Super heavy duty , high clearance folding rotary hoe (Spike & Anti-pan rotor options available , suitable for tractors up to 360 hp.
Specifications:
Actual Width: 516cm
Working Width: 491cm
Required HP: 200-360hp
Weight: Cage roller - 3300kg, Packer roller - 3600kg
No of Blades: 114
Features:
Rotary hoe
Rated up to 360 hp
Hydraulic folding with safety locks and 2.5m transport width
80 x 10mm 'L' or 'C' shaped blades(options for 10mm blades, spikes rotor or antispan rotor)
Double welded blade flanges
16mm blade bolts
1000 rpm
Unique central split gearbox system for high horsepower loading and efficient torque distribution
Two speed side gearboxes with available gear speeds of: 208,230,260,284,310,340,375,410
2 piece split tailgates with dual manual angle adjustment
High clearance under hood
Gear side drive
Category three hitch, suitable for quick hitch (floating or fixed bottom links)
Grease lubricated centre drive bearings
Central loosening tine for 5mm bed gap
250mm working depth
Cam clutches on side driveshafts
Rear light frame with LED lights and AU Hazard panels
1 3/4 20 spline heavy duty front driveshaft
2 year warranty
Accessories:
450hp gearbox
Oil cooler with reservoir on central gearbox
Oil coolers with reservoir on side gearboxes
Front sod breaking disks (pair)
Track eradicators (set of 4)
'C' (speed) blades in lieu of 'L' blades
Options in Lieu of Standard:
Rotor Options
Double flange rotor (c/w 10mm blades)
Spike rotor spike (30x30x195)
Anti-pan rotor (10mm straight blade)
Roller Options
Cage roller (500mm diameter) with hydraulic adjustment
Packer roller (555mm diameter) with hydraulic adjustment
Models:
SUPERTIGER360P-500 491cm Working Width 200-360HP 114 BLADES
SUPERTIGER360P-500 541cm Working Width 220-360HP 126 BLADES
SUPERTIGER360P-600 591cm Working Width 240-360HP 138 BLADES
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

CELLI 4.91M (200-360 HP) SUPER TIGER ROTARY HOE

Series 23 Small Acreage Chain Harrow. (0.91m x 0.76m)
Designed to be operated via UTV, 4WD or ride on Mower.
Specifications:
- Available in 0.76m (26) depth
- High Carbon 10mm Square Steel
- Weight: 29kg
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

MURRAY SMALL ACREAGE CHAIN HARROW (0.91M X 0.76M) - SERIES 23

Murray 1.83m, Series 06 Straight Spring Tine 3 Rank Extra Wide Spacing Harrow System - Medium Duty- Complete Unit - 6060.
The Series 06 is a medium duty Spring Tine Harrow System popular with farmers for levelling operations in conjunction with primary and secondary tillage implements.
Series 06 Harrows employ double spring tines available in Kinked or Straight Tines, both 10mm in diameter. The tine angle is adjustable to suit your field conditions.
3 rank versions are available in three sizes ranging from 1.37m (4ft 6in) to 2.28m (7ft 6in). Murrays also manufacture an extra wide 14in (335mm) Rank Spacing Straight Tine units which seeks to provide superior trash flow handling capabilities.
Manual lifting has been eliminated with harrows able to be folded and travel with the principal implement.
Specificatons:
- 1.83m
- Weight: 81.5kg
- Tine Spacing - 75mm (3in)
- Tine diameter is 10mm, Straight Tine
- Tine Length 450mm (17ft 3/4in) approx
- Rank Spacing 3555mm (14in) - Extra Wide
- 1 Mount Arm per unit
Features:
- 14inch (355mm) Extra Wide Rank spacing with straight tines.
- Adjustable Tine angle.
* Murray Harrows must be pulled (towed) by a tractor correctly fitted with an approved rollover protection structure. Murray Harrows are NOT intended for use with an ATV or Ride On Lawn Mower.

