The rigid chisel plough is used in a similar fashion to the stump jump as a primary cultivator.
The rigid tine is harder to pull as it has not got the jack hammering effect of the stump jump tine. It should also be used in country which is known to be clean, as the tine is clamped onto the frame and will only shear the clamp bolts under load.
The tines are extremely strong for this reason, using the same tines as the stump jump plough. The machine is ideal for lighter sandy soils where penetration and draft are not a problem.
Features:
9 Tines at 12 adjustable spacings.
Heavy duty 100x100x6mm frame.
Overall width of the machine is 9 wider than the cut width ie 5 tine is 5 9, 7 tine is 79 and so on.
Cat 1 & 2 Linkage.
65mm Reversible Points as standard.
Silicone chrome spring steel shanks.
Available in 5, 7, 9 and 11 tine sizes with tines at 12 adjustable spacings.
Horsepower requirements vary widely but 10 HP per tine is a rough guide.
Excellent underframe trash clearance of 520mm.
Adjustable spring is designed to give a longer, more progressive action, actually chiselling as the machine moves through the ground.
The wheel kit consists of a pair of 14 Holden wheels, height adjustable, fitted on the outside of the machine (increasing the overall width approx 450mm (18).
Options:
0200 Depth Wheels (Pair Holden)
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

JOHN BERENDS RIGID TINE CHISEL PLOUGHS 9'9" (2.9M) - 0184

Note: This model does not include a crumbler, however, it is available as an option. The second picture of this listing shows the cultivator with a crumbler.
Features:
Standard model features a 50×12 flat frame with 50×50 RHS perimeter frame. The flat section frame allows more vibration through out the machine giving a better cultivating effect.
Adjustable headstock allows machine to be offset for closer cultivation near fences, trees, vines etc.
Four bar assembly allows approx 400mm (16') tine clearance which is extremely important in preventing trash build up.
Optional crumbler roller breaks down clods and also controls cultivation depth.
Please note the actual width of the machine is 125mm wider than the working width, and the optional wheel kit adds an additional 500mm.
Specifications:
No of Tines: 24
Tine Size: 32mm x 10mm
Frame Size: 50mm x 12mm Flat
Tractor HP Guide: 2HP per tine
Headstock: 3 Point Linkage Cat 1/2
Options:
Pair Pneumatic Depth Wheels
2.4m Crumbler
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

JOHN BERENDS 2.4M S-TINE (24 TINES) STANDARD CULTIVATOR - MIN 48HP

(Photos show x3 shanks, this model is single shank only)
Deep ripping is most effective in sandy textured soils where plant roots need to grow deeper to access subsoil moisture.
Deep ripping is of particular benefit when it is used to break through compacted layers, allowing roots to access soil water beneath this layer.
Where root growth is impeded by hard layers, a greater amount of energy is required for roots to grow through compacted soil, therefore production is usually reduced.
After removing the compacted layer by deep ripping, plant roots can grow faster and deeper, increasing the amount water and nutrients available to the crop, resulting in improved yield.
Tips:
Ground must be moist enough to allow ripping tines to penetrate below the compacted layer.
Soil must not be too moist that the ripper tines cause smearing rather than fracturing or shattering of the compacted layer.
Single Shank:
Category 2
110hp maximum requirement
Triple Shank:
Category 2 or 3
140hp maximum requirement
Adjustable width
Both Models Feature:
700mm working depth
30mm shank thickness
Safety shear bolt
Galvanised
Replaceable point
Daken sub-soil rippers are perfect for breaking up compacted and hard soil layers.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available
Contact Farm Supplies today for sale or more information
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

DAKEN CAT II SINGLE SHANK SUB SOIL RIPPER (MAX 110HP)

