Designed for extremely tough conditions and is one of the strongest linkage disc ploughs available. Heavy weighted gangs provide excellent digging ability.
Features:
Each machine takes approximately 2-3HP per disc to pull, depending on conditions.
Prong scrapers are also available for heavy clay soil.
Twin spring loaded pressure screws prevent damage in rocky or undulating conditions.
Easy gang angle adjustment.
Fitted with hard wearing European Bellota Boron discs at 9 inch spacing. Available in 22x5mm(or optional 24x5mm sizes).
Cat 1 & 2 linkage.
28mm square high tensile axles.
Greaseable flanged disc bearings with excellent sealing to exclude contaminants.
Solid cast spools, individually machined, provide all the weight in the gangs rather than in the frame (which can add load onto the bearings.
Specifications:
Disc Size 22inch dia, 5mm thick, Scallop Disc
Approx Weight- 820kg
No. Bearings 6
No. Axles 2
Cutting Width 2.06m(6ft 9inch)
Options:
0947 Optional Scrapers suit 18 plate GM40.
0953 Optional Furrow filler (not sold separately).
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

JOHN BERENDS GM40 18 PLATE HEAVY DUTY OFFSET DISCS - 0810, 2-3HP PER DISC

Series 20 Pasture Harrow System - Medium/Heavy duty.
Complete medium/heavy duty harrow systems available from 2.59m (8ft) to 5.18m (17ft) configurations, drag or lift type.
Extreme high quality Australian product, built for our harsh conditions!
For larger field operations over 100 acres (40 hectares), where greater strength and durability are needed in a pasture harrow, the Murray Series 20 Pasture Harrow System performs above the rest. The system consists of a front drawbar, 3, 4 or 5-rank Pasture Harrow sections and heavy steel square chain mesh together with the appropriate weights. The flexibility and strength of the Murray Pasture Harrow sections easily accommodates uneven ground and stony areas of roughly cleared country which would present difficulties for rigid tines harrows. Each harrow section has a 4-point pull which ensures true tracking and proper operation of the tine section.
The heavy duty square chain mesh breaks down and distributes animal manures and other organic matter evenly across the whole pasture. This promotes a quick response to seasonal breaks and optimum pasture growth.
The Murray Series 20 Pasture Harrow is available in four working widths between 2.6 metres (8ft6in) and 5.1m (17ft). Each set is supplied complete with front drawbar, harrow sections and chain mesh sections including weights.
100% Australian made and owned.
Features:
- High Carbon Steel Tines and Square Chain Mesh
- Coverage 0.86m (2ft10in)
- Tine Spacing 44mm (1 3/4in)
- Tine Length 197mm (7 3/4in) approx
- Centre to Centre of Front Hooks 222mm (8 3/4in)
- 3 Ranks 12 Tines or 4 Ranks 16 Tines or 5 Ranks 20 Tines
- Available in 2 chain mesh depths 0.76m (2ft6in) and 1.5m (5ft)
3 Rank sections and Standard 0.76m (2ft6in) Deep Mesh Chain Drag Type:
20001 3 sections, 2.59m (8ft6in) 152kg
20002 4 sections, 3.45m (11ft4in) 230kg
20003 5 sections, 4.31m (14ft2in) 285kg
20004 6 sections, 5.18m (17ft) 345kg
3 Rank sections and Standard 0.76M (2ft6in) Deep Mesh Chain Lift Type:
20240 3 sections, 2.59m (8ft6in) 200kg
20241 4 sections, 3.45m (11ft4in) 280kg
20242* 5 sections, 4.31m (14ft2in) 348kg
* Lift sets Model Numbers 20242 & 20246 also include a Rear Lift / Hoist extension bar.

3 Rank Sections And Super 1.5m (5ft) Deep Mesh Chain Drag Type:
20005 3 Sections, 2.59m (8ft6in) 197kg
20006 4 sections, 3.45m (11ft4in) 297kg
20007 5 sections, 4.31m (14ft2in) 365kg
20008 6 sections, 5.18m (17ft) 435kg
3 Rank sections and Super 1.5m (5ft) Deep Mesh Chain Lift Type:
20244 3 sections 2.59m (8ft6in) 249kg
20245 4 sections 3.45m (11ft4in) 352kg
20246* 5 sections 4.31m (14ft2in) 434kg
* Lift sets Model Numbers 20242 & 20246 also include a Rear Lift / Hoist extension bar.

