5.58m Murray Series 03 Levelling Harrow 4 Rank Deep Sections & Standard Drawbar, Light Duty. Complete Set.
3514 - 5.58m (18ft 4in)(28 Row) 6/16 Tine - 108kg.
Murray Levelling Harrows are an excellent choice to complement sowing or cultivation implements. Designed to level soil and seedbeds, the flexible frame design provides durability in all soil types. 3 and 4 rank versions are suitable for use to cover seed in light to medium soils in conjunction with combines and seed drills. The 5 rank model is used in heavier soils to counter weed growth and break down large clods. It is a popular implement that complements cultivators, scarifiers or chisel plows.
If you require additional weight to work your land, a Heavy version of our Series 03 Levelling Harrows is available. Made from heavier High Carbon Steel, the Tine Spacing remains the same as the standard version.
The Series 03 Levelling Harrow is available in either 3 or 4 row widths allowing extensions in increments of 235mm (9 ¼) to suit primary machines of almost any width. This allows a combination of harrow sections to be configured to suit your application.
A full range of standard and heavy duty drawbars are available to correctly match your soil conditions and available working width of your equipment. Harrow sets complete with drawbars range from 2.31m (77) to 5.58m (184) in width.
Specifications:
- Tine Spacing 76mm (3in).
- Tine Length 190mm (7 1/2in) approx.
- Centre to centre of Front Hooks 235mm (9 1/4in).
Features:
- High Carbon Cut Tines.
- Light models manufactured from 25 x 6mm carbon steel and Heavy models from 32 x 6mm.
* Murray Harrows must be pulled (towed) by a tractor correctly fitted with an approved rollover protection structure. Murray Harrows are NOT intended for use with an ATV or Ride On Lawn Mower.

All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

MURRAY SERIES 03 LEVELLING HARROW 5.58M, 4 RANK DEEP SECTIONS & STD DRAWBARS-LIGHT DUTY-COMPLETE SET

Single Tine Ripper up to 100hp.
Daken single tine rippers are a useful and versatile implement around the property.
The single tine ripper can be used to preparing soil for crops or tree lines, disturbing rabbit warrens, breaking up or aerating compacted ground.
Also used on sloping ground to reduce water runoff.
By ripping around the contours of your country you will increase water retention in the subsoil allowing pasture to thrive into the dry season.
The ripper can also be attached with the pipe layer attachment for laying poly pine up to 2inch.
Features:
- Suits tractors up to 100hp
- Cat 1 and 2
- Max depth 800mm
- Leg 150mm x 50mm
- Reversible point 300mm x 75mm x 15mm
Optional Pipe layer take 2 poly pipe.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

DAKEN SINGLE TINE RIPPER UP TO 100HP GALVANIZED - 86000DC

Description
RZ Range RLC Leaf Spring Rippers 3m R9-3
Heavy duty leaf spring ripper for primary cultivation, winter crop cultivation and increased soil drainage. Fixed and hydraulic folding models available. This is the Fixed Frame version.
Specifications
Working Width: 300cm
Required HP: 125-200hp
Rippers: 9
Fixed Frame.
Features
Double clamp bolt-on legs.
Adjustable leaf spring.
Heavy duty 100x100mm box section.
Adjustable rubber depth wheels.
865kg breakout.
Reversible chisel point.
Solid steel legs.
Options
Rear rollers.
Rubber depth wheels (2×600-9)
Wing share.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

RLC 3M FIXED FRAMED LEAF SPRING RIPPERS (9 RIPPERS)