Murray 1.93m, Series 04 Diamond Harrow 3PL hoist lift type system with Series 21 Hoist Frame.
Please note 2nd picture shows how harrows are attached to frame, but the harrows in that picture are not diamond harrows.
4029 - 2 sections - 1.93m.
Complete Set Comprises:
Front Lift Drawbar, Harrow sections, Rear Lift Drawbar and Series 21 3-Point Linkage Hoist Frame.
Suitable for open country and lighter loamy soils, Murray Diamond Harrows are an effective implement used for weed control and final seedbed preparation.
Specialising in shattering soil crusts allowing improved aeration and moisture penetration, it will give your crops every chance of reliable germination and subsequent vigour.
The Diamond frame design is constructed using flat bar material providing the Harrow with strength and rigidity. It features replaceable bolt-in 16mm square section High Carbon Steel tapered tines with a working depth between 50 to 80mm (2 to 3).
Murray Diamond Harrows are supplied in sets complete with drawbars, ranging from 2 sections 2.03m (68) to 10 sections 10.16m (334). Lift type sets using our 3 Point Linkage Hoist Frame (Series 21) are available, making transportation of your Harrows easy and convenient. The complete set is comprised of a Front Lift Drawbar, Harrow Sections, Rear Lift Drawbar and 3 Point Linkage Hoist Frame (Series 21).
Features:
- 2 Point Pull (2PP). Replaceable bolt-in 16mm square section High Carbon Steel tapered tines.
- Manufactured from flat bar material
Specifications:
- 30 kg (66lb).
- Coverage 0.97M (38").
- Tine Spacing 51mm (2").
- Tine Length 152mm (6") approx
- Centre to centre of Front Hooks 508mm (20").
- 5 Rank / 20 Tines.
- Tapered Tines with working depth between 50-80mm (2" - 3")
Model No. 4029 2 section set Rear Lift connectors supplied in lieu of Rear Lift Drawbar
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

MURRAY 1.93M 3PL HOIST LIFT DIAMOND HARROW SYSTEM 2 SECTIONS WITH SERIES 21 HOIST FRAME

Series 39 Hydraulic folding wing frame with 5 section folding S08 Stump Jump Harrow. 4.3m coverage. Transport width: 2.9m.
Please note that 3 point linkage pins are not supplied.
Murray Series 39 Hydraulic Folding Harrow Frames provide a solution to the transportation of multiple Harrow sections.
Designed to fit Category I or II three-point linkage systems, Murray Series 39 Harrow Frames allow transport between paddocks and through smaller sized gates.
Each unit features a top class frame designed and backed by Murrays years of experience.
Simplicity and strength are combined in a compact frame utilising a rigid linkage-mounted centre section and hydraulic folded wings.
Murray Series 39 Harrow Frames suit Category C Harrows including Series 04 Diamond Harrow sections and Series 08 Stump Jump Harrow sections.
Series 39 Folding Harrow Frames are supplied complete with centre section, wing attachments and all rings and links to suit your harrow type and size.
Specifications:
- Anchor points to suit desired Harrow
* Murray Harrows must be pulled (towed) by a tractor correctly fitted with an approved rollover protection structure. Murray Harrows are NOT intended for use with an ATV or Ride On Lawn Mower.

All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

MURRAY 4.3M HYDRAULIC FOLDING FRAME STUMP JUMP HARROW

Stony soil can be a major problem in the construction of parks, gardens, golf courses and any other designated green areas.
Breviglieri has engineered an efficient and functional appliance for burying stones. The robust system and oversized parts make the stone burier a dependable machine that can deal with even the toughest situations.
Stone buriers perform multiple functions in a single pass, delivering considerable agronomic and economic benefits:
- mills soil + seeds
- separates and buries soil + seeds
- levels tilled earth ready for seeding
- breaks up large clods
- facilitates drainage of the seed bed and improves water flow regulation
- reduces soil compaction
- generates significant labour savings
- speeds up soil preparation
- seeding
3 Types of SB35 Models: Please note the price listed is for model SB35 85.
- SB35 85: 12-20HP, 85cm working width, 16L blades, 245kg
- SB35 105: 20-28HP, 105cm working width, 20L blades, 270kg
- SB35 125: 25-35HP, 125cm working width, 24L blades, 295kg
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

