chain guard rear
- Height wheels - single
- Height wheels - twin
- Roller kit
- Support stand Complete
- Support stand Mtg tube only
- Body corner guards
- Council rear sign holder
- Council knapsack holder
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

AGRIFARM GALVANISED 150CM ROTARY SLASHER (125HP) - ACS SERIES

Box blade 5ft , bolt on cutting edge, 5 rippers.
The Daken Box blade is a very useful tool for breaking compact soils and levelling.
Its ideal for filling pot holes or removing bumps and humps in your drive way, it comes with front and rear edges and rippers.
Features:
- Front and rear cutting edges
- Rippers have adjustable depth
- Suits cat 1 or 2 tractors
- Suitable for tractors up to 35hp
- Weight: 165kg
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

DAKEN BOX BLADE 5FT WITH 5 RIPPERS- 61035DC

This Halo Retrofit Kit suits Digga models PD25 - PD50, PDT25 - PDT50 Auger Drives made after 2007. They are suitable for excavators and skid steer loaders.
What is Halo?
Halo is an alignment system located in the hood ring of the auger drive, which provides an operator with a simultaneous clear line of sight to itself, as well as the hole being dug. Halo utilises a band of LED lights, which when fully illuminated green, indicate the drive is plumb.
The Retrofit Kit includes a new hood with halo ring, hood box, 3M cable & cigarette plug.
Options - Extension Cables:
EC-001292 - Halo 1m extension cable
EC-001293 - Halo 3m extension cable
EC-001294 - Halo 6m extension cable
Options - Battery:
EC-001301 - Halo battery kit. Includes battery with zero function, and 1m cable
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

DIGGA HALO RETROFIT KIT (SUITS PD25 - PD50, PDT25 - PDT50)

The hydraulically shiftable MU-FM/S rear and side mulcher, which can operate both to the side and the rear behind the tractor, is a genuine all rounder.
Its operating range is variable from 90° upwards to 60° downwards hydraulically adjustable.
Its large swivelling range of 112 cm means that the mulcher is ideal for working on roadside greenery, dykes, ditches and hedges.
Features:
The MU-FM/S is designed for tractors of up to approx. 45hp and one of its outstanding features is the well established Müthing mechanical safety breakaway system. This allows the mulcher to permanently reduce its load upwards, thus reducing the forces bearing on the lower link and the device.
The mulcher is of course also equipped with the M-Carbide shackle flails and the patented Shark fin" shredding bar system and possesses all the positive mowing and mulching characteristics of the MU-FM.
This produces optimum mowing and mulching and an even spread of the mulch on the surface resulting in a rapid and perfect rotting composting on the surface.
Brilliant in combination with a front mounted mulcher provided appropriate engine power is available.
Options:
Electro-Hydraulic 6/2 distributer with handle and feeler (1 double acting spool valve with floating position required).
Hood Wear Plate (factory mounted).
Second Patented removable shredding bar system: "Shark Fin".
Working hours meter with electronic sensor.
Model:
MU-FM/S 120 1200mm 45 HP WW 1200mm Weight 340kg Flails 20
MU-FM/S 140 1400mm 45 HP WW 1400mm Weight 353kg Flails 24
MU-FM/S 160 1600mm 45 HP WW 1600mm Weight 370kg Flails 28
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

MUTHING MU-FM/S 140 MULCHER (MECHANICAL SAFETY BREAKAWAY)

Find Machinery Attachments For Sale. Browse 1356 Machinery Attachments listings from Farm Supplies Machinery & Equipment.

New & Used Machinery Attachments For Sale in Australia

Farm Supplies Machinery & Equipment

Sale Price

MUTHING 160CM MULCHER SUITS UP TO 35HP MU-C160

SHW LOADER TINE - CRANKED, 820MM LENGTH, M24 X 1.5 THREAD (SQUARE)

DIGGA 350MM AUGER (HEAVY-HARD GROUND) FOR 3 POINT LINKAGE

DIGGA 350MM AUGER (HEAVY-HARD GROUND) FOR RAMDRILL PHD- HYDRAULIC DRIVE

MUTHING MU-H VARIO 180 MULCHER (35-90HP) - FRONT OR REAR

SPAREX LOADER TINE - STRAIGHT, 1,100MM LENGTH (FLUTED)

DIGGA 100MM AUGER (STANDARD- TUNGSTEN) FOR 3 POINT LINKAGE

DIGGA BIGFOOT XD TRENCHER 900MM DIG - 150MM EARTH CHAIN WITH CRUMBER BAR

AGRIFARM GALVANISED 150CM ROTARY SLASHER (125HP) - ACS SERIES

DAKEN BOX BLADE 5FT WITH 5 RIPPERS- 61035DC

DIGGA HALO RETROFIT KIT (SUITS PD25 - PD50, PDT25 - PDT50)

MUTHING MU-FM/S 140 MULCHER (MECHANICAL SAFETY BREAKAWAY)

Farm Supplies Machinery & Equipment

Dealer Address