4 Rank sections and Standard 0.76m (2ft6in) Deep Mesh Chain Drag Type:
20009 3 sections 2.59m (8ft6in) 180kg
20010 4 sections 3.45m (11ft4in) 268kg
20011 5 sections 4.31m (14ft2in) 323kg
20012 6 sections 5.18m (17ft) 390kg
4 Rank sections and Super 1.5m (5ft) Deep Mesh Chain Drag Type:
20013 3 sections 2.59m (8ft6in) 225kg
20014 4 sections 3.45m (11ft4in) 335kg
20015 5 sections 4.31m (14ft2in) 403kg
20016 6 sections 5.18m (17ft) 479kg
5 Rank sections and Standard 0.76m (2ft6in) Deep Mesh Chain Drag Type:
20017 3 sections 2.59m (8ft6in) 213kg
20018 4 sections 3.45m (11ft4in) 308kg
20019 5 sections 4.31m (14ft2in) 375kg
20020 6 sections 5.18m (17ft) 456kg
5 Rank sections and Super 1.5m (5ft) Deep Mesh Chain Drag Type:
20021 3 sections 2.59m (8ft6in) 258kg
20022 4 sections 3.45m (11ft4in) 375kg
20023 5 sections 4.31m (14ft2in) 455kg
20024 6 sections 5.18m (17ft) 541kg
Complete Set Comprises Front Drag Drawbar, Tine sections (3, 4 or 5 Rank deep), Mesh Chain section (2ft 6in or 5ft deep) (and Series 21 3-Point Linkage Hoist Frame, Front Lift Drawbar [in lieu of Front Drag Drawbar] and Rear Lift connectors if Hoist Lift type specified.
Lift sets Model Numbers 20242 & 20246 also feature a Model Number 5071 Rear Lift / Hoist extension bar).
Individual panels, chains and parts also available for sale.
* Murray Harrows must be pulled (towed) by a tractor correctly fitted with an approved rollover protection structure. Murray Harrows are NOT intended for use with an ATV or Ride On Lawn Mower.

All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

MURRAY SERIES 20 PASTURE MEDIUM HARROW SYSTEMS- MEDIUM/HEAVY DUTY - (2.59M - 5.18M) WIDTH

Universal Trashboard specifications shown in images.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SPAREX UNIVERSAL TRASHBOARD - LH (KVERNELAND)

Power Harrow Blade specifications shown in images.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SPAREX POWER HARROW BLADE (REPLACEMENT FOR CELLI)

Rotavator Blade specifications shown in images.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SPAREX ROTAVATOR BLADE CURVED (RH) 90 X 10MM

SPAREX ROTAVATOR BLADE SQUARE (LH) 80 X 8MM

The RM80 offset disc cultivating plough is similar to the RM75 with the main difference being in the greater number of bearings and shorter axles in the disc gang assemblies.
Features:
Ideal for primary and secondary tillage for 75-165 HP tractors.
Fitted with 26inch x 6mm scalloped discs. All discs are European Bellota Boron discs which carry a lifetime warranty against manufacturing failure.
Fitted with two 11×16 flotation wheels on a 5 tonne axle. Hydraulic wheel lift is standard. All models fitted with 8inch Australian made Eaton Rams.
40mm square high tensile gang bolts.
Single pressure screw can be adjusted to transfer weight to the rear of the cultivator, resulting in even disc penetration. Option of fixed or floating position.
Flanged disc bearings designed specifically for severe tillage applications. The bearings are encapsulated in two case hardened zinc plated stampings. Two nitrile O rings are fitted to exclude contaminants and provide a grease seal to ensure lubricant goes directly into the bearing.
Fully adjustable drawbar.
Solid cast spools throughout the gangs provide ballast weight in the gangs, where it counts, rather than the main frame. Each is individually machined to suit the disc for extra strength.
9 inch disc spacing.
Australian made Ryco hoses are used with a minimum burst pressure of 20,400 psi.
Prong type scrapers are standard formed scrapers available on request.
Parking jack is standard.
Optional furrow fillers available.
Specifications:
Approx Weight: 1970kg
No of bearings: 12
No of axles: 6
Cutting width: 2.74m (9ft)
Options:
0953 Optional Furrow filler (not sold separately)
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