BREVIGLIERI 85-125CM STONE BURIER (12-35HP)

Murray 2.28m, Series 06 Kinked Spring Tine 3 Rank Harrow System - Medium Duty- Complete Unit - 6015.
The Series 06 is a medium duty Spring Tine Harrow System popular with farmers for levelling operations in conjunction with primary and secondary tillage implements.
Series 06 Harrows employ double spring tines available in Kinked or Straight Tines, both 10mm in diameter. The tine angle is adjustable to suit your field conditions.
3 rank versions are available in three sizes ranging from 1.37m (4ft 6in) to 2.28m (7ft 6in). Murrays also manufacture an extra wide 14in (335mm) Rank Spacing Straight Tine units which seeks to provide superior trash flow handling capabilities.
Manual lifting has been eliminated with harrows able to be folded and travel with the principal implement.
Specificatons:
- 2.28m
- Weight: 121kg
- Tine Spacing for 3 rank models - 75mm (3in)
- Tine diameter is 10mm, Kinked (standard) or Straight Tine (Optional)
- Tine Length 450mm (17 3/4in) approx
- Rank Spacing 235mm (9 1/4in) STD 3 Rank
- 2 Mount Arms per unit
Features:
- Kinked design Tines as standard.
- Straight design Tines optional.
- This Harrow is designed to fit on to the rear bar of scarifiers, chisel plows, cultivators etc.
- Adjustable Tine angle.
Optional:
- Straight Tines
* Murray Harrows must be pulled (towed) by a tractor correctly fitted with an approved rollover protection structure. Murray Harrows are NOT intended for use with an ATV or Ride On Lawn Mower.

All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

MURRAY 2.28M KINKED SPRING TINE 3 RANK HARROW MEDIUM DUTY COMPLETE UNIT - SERIES 06

3.70m Murray Series 03 Levelling Harrow 4 Rank Deep Sections & Standard Drawbar, Heavy Duty. Complete Set.
3607 - 3.70m (12ft 2in) 4/12 Tine, 1/16 Tine - 87kg.
Murray Levelling Harrows are an excellent choice to complement sowing or cultivation implements. Designed to level soil and seedbeds, the flexible frame design provides durability in all soil types. 3 and 4 rank versions are suitable for use to cover seed in light to medium soils in conjunction with combines and seed drills. The 5 rank model is used in heavier soils to counter weed growth and break down large clods. It is a popular implement that complements cultivators, scarifiers or chisel plows.
If you require additional weight to work your land, a Heavy version of our Series 03 Levelling Harrows is available. Made from heavier High Carbon Steel, the Tine Spacing remains the same as the standard version.
The Series 03 Levelling Harrow is available in either 3 or 4 row widths allowing extensions in increments of 235mm (9 ¼) to suit primary machines of almost any width. This allows a combination of harrow sections to be configured to suit your application.
A full range of standard and heavy duty drawbars are available to correctly match your soil conditions and available working width of your equipment. Harrow sets complete with drawbars range from 2.31m (77) to 5.58m (184) in width.
Specifications:
- Tine Spacing 76mm (3in).
- Tine Length 190mm (7 1/2in) approx.
- Centre to centre of Front Hooks 235mm (9 1/4in).
Features:
- High Carbon Cut Tines.
- Light models manufactured from 25 x 6mm carbon steel and Heavy models from 32 x 6mm.
* Murray Harrows must be pulled (towed) by a tractor correctly fitted with an approved rollover protection structure. Murray Harrows are NOT intended for use with an ATV or Ride On Lawn Mower.