Heavy duty trailing tandem disc plough designed for heavy cultivation in hard conditions. The angle is hydraulically adjusted and has a transport width of under 2.4m.
Features:
Available in 28, 32, 36, 40, 44 and 48 plate models at 9 inch disc spacing's.
Fitted with 24 inch x 6mm or 26 inch x 6mm scalloped discs. All discs are European Bellota Boron discs which carry a lifetime warranty against manufacturing failure.
All models are fitted with hydraulic gang adjustment which allows the gangs to be folded parallel with the main frame, to be under 2.4m overall width.
Gangs can also be opened right up to no angle at all when only a fine till of the topsoil is required.
Solid cast of spools throughout the gangs provide ballast weight in the gangs, where it counts, rather than in the main frame. Each is individually machined to suit the disc for extra strength.
Flanged disc bearings designed specifically for severe tillage applications. The bearings are encapsulated in two case hardened zinc plated stampings. Two nitrile O rings are fitted to exclude contaminants and provide a grease seal to ensure lubricant goes directly into the bearing.
Buster tine removes centre ridge to create a level finish.
Integrated furrow fillers are standard.
Fitted with four Land Cruiser wheels on a 5 tonne axle. Hydraulic wheel lift is standard.
40mm square high tensile gang bolts.
Fully adjustable drawbar height with parallel lift for better transportation.
Wheelkit locking arms reduce stress on the hydraulics when transporting.
Australian made Ryco hoses are used with a minimum burst pressure of 20,400 psi.
Australian made Eaton cylinders.
Prong type scrapers are standard formed scrapers on request.
Parking jack is standard.
Specifications:
Approx Weight: 3290kg
No. of Bearings: 12
No. of axles: 4
Cutting width: 3.43m (11ft 3inch)
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

JOHN BERENDS TH100 HD TRAILING TANDEM DISCS - 28 PLATE X 26 INCH DISCS - 0960

9 leg Subsoiler with tines & discs up to 450mm working depth. Made in new Zealand.
304 Auto Reset Panerazers are the ultimate sub soiling machine. Especially when the soils to be aerated are heavy & full of obstructions.
Being auto reset makes your sub soiling job seamless as the legs simply lift over any obstruction & immediately reset automatically so you can continue aerating your soils without stopping. Leaf spring reset has a great advantage over rams, not only do they require less maintenance, but the legs are at the highest point of resistance while in the ground & resistance reduces as they lift.
This ensures the legs do not tip falsely but ensures they do clear obstructions when struck.
Rata Panerazer legs are in a 'V' formation. This reduces drag between the legs making it easier to pull and uses less fuel. V formation also means the legs leave the ground independently at the headlands which eliminates 'heaving'.
They feature a heavy duty build RHS main frame construction with reinforcing to cope with hard conditions. The wear protected legs are also securely bolted into the reset mounts.
Working depth is easily controlled via the rear roller setting and tractor 3 point linkage. The rear roller is secured to the main aerator frame with heavy machine pins.
The rear roller is securely mounted into a sealed bearing to ensure smooth operation with minimal wear. The roller is also kept clean by a scraper mounted just behind it.
An innovative modular leg, foot & point assembly provides maximum flexibility of parts. Cast point provides extra wear protection in the form of bevelled hard wearing plate.
Winged feet are an option on the Rata Panerazer range (see photos attached). These provide extra ground lift when sub soiling to create greater subsoil disturbance.
The auto reset system is powered by heavy duty leaf springs mounted on each leg. Leaf springs reset immediately after tripping & clearing the obstacle unlike other reset systems such as hydraulic. This tension is easily adjusted via the 'tension bolt' mounted on the leg. This enables the operator to adjust the tension to the ideal level required for the ground they're operating in. The tension adjustment spanner is included with the implement.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

RATA 9 LEG (AUTO RESET) SUBSOIL CULTIVATOR (150HP RECOMMENDED)

Daken Dillon Pasture Harrows - Pasture Harrow - 8ft wide.
Includes draw bar, scarifier section and spreader section and 4 x trail weights.
Take advantage of summer storms and rain to improve your pasture.
Using a Daken Dillon harrow will revitalize tired pasture buy breaking up and spreading manure so it can be readily taken up by pastures and encouraging pasture growth.
Manure is a very valuable commodity, more than 80 percent of the plant nutrients are returned to the soil through the deposition of manure and urine.
Feeding stock with hay during drought will see lots of leftover clumps mixed with manure that can be better spread out where it can do some good.
Daken Dillon Pasture Harrows are a simple product for breaking up and spreading cow manure.
The Daken Dillon Pasture Harrow can be towed behind a tractor or the farm ute.
Manufactured using heavy 12mm square and round bar.
Features:
- Improve Pasture
- Spread Manure
- Flexible
- Chain sections not welded
- Additional sections can be added
- Chain 11mm
- Bar 5mm
- Length: 2 meters
- Weight: 118kg
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