JOHN BERENDS RM80 HD TRAILING OFFSET 24 PLATE 26 INCH 6MM SCALLOP DISCS - 0871, SUIT 75-165HP

The RM75 offset disc cultivating plough is a tough, rugged machine designed for Australian conditions. The RM75 is similar to the RM80 with the main difference being in the lesser number of bearings and longer axles. Ideal for primary and secondary tillage for 60HP-130HP tractors.
Features:
Fitted with 24 inch x 5mm scalloped discs. All discs are European Bellota Boron discs which carry a lifetime warranty against manufacture failure.
Fitted with two 750×16 Land Cruiser wheels on a 5 tonne axle. Hydraulic wheel lift is standard. All models fitted with 8 inch Australian made Eaton rams.
Australian made Ryco hoses are used with a minimum burst pressure of 20,400psi.
Twin pressure screws can be adjusted individually to transfer weight to the rear of the plough, resulting in even disc penetration.
40mm square high tensile gang bolts.
Flange disc bearings designed specifically for severe tillage applications. The bearings are encapsulated in two case hardened zinc plated stampings. Two nitrile O rings are fitted to exclude contaminants and provide a grease seal to ensure lubricant goes directly into the bearing.
Fully adjustable drawbar.
Solid cast spools throughout the gangs provide ballast weight in the gangs, where it counts, rather then the main frame. Each is individually machined to suit the disc for extra strength.
9 inch disc spacing.
Fitted with hydraulic lift as standard.
Prong type scrapers are standard formed scrapers on request.
Parking jack is optional.
Optional furrow fillers available.
Specifications:
Approx Weight: 1575kg
No of bearings: 6
No of axles: 2
Cutting width: 2.06m (6ft 9inch)
Options:
0951 Optional jack
0953 Optional Furrow filler (not sold separately)
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

JOHN BERENDS RM75 HD TRAILING OFFSET 18 PLATE 5MM DISCS - 0830, SUIT 60-130HP

Seeder Tine.
Specifications shown in images.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

GRANGE & WALTER SEEDER TINE - 480MM LENGTH

300 series Mekfold Folding Power Harrow with 450mm cage roller.
Specifications:
Tractor HP: 190-300
Working Width: 6880mm
Folded Width for Transport: 2500
Working Depth: 100-300
Blades: 56
Weight: 3510kg
Features:
- Single speed central gearbox (1000 RPM) and multi speed side gearboxes.
- Phased rotors.
- Stone protection system.
- Levelling bar standard.
- Floating side shields.
- Folded width 250cm.
- 450mm Cage roller standard.
- Konic - tapered roller bearings on MEKFOLD350.
- 1 3/4" 20 spline PTO with cam clutch.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