All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

MURRAY 1.83M STRAIGHT SPRING TINE 3 RANK EXTRA WIDE SPACING HARROW MEDIUM DUTY COMPLETE UNIT - SERIES 06

The RM80 offset disc cultivating plough is designed for extremely tough conditions. It is similar to the RM75 with the main difference being in the greater number of bearings and shorter axles in the disc gang assemblies.
Features:
Ideal for primary and secondary tillage for 75HP-165HP tractors.
Fitted with 24inch x 6mm scalloped discs. All discs are European Bellota Boron discs which carry a lifetime warranty against manufacturing failure.
Fitted with two 11×16 flotation wheels on a 5 tonne axle. Hydraulic wheel lift is standard. All models fitted with 8inch Australian made Eaton Rams.
40mm square high tensile gang bolts.
Single pressure screw can be adjusted to transfer weight to the rear of the cultivator, resulting in even disc penetration. Option of fixed or floating position.
Flanged disc bearings designed specifically for severe tillage applications. The bearings are encapsulated in two case hardened zinc plated stampings. Two nitrile O rings are fitted to exclude contaminants and provide a grease seal to ensure lubricant goes directly into the bearing.
Fully adjustable drawbar.
Solid cast spools throughout the gangs provide ballast weight in the gangs, where it counts, rather than the main frame. Each is individually machined to suit the disc for extra strength.
9 inch disc spacing.
Australian made Ryco hoses are used with a minimum burst pressure of 20,400 psi.
Prong type scrapers are standard formed scrapers available on request.
Parking jack is standard.
Optional furrow fillers available.
Specifications:
Approx Weight: 1970kg
No of bearings: 12
No of axles: 6
Cutting width: 2.74m (9ft)
Options:
0953 Optional Furrow filler (not sold separately)
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

JOHN BERENDS RM80 HD TRAILING OFFSET 24 PLATE 24 INCH 6MM SCALLOP DISCS - 0861, SUIT 75-165HP

Heavy duty double drive fixed rotary hoe suitable for tractors up to 280 hp.
Specifications:
Actual Width: 463cm
Working Width: 441cm
Required HP: 200-280hp
Weight: 2120kg
No of Blades: 102
Features:
Rated up to 280 hp
Unique central split gearbox system for high horsepower loading and efficient torque distribution
Two speed side gearboxes with available gear speeds of: 208,230,260,284,310,340,375,410
Swinging lower links
Gear side drive
Side drive shafts with automatic safety clutches (CAM)
80 x 8mm 'L' blades
6 blades per flange
250mm working depth
Side skids or rear rollers with hydraulic adjustment
Adjustable , spring loaded tailgates
Options in Lieu of Standard:
Rotor Options
Double flange rotor (c/w 10mm blades)
Spike rotor spike (30x30x195)
Anti-pan rotor (10mm straight blade)
Roller Options
Cage roller (500mm diameter) with hydraulic adjustment
Packer roller (555mm diameter) with hydraulic adjustment
Models:
TIGER 280DD-400 391cm Working Width 180-280hp 2000kg 90 L blades
TIGER 280DD-450 441cm Working Width 200-280hp 2120kg 102 L blades
TIGER 280DD-500 491cm Working Width 220-280hp 2240kg 114 L blades
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

CELLI 4.41M (200-280 HP) TIGER ROTARY HOE

Rotavator Blade specifications shown in images.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SPAREX ROTAVATOR BLADE CURVED (RH) 60 X 6MM