All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

MURRAY SERIES 03 LEVELLING HARROW 3.70M, 4 RANK DEEP SECTIONS & STD DRAWBARS-HEAVY DUTY-COMPLETE SET

Specifications:
Working width: 2800mm
Discs: 24
Weight: 2280kg
Features:
Hydraulic gang adjustment ( Separate ram for both gangs)
Manual levelling adjustment (Optional hydraulic)
12.5/80-15 PR14 tyres
Hydraulic drawbar offset (Optional manual)
660mm scollped discs
6mm thick disc blades
230mm disc spacing
8 bearings (double taper roller) GB280-320
12 bearings (double taper roller) GB370
Bearing protectors
40mm square shaft
150 x 100 x 8mm chassis and gang beam
Swivel hitch
Options:
Manual drawbar offset
Hydraulic levelling adjustment
Models:
GB280 2.8M 24 DISCS 2280kg
GB320 2.8M 28 DISCS 2550kg
GB370 2.8M 32 DISCS 2900kg
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

GB 2.8M, 24 DISCS (110-150HP) MEDIUM DUTY OFFSET DISCS

Medium duty rotary hoe suitable for tractors up to 120hp.
Specifications:
Actual Width: 182cm
Working Width: 160cm
Required HP: 60-120hp
Weight: 600kg
No of Blades: 36
Features:
Rated up to 120hp
PTO 540rpm 4 speed gearbox (155-180 models)
PTO 1000rpm 2 speed gearbox (205-305 models)
Swinging lower links
Gear side drive
80x7mm L blades
6 blades per flange
250mm woring depth
Side skids
Adjustable scroll tailgate
Foot stand
Slip clutch
Options In Lieu of Standard:
Rotor Options:
Spike rotor (30x30x170mm spikes) c/w 2 piece adjustable tailgate (180-305 only)
Anti-pan (straight blade) rotor c/w 2 piece adjustable tailgate (180-305 only)
Roller Options:
Cage Roller (385mm diameter)
Ergon 155 = 860kg with roller
Ergon 180 = 880kg with roller
Ergon 205 = 920kg with roller
Cage Roller (440mm diameter)
Ergon 230 = 980kg with roller
Ergon 255 = 1050kg with roller
Ergon 280 = 1110kg with roller
Ergon 305 = 1180kg with roller
Packer Roller (420mm diameter)
Ergon 155 = 920kg with roller
Ergon 180 = 1000kg with roller
Ergon 205 = 1080kg with roller
Packer Roller (470mm diameter)
Ergon 230 = 1160kg with roller
Ergon 255 = 1240kg with roller
Ergon 280 = 1300kg with roller
Ergon 305 = 1380kg with roller
Accessories:
Automatic cut-out clutch (Cam) - All models
Hydraulic adjustment for rear roller - All models
Bolt on double flange kit (per flange) - All models
'C' (speed) blades in lieu of 'L' blades - All models
Rear steel wheels - All models
Models
ERGON120-155 160cm Working width 60-120hp 600kg 36 Blades
ERGON120-180 185cm Working width 70-120hp 650kg 42 Blades
ERGON120-205 210cm Working width 75-120hp 690kg 48 Blades
ERGON120-230 235cm Working width 80-120hp 733kg 54 Blades
ERGON120-255 260cm Working width 85-120hp 770kg 60 Blades
ERGON120-280 285cm Working width 90-120hp 800kg 66 Blades
ERGON120-305 310cm Working width 100-120hp 880kg 72 Blades
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

CELLI 1.6M (60-120HP) ERGON ROTARY HOE

Note: This model does include a crumbler.
Features:
Standard model features a 50×12 flat frame with 50×50 RHS perimeter frame. The flat section frame allows more vibration through out the machine giving a better cultivating effect.
Adjustable headstock allows machine to be offset for closer cultivation near fences, trees, vines etc.
Four bar assembly allows approx 400mm (16') tine clearance which is extremely important in preventing trash build up.
Please note the actual width of the machine is 125mm wider than the working width, and the optional wheel kit adds an additional 500mm.
Specifications:
No of Tines: 20
Tine Size: 32mm x 10mm
Frame Size: 50mm x 12mm Flat
Tractor HP Guide: 2HP per tine
Headstock: 3 Point Linkage Cat 1/2
Options:
Pair Pneumatic Depth Wheels
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