DAKEN DILLON PASTURE HARROW 8FT WIDE - GALVANISED DRAW BARS - 02100DC

Sparex Conical Head Bolt 2 Flats With Nut. Specifications shown in images.

SPAREX CONICAL HEAD BOLT 2 FLATS WITH NUT - 1/2" X 1 1/2"

The reverse rotation stone burier is ideal for horticultural applications in a range of soil conditions.
Specifications:
Actual Width: 203cm
Working Width: 185cm
Required HP: 80-110hp
Weight: 1157kg
No of Blades: 54
Features:
Rotary hoe or reverse rotor rotation
Rated up to 80hp
Four speed gearbox
540 rpm
Category two hitch
Stone burier blades (90x10mm)
6 blades per flange
Rear tailgate with spring cushioned comb
Levelling bar
25cm working depth
Gear side drive
Cam clutch
Front sod breaking discs
Mesh roller
Options in Lieu of Standard:
Hydraulic roller adjustment
Oil cooler
Models:
ARES-BF130 1.3M 60-110HP 830kg 36 blades
ARES-B150 1.5M 65-110HP 920kg 42 blades
ARES-BF170 1.7M 75-110HP 1055kg 48 blades
ARES-BF185 1.85M 80-110HP 1157kg 54 blades
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

CELLI 1.85M (80-110HP) ARES STONE BURIER

4ft Mini Drawbar Harrow (inc Drawbar).
Tyne Diameter = 1/2
Width & Length = 4 x 4.5
Total weight = 23kg
Points per 4ft = 108
Horse power requirement = 6hp
Turnlock means the Harrows can be turned over to use for levelling also.
Flexible two way design - Variable tyne positions (heavy, medium, light) allows for a single type of tool to fit each properties needs.
The Delta drawbars (made in Canada) are heavy duty steel construction with Turnlock design. Ideal for extreme tillage conditions.
Heavy Residue is quickly surfaced without clogging or bunching even in the most extreme no-till or ridge-till applications.
Studies prove that mechanically stimulating hay, pasture or forage land is the most cost-effective method of dramatically improving the hardiness and productivity.
Scratching the surface covers open seed, assisting in germination and the establishment of new plants. Stimulating and spreading dead thatch assists in decomposition. This increases the speed at which nutrients are released into the area.
Solid or liquid manure makes the surrounding grass unpalatable for livestock. Treatment with the Delta Flexible harrow maximises the fertiliser benefits of existing droppings by encouraging decomposition, spreading nutrients, incorporating moisture, uncovering growth and aerating soil.
Additionally, rodent mounts are effectively levelled.
In combination with field cultivators, the Delta Flexible Harrow prepares a firm, level seed-bed or follows to pack and cover. Used alone it breaks up crust, ridges or stalks for minimum or no-till operations.
The various sizes of the Harrow make it ideal for mounting behind your disk, field cultivator or applicator for one-pass applications. Low, wet areas dry more quickly when aerated by the Delta Flexible Harrow.
Arenas or playing fields become smooth and loosely packed - meaning a safe surface for all activities.
Set the tynes to fill holes and level, or to loosen soil and aid drying. Gravel roads or dirt paths are quickly maintained, dried and raked.
Unmanaged turf becomes heavily thatched, preventing healthy growth from reaching its full potential. The delta harrow stimulates growth by surfacing the dead material, aerating the soil and strengthening the grasses.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