2.31m Murray Series 03 Levelling Harrow 4 Rank Deep Sections & Standard Drawbar, Heavy Duty. Complete Set.
3601 - 2.31m (7ft 7in) 2/12 Tine, 1/16 Tine - 52kg.
Murray Levelling Harrows are an excellent choice to complement sowing or cultivation implements. Designed to level soil and seedbeds, the flexible frame design provides durability in all soil types. 3 and 4 rank versions are suitable for use to cover seed in light to medium soils in conjunction with combines and seed drills. The 5 rank model is used in heavier soils to counter weed growth and break down large clods. It is a popular implement that complements cultivators, scarifiers or chisel plows.
If you require additional weight to work your land, a Heavy version of our Series 03 Levelling Harrows is available. Made from heavier High Carbon Steel, the Tine Spacing remains the same as the standard version.
The Series 03 Levelling Harrow is available in either 3 or 4 row widths allowing extensions in increments of 235mm (9 ¼) to suit primary machines of almost any width. This allows a combination of harrow sections to be configured to suit your application.
A full range of standard and heavy duty drawbars are available to correctly match your soil conditions and available working width of your equipment. Harrow sets complete with drawbars range from 2.31m (77) to 5.58m (184) in width.
Specifications:
- Tine Spacing 76mm (3in).
- Tine Length 190mm (7 1/2in) approx.
- Centre to centre of Front Hooks 235mm (9 1/4in).
Features:
- High Carbon Cut Tines.
- Light models manufactured from 25 x 6mm carbon steel and Heavy models from 32 x 6mm.
* Murray Harrows must be pulled (towed) by a tractor correctly fitted with an approved rollover protection structure. Murray Harrows are NOT intended for use with an ATV or Ride On Lawn Mower.

All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

MURRAY SERIES 03 LEVELLING HARROW 2.31M, 4 RANK DEEP SECTIONS & STD DRAWBARS-HEAVY DUTY-COMPLETE SET

3.70m Murray Series 03 Levelling Harrow 4 Rank Deep Sections & Standard Drawbar, Heavy Duty. Complete Set.
3607 - 3.70m (12ft 2in) 4/12 Tine, 1/16 Tine - 87kg.
Murray Levelling Harrows are an excellent choice to complement sowing or cultivation implements. Designed to level soil and seedbeds, the flexible frame design provides durability in all soil types. 3 and 4 rank versions are suitable for use to cover seed in light to medium soils in conjunction with combines and seed drills. The 5 rank model is used in heavier soils to counter weed growth and break down large clods. It is a popular implement that complements cultivators, scarifiers or chisel plows.
If you require additional weight to work your land, a Heavy version of our Series 03 Levelling Harrows is available. Made from heavier High Carbon Steel, the Tine Spacing remains the same as the standard version.
The Series 03 Levelling Harrow is available in either 3 or 4 row widths allowing extensions in increments of 235mm (9 ¼) to suit primary machines of almost any width. This allows a combination of harrow sections to be configured to suit your application.
A full range of standard and heavy duty drawbars are available to correctly match your soil conditions and available working width of your equipment. Harrow sets complete with drawbars range from 2.31m (77) to 5.58m (184) in width.
Specifications:
- Tine Spacing 76mm (3in).
- Tine Length 190mm (7 1/2in) approx.
- Centre to centre of Front Hooks 235mm (9 1/4in).
Features:
- High Carbon Cut Tines.
- Light models manufactured from 25 x 6mm carbon steel and Heavy models from 32 x 6mm.
* Murray Harrows must be pulled (towed) by a tractor correctly fitted with an approved rollover protection structure. Murray Harrows are NOT intended for use with an ATV or Ride On Lawn Mower.