BREVIGLIERI 6.9M MEKFOLD300 POWER HARROW (190-300HP) WITH 450MM CAGE ROLLER

Heavy duty trailing tandem disc plough designed for heavy cultivation in hard conditions. The angle is hydraulically adjusted and has a transport width of under 2.4m.
Features:
Available in 28, 32, 36, 40, 44 and 48 plate models at 9 inch disc spacing's.
Fitted with 24 inch x 6mm or 26 inch x 6mm scalloped discs. All discs are European Bellota Boron discs which carry a lifetime warranty against manufacturing failure.
All models are fitted with hydraulic gang adjustment which allows the gangs to be folded parallel with the main frame, to be under 2.4m overall width.
Gangs can also be opened right up to no angle at all when only a fine till of the topsoil is required.
Solid cast of spools throughout the gangs provide ballast weight in the gangs, where it counts, rather than in the main frame. Each is individually machined to suit the disc for extra strength.
Flanged disc bearings designed specifically for severe tillage applications. The bearings are encapsulated in two case hardened zinc plated stampings. Two nitrile O rings are fitted to exclude contaminants and provide a grease seal to ensure lubricant goes directly into the bearing.
Buster tine removes centre ridge to create a level finish.
Integrated furrow fillers are standard.
Fitted with four Land Cruiser wheels on a 5 tonne axle. Hydraulic wheel lift is standard.
40mm square high tensile gang bolts.
Fully adjustable drawbar height with parallel lift for better transportation.
Wheelkit locking arms reduce stress on the hydraulics when transporting.
Australian made Ryco hoses are used with a minimum burst pressure of 20,400 psi.
Australian made Eaton cylinders.
Prong type scrapers are standard formed scrapers on request.
Parking jack is standard.
Specifications:
Approx Weight: 3290kg
No. of Bearings: 12
No. of axles: 4
Cutting width: 3.43m (11ft 3inch)
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

JOHN BERENDS TH100 HD TRAILING TANDEM DISCS - 28 PLATE X 26 INCH DISCS - 0960

Specifications:
Beta DTM-20 Multi Disc Harrow
22'' / 560mm Scalloped Discs
Number of discs: 20
Working depth with 560 mm discs (mm) : up to 150
Working depth with 610 mm discs (mm): Up to 200
Working width (mm): 2700 mm
Overall width (mm): 2900
Overall length in operation (mm) :2840
Transit-mode length (mm): 2060
Overall height in operation (mm): 1510
Transit-mode height (mm): 2280
Weight with cage roller (kg): 1520
Weight with double cage roller (kg): 1660
Required tractor power (HP): 78-85
Beta utilizes its clever design and systematically arranged components, farmers can harness a higher working capacity while saving time and fuel costs. It is an excellent choice for seedbed preparation and stubble processing.
The main platform is built using a select choice of high-quality thick steel plates. Another noticeable aspect is that the brush tines are suspended on solid HSS steel for added strength and effectiveness against stubborn weeds and clumped-up soil. Its main contraption is its two rows of opposite facing disc harrows that very aggressive work front which ensures optimal flow of soil and/or residue in every work condition. The discs are mounted on independent suspensions and are spaced by 30 cm to increase efficiency and operating performance.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

MINOS AGRI BETA DTM-20 SPRING MOUNTED DISC ARM - 2.7M (MIN 78HP)

Find Tillage AND Seeding For Sale. Browse 970 Tillage AND Seeding listings from Farm Supplies Machinery & Equipment.

New & Used Tillage AND Seeding For Sale in Australia

Farm Supplies Machinery & Equipment

Sale Price

JOHN BERENDS GM40 18 PLATE HEAVY DUTY OFFSET DISCS - 0810, 2-3HP PER DISC

MURRAY SERIES 20 PASTURE MEDIUM HARROW SYSTEMS- MEDIUM/HEAVY DUTY - (2.59M - 5.18M) WIDTH

SPAREX UNIVERSAL TRASHBOARD - LH (KVERNELAND)

SPAREX POWER HARROW BLADE (REPLACEMENT FOR CELLI)

SPAREX ROTAVATOR BLADE CURVED (RH) 90 X 10MM

SPAREX ROTAVATOR BLADE SQUARE (LH) 80 X 8MM

JOHN BERENDS RM80 HD TRAILING OFFSET 24 PLATE 26 INCH 6MM SCALLOP DISCS - 0871, SUIT 75-165HP

JOHN BERENDS RM75 HD TRAILING OFFSET 18 PLATE 5MM DISCS - 0830, SUIT 60-130HP

GRANGE & WALTER SEEDER TINE - 480MM LENGTH

BREVIGLIERI 6.9M MEKFOLD300 POWER HARROW (190-300HP) WITH 450MM CAGE ROLLER

JOHN BERENDS TH100 HD TRAILING TANDEM DISCS - 28 PLATE X 26 INCH DISCS - 0960

MINOS AGRI BETA DTM-20 SPRING MOUNTED DISC ARM - 2.7M (MIN 78HP)

Farm Supplies Machinery & Equipment

Dealer Address