REM DELTA 4FT (MINI) FLEXIBLE HARROWS

Specifications:
Working width: 2800mm
Discs: 24
Weight: 2280kg
Features:
Hydraulic gang adjustment ( Separate ram for both gangs)
Manual levelling adjustment (Optional hydraulic)
12.5/80-15 PR14 tyres
Hydraulic drawbar offset (Optional manual)
660mm scollped discs
6mm thick disc blades
230mm disc spacing
8 bearings (double taper roller) GB280-320
12 bearings (double taper roller) GB370
Bearing protectors
40mm square shaft
150 x 100 x 8mm chassis and gang beam
Swivel hitch
Options:
Manual drawbar offset
Hydraulic levelling adjustment
Models:
GB280 2.8M 24 DISCS 2280kg
GB320 2.8M 28 DISCS 2550kg
GB370 2.8M 32 DISCS 2900kg
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

GB 2.8M, 24 DISCS (110-150HP) MEDIUM DUTY OFFSET DISCS

FTD 3000 Direct Drill is designed to improve your strike rate when sowing grasses, oats, and summer crops. This direct drill features a heavy-duty build that provides the necessary down pressure for direct drilling, ensuring that your seeds are planted at the desired depth for optimal germination.
The FTD 3000 Direct Drill boasts a range of features that make it standout among its competitors. It is front culters and bakerboot tines provide excellent soil tilth for seed germination.
Direct Drill your paddocks with Grasses or Summer Crops.
- Baker Boot Style Tines for Precise Seeding
- XL Hopper Capacity
- Hydraulic Front Coulters
- Easy Calibration System
- Optimal Row Spacing with 125mm (5 inch) Rows
- Double Shot System for Separate Seed and Fertilizer Placement
- Heavy-Duty Steel Frame and Independent Ground Drive Metering Systems
Design and Standard Features:
Baker Boot Style is a type of tine that is designed to provide precise seed placement and excellent tilth for seed germination. The boot style of the drill is specially designed to cut a furrow with minimal wear to the points, ensuring that it provides precise seed placement with every pass.
XL Hopper Capacity:
When it comes to choosing a seed drill, one of the most important factors is the hopper capacity. A larger hopper capacity means that you can cover more ground without having to stop and refill as often, saving you both time and energy. The FTD Tine Seed Drill Irtem boasts an XL hopper capacity, with a 1080L seed bin and a 700L fertiliser bin.
Easy Calibration:
The FTD tine seed drill, also known as the Easy Calibration Drill, is a game-changer when it comes to accurate and efficient seed placement. One of the standout features of this machine is its adjustable seed rollers and consistent ground-driven gearboxes, which allow for precise seed placement and an improved strike rate. In addition to its accuracy, the FTD tine seed drill is also incredibly user-friendly. The calibration process is fast and easy, taking less than 10 minutes in most cases. This means that you can spend more time planting and less time tinkering with the settings.
Double Shot System:
One of the highlights of the FTD Tine Seed Drill is its Double Shot System, which ensures that the seed and fertiliser are placed separately into the soil. This innovative feature effectively reduces the chance of seed burn, meaning your crops get the boost they need without being damaged by fertiliser.
Hydraulic Drawbar for safe transport
125mm (5 inch) Row Spacing:
The FTD Tine Seed Drill is an incredible machine that offers a wide range of features to help farmers achieve excellent results when sowing grasses, oats and summer crops. One of the key features that make this direct drill stand out is its 125mm (5-inch) row spacing. This precise row spacing is ideal for sowing grasses and oats, two crops that require careful placement of the seed.
Heavy Duty Steel Frame:
The FTD Tine Seed Drill is a heavy-duty steel-framed machine that is designed for efficient and effective direct drilling. Its sturdy construction provides the weight needed for direct drilling, making it a reliable choice for farmers.
2 Independent Ground Drive Metering Systems:
The Independent Ground Drive Metering System is a key feature of the FTD Tine Seed Drill. This innovative system consists of two side-by-side metering units, one for seed box and one for fertilizer, which are operated independently from each other. The system ensures consistent and accurate dosing of both seed and fertilizer.
Hydraulic Front Coulters:
The Hydraulic Front Coulters cut stubble and weeds allowing the tines to dig into the soil without build-up or blockages.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