All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

MURRAY SERIES 03 LEVELLING HARROW 3.70M, 4 RANK DEEP SECTIONS & STD DRAWBARS-HEAVY DUTY-COMPLETE SET

Series 35 Forged Tine Levelling Harrow System (Category L) "Extra Heavy" Harrow Sections including optional drawbar.
4 Rank (Length) Deep Harrow Sections (May be used with seeding combines, air seeders, etc.)
Model:
35003 - 12 Tine (3W x 4L deep) 2.3m wide (min) - this listings price. Heavy Duty drawbar options listed below (2.3m - 5.6m wide options).
Note: Picture shown first is 5 Rank (Length).
Information on the Harrow System:
- If you want to level your land and need a Harrow that will stand up to the demands of todays conditions, Murrays manufacture an Extra Heavy Levelling Harrow. Built from heavier High Carbon Steel, each Tine is specially forged revealing a diamond shape designed to level your ground. Tine spacing remains the same as our standard Series 03 version.
- The Series 35 is suitable for heavier clay type soils and is used after primary or secondary tillage. Available in three and four row widths allowing flexibility to build up Harrow Sections to suit the width of your primary machine. 100% Australian made and owned.
Specifications of the Harrow Sections:
- Tine Spacing 76mm (3in)
- Tine length 190mm (7 1/2in) approx.
- Centre to Centre of Front Hooks 235mm (9 3/4in)
Features:
- Forged Tine ends. Manufactured from 25 x 10mm carbon steel.
Heavy Duty Drawbars (only) options:
3074 - 7ft 7in (10 bar anchors) 9kg
3075 - 8ft 5in (11 bar anchors) 10kg
3076 - 9ft 2in (12 bar anchors) 13kg
3077 - 9ft 11in (13 bar anchors) 14kg
3078 - 10ft 8in (14 bar anchors) 15kg
3079 - 11ft 5in 16 row (15 bar anchors) 17kg
3080 - 12ft 2in (16 bar anchors) 21kg
3081 - 13ft (17 bar anchors) 27kg
3082 - 13ft 9in 20 row (18 bar anchors) 29kg
3083 - 14ft 6in (19 bar anchors) 31kg
3084 - 15ft 3in (20 bar anchors) 33kg
3085 - 16ft 24 row (21 bar anchors) 34kg
3073 - 16ft 10in (22 bar anchors) 36kg
3086 - 18ft 4in 28 row (24 bar anchors) 40kg
* Murray Harrows must be pulled (towed) by a tractor correctly fitted with an approved rollover protection structure. Murray Harrows are NOT intended for use with an ATV or Ride On Lawn Mower.

All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

MURRAY 2.3M WIDE (3W X 4L TINES) EXTRA HEAVY DUTY LEVELLING HARROW (2.3M - 5.6M)

Series 30 1.78m Mounted Spring Tine Harrow System - Light Duty 2 Rank- Straight Tines.
The Series 30 Light Duty is the perfect implement for sandy to light soils. Specifically designed to increase trash flow using wide spacing between each straight tine, the 2 rank is a lighter duty harrow available in five sizes ranging from 1.78m (510) to 3.20m (106). Each section is supplied complete with two mount arms.
Harrow depth control is adjustable by means of specially designed cam-action fitting within the mount arm.
Specifications:
- Coverage: 1.78m
- Weight: 56kg
- Tine spacing 85mm (3 3/8) 2 Rank.
- Tine Diameter 10mm Straight Tine.
- Tine length 385mm (15) approx.
- Rank Spacing 324mm (12 3/4").
- 2 Mount Arms per unit.
- Mount clamp suits 81mm to 100mm (3 1/4 to 4) square frame positioned on the flat or on the edge (Spacers
required for 75mm [3] square frame).
Features:
- May be attached to the rear bar of light duty cultivators, seeding drills, etc.
- Unit features two Series 30 Mount Arms.
- A cam incorporated in the mount clamp adjusts the height of the Harrow Tine Section.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

MURRAY 1.78M MOUNTED SPRING TINE HARROW SYSTEM - LIGHT DUTY - 2 RANK

Heavy duty trailing tandem disc plough designed for heavy cultivation in hard conditions. The angle is hydraulically adjusted and has a transport width of under 2.4m.
Features:
Available in 28, 32, 36, 40, 44 and 48 plate models at 9 inch disc spacing's.
Fitted with 24 inch x 6mm or 26 inch x 6mm scalloped discs. All discs are European Bellota Boron discs which carry a lifetime warranty against manufacturing failure.
All models are fitted with hydraulic gang adjustment which allows the gangs to be folded parallel with the main frame, to be under 2.4m overall width.
Gangs can also be opened right up to no angle at all when only a fine till of the topsoil is required.
Solid cast of spools throughout the gangs provide ballast weight in the gangs, where it counts, rather than in the main frame. Each is individually machined to suit the disc for extra strength.
Flanged disc bearings designed specifically for severe tillage applications. The bearings are encapsulated in two case hardened zinc plated stampings. Two nitrile O rings are fitted to exclude contaminants and provide a grease seal to ensure lubricant goes directly into the bearing.
Buster tine removes centre ridge to create a level finish.
Integrated furrow fillers are standard.
Fitted with four Land Cruiser wheels on a 5 tonne axle. Hydraulic wheel lift is standard.
40mm square high tensile gang bolts.
Fully adjustable drawbar height with parallel lift for better transportation.
Wheelkit locking arms reduce stress on the hydraulics when transporting.
Australian made Ryco hoses are used with a minimum burst pressure of 20,400 psi.
Australian made Eaton cylinders.
Prong type scrapers are standard formed scrapers on request.
Parking jack is standard.
Specifications:
Approx Weight: 3500kg
No. of Bearings: 16
No. of axles: 8
Cutting width: 3.88m (12ft 9inch)
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