JOHN BERENDS 2M S-TINE (20 TINES) STANDARD CULTIVATOR (WITH CRUMBLER) - MIN 40HP

Model 44050 complete WITH 2 front connectors Series 44 Broadacre Stump Jump Harrow (2 point pull, Category C).
Options for this listing: Includes drawbar.
44002 - 1.72m with 2 sections (this listings price) 13kg
44003 - 2.58m with 3 sections (call for price) 20kg
44004 - 3.44m with 4 sections (call for price) 31kg
44005 - 4.3m with 5 sections (call for price) 51kg
44006 - 5.16m with 6 sections (call for price) 76kg
Note: The image on this listing only shows 1 section.
Information on the Broadacre Stump Jump Harrow:
- Break down clods, weed control and final seedbed preparation! Experience the difference with Murrays Series 44 known as the Broadacre Stump Jump Harrow. Featuring a Wrap Around tine design, which effectively creates the section frame, the Series 44 is manufactured using High Carbon Steel Forged tines.
- Our forging process shapes the tine into a diamond shape and will ensure that your tines are able to endure rough surfaces and clear your land with ease. The tines also feature greater layback which is designed for superior trash flow. Equipped with 2 pulling points per section, this Stump Jump is compatible with most makes of Hydraulic Drawbars. 100% Australian made and owned.
Specifications for the Stump Jump Harrow (44050)
Harrow weight: 44.2kg (97 1/4 lb)
Coverage: 0.86m (2'10")
Tine Spacing: 44mm (1 3/4in)
Tine Length: 248mm (9 3/4in) approx
Centre to Centre of Front Hooks 444mm (17 1/2in)
5 Ranks / 20 Tines
* Murray Harrows must be pulled (towed) by a tractor correctly fitted with an approved rollover protection structure. Murray Harrows are NOT intended for use with an ATV or Ride On Lawn Mower.

All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

MURRAY 1.72M SERIES 44 STUMP JUMP HARROW INCL DRAWBAR (1.72M-5.16M)

Find Tillage AND Seeding For Sale. Browse 984 Tillage AND Seeding listings from Farm Supplies Machinery & Equipment.

New & Used Tillage AND Seeding For Sale in Australia

Farm Supplies Machinery & Equipment

Sale Price

JOHN BERENDS RIGID TINE CHISEL PLOUGHS 9'9" (2.9M) - 0184

JOHN BERENDS 2.4M S-TINE (24 TINES) STANDARD CULTIVATOR - MIN 48HP

DAKEN CAT II SINGLE SHANK SUB SOIL RIPPER (MAX 110HP)

MURRAY 1.93M 3PL HOIST LIFT DIAMOND HARROW SYSTEM 2 SECTIONS WITH SERIES 21 HOIST FRAME

MURRAY 4.3M HYDRAULIC FOLDING FRAME STUMP JUMP HARROW

BREVIGLIERI 85-125CM STONE BURIER (12-35HP)

MURRAY 2.28M KINKED SPRING TINE 3 RANK HARROW MEDIUM DUTY COMPLETE UNIT - SERIES 06

MURRAY SERIES 03 LEVELLING HARROW 3.70M, 4 RANK DEEP SECTIONS & STD DRAWBARS-HEAVY DUTY-COMPLETE SET

GB 2.8M, 24 DISCS (110-150HP) MEDIUM DUTY OFFSET DISCS

CELLI 1.6M (60-120HP) ERGON ROTARY HOE

JOHN BERENDS 2M S-TINE (20 TINES) STANDARD CULTIVATOR (WITH CRUMBLER) - MIN 40HP

MURRAY 1.72M SERIES 44 STUMP JUMP HARROW INCL DRAWBAR (1.72M-5.16M)

Farm Supplies Machinery & Equipment

Dealer Address