IRTEM FTD3000 TINE SEED DRILL (3.0M)

2.56m Murray Series 03 Levelling Harrow 4 Rank Deep Sections & Standard Drawbar, Heavy Duty. Complete Set.
3602 - 2.56m (8ft 5in) 1/12 Tine, 2/16 Tine - 56kg.
Murray Levelling Harrows are an excellent choice to complement sowing or cultivation implements. Designed to level soil and seedbeds, the flexible frame design provides durability in all soil types. 3 and 4 rank versions are suitable for use to cover seed in light to medium soils in conjunction with combines and seed drills. The 5 rank model is used in heavier soils to counter weed growth and break down large clods. It is a popular implement that complements cultivators, scarifiers or chisel plows.
If you require additional weight to work your land, a Heavy version of our Series 03 Levelling Harrows is available. Made from heavier High Carbon Steel, the Tine Spacing remains the same as the standard version.
The Series 03 Levelling Harrow is available in either 3 or 4 row widths allowing extensions in increments of 235mm (9 ¼) to suit primary machines of almost any width. This allows a combination of harrow sections to be configured to suit your application.
A full range of standard and heavy duty drawbars are available to correctly match your soil conditions and available working width of your equipment. Harrow sets complete with drawbars range from 2.31m (77) to 5.58m (184) in width.
Specifications:
- Tine Spacing 76mm (3in).
- Tine Length 190mm (7 1/2in) approx.
- Centre to centre of Front Hooks 235mm (9 1/4in).
Features:
- High Carbon Cut Tines.
- Light models manufactured from 25 x 6mm carbon steel and Heavy models from 32 x 6mm.
* Murray Harrows must be pulled (towed) by a tractor correctly fitted with an approved rollover protection structure. Murray Harrows are NOT intended for use with an ATV or Ride On Lawn Mower.

All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

MURRAY SERIES 03 LEVELLING HARROW 2.56M, 4 RANK DEEP SECTIONS & STD DRAWBARS-HEAVY DUTY-COMPLETE SET

Find Tillage AND Seeding For Sale. Browse 970 Tillage AND Seeding listings from Farm Supplies Machinery & Equipment.

New & Used Tillage AND Seeding For Sale in Australia

Farm Supplies Machinery & Equipment

Sale Price

MURRAY SERIES 03 LEVELLING HARROW 5.58M, 4 RANK DEEP SECTIONS & STD DRAWBARS-LIGHT DUTY-COMPLETE SET

DAKEN SINGLE TINE RIPPER UP TO 100HP GALVANIZED - 86000DC

RLC 3M FIXED FRAMED LEAF SPRING RIPPERS (9 RIPPERS)

JOHN BERENDS TH100 HD TRAILING TANDEM DISCS - 28 PLATE X 26 INCH DISCS - 0960

RATA 9 LEG (AUTO RESET) SUBSOIL CULTIVATOR (150HP RECOMMENDED)

DAKEN DILLON PASTURE HARROW 8FT WIDE - GALVANISED DRAW BARS - 02100DC

SPAREX CONICAL HEAD BOLT 2 FLATS WITH NUT - 1/2" X 1 1/2"

CELLI 1.85M (80-110HP) ARES STONE BURIER

REM DELTA 4FT (MINI) FLEXIBLE HARROWS

GB 2.8M, 24 DISCS (110-150HP) MEDIUM DUTY OFFSET DISCS

IRTEM FTD3000 TINE SEED DRILL (3.0M)

MURRAY SERIES 03 LEVELLING HARROW 2.56M, 4 RANK DEEP SECTIONS & STD DRAWBARS-HEAVY DUTY-COMPLETE SET

Farm Supplies Machinery & Equipment

Dealer Address