JOHN BERENDS TH100 HD TRAILING TANDEM DISCS - 32 PLATE X 24 INCH DISCS - 0973

Series 37 1.83m Mounted Spring Tine Harrow System - Heavy Duty 3 Rank- Kinked Tines.
A Heavy Duty Spring Tine Harrow. Designed to fit onto the rear bar of Scarifiers and Chisel Plows to assist in breaking
down ground and seed bed preparation.
Complementing scarifiers and chisel plows, it will break down cloddy ground and aid final seedbed preparation.
Using larger 465mm (183/4) by 12mm Diameter tines with a 75mm (3) spacing, the Series 37 is put together using a heavier tine section frame.
Available in a 3 Rank model, it is supplied with two mounting arms for each section. Two sizes are available 1.83m (6) and 2.28m (76).
Experience the difference with our kinked tine designed to exert aggression in breaking down cloddy ground and final seedbed preparation.
Specifications:
- Coverage: 1.83m
- Weight: 146kg
- Tine spacing 75mm (3) 3 Rank.
- Tine Diameter 12mm Kinked Tine.
- Tine length 465mm (18 1/4) approx.
- Rank spacing 305mm (12).
- 2 Mount Arms per unit.
Features:
- Unit features two Mount Arms (Model 37004 with reinforced bolt-on clamp plate).
- Standard mount clamp suits 75mm to 100mm (3 to 4) square frames positioned on the flat.
- Adjustable Tine angle
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

MURRAY 1.83M MOUNTED SPRING TINE HARROW SYSTEM - HEAVY DUTY - 3 RANK

Find Tillage AND Seeding For Sale. Browse 984 Tillage AND Seeding listings from Farm Supplies Machinery & Equipment.

New & Used Tillage AND Seeding For Sale in Australia

Farm Supplies Machinery & Equipment

Sale Price

CELLI 4.91M (200-360 HP) SUPER TIGER ROTARY HOE

MURRAY SMALL ACREAGE CHAIN HARROW (0.91M X 0.76M) - SERIES 23

MURRAY 1.83M STRAIGHT SPRING TINE 3 RANK EXTRA WIDE SPACING HARROW MEDIUM DUTY COMPLETE UNIT - SERIES 06

JOHN BERENDS RM80 HD TRAILING OFFSET 24 PLATE 24 INCH 6MM SCALLOP DISCS - 0861, SUIT 75-165HP

CELLI 4.41M (200-280 HP) TIGER ROTARY HOE

SPAREX ROTAVATOR BLADE CURVED (RH) 60 X 6MM

MURRAY SERIES 03 LEVELLING HARROW 2.31M, 4 RANK DEEP SECTIONS & STD DRAWBARS-HEAVY DUTY-COMPLETE SET

MURRAY SERIES 03 LEVELLING HARROW 3.70M, 4 RANK DEEP SECTIONS & STD DRAWBARS-HEAVY DUTY-COMPLETE SET

MURRAY 2.3M WIDE (3W X 4L TINES) EXTRA HEAVY DUTY LEVELLING HARROW (2.3M - 5.6M)

MURRAY 1.78M MOUNTED SPRING TINE HARROW SYSTEM - LIGHT DUTY - 2 RANK

JOHN BERENDS TH100 HD TRAILING TANDEM DISCS - 32 PLATE X 24 INCH DISCS - 0973

MURRAY 1.83M MOUNTED SPRING TINE HARROW SYSTEM - HEAVY DUTY - 3 RANK

Farm Supplies Machinery & Equipment

Dealer Address
