3PL 750L Fertilizer Spreader - Made in New Zealand.
The TPL750 boasts several features and is in a class of its own. Designed primarily for the application of Urea, it can also be used for spreading seed, granulated fertilisers and pelletized lime.
The huge 750 litre super thick plastic hopper can hold a 500kg bag of Urea with ease. That along with its heavy duty gearbox and stainless steel shutter plate, optional hydraulic shutter all housed in by the robust hot dip galvanised frame will give you a spreader that will last the test of time.
Capacity (750L) or (520kg)
Max Spread Width (18m Urea)
Dry Weight (180kg)
Loading Height (1,375mm)
Optional - Hydraulic actuator Control (see pictures)
Optional - Side Chute
Optional - 3PL Quick Hitch
Linkage arms are made of heavy steel plate that is more than adequate for the fertilisers hopper capacity. In keeping with the overall Vogal theme of overbuilding rather than under building.
This spreader features 3 spreading fins on the spinner disc. These fins are adjustable to enable fine adjustments to the spreading width and pattern.
A removable agitator that's secured onto the drive shaft via a linch pin provides an easy way of removing the agitator and to enable easy cleaning of the spreaders hopper base.
Includes a large heavy duty hopper with a PVC cover. The PVC cover is easily removed and refitted for loading as well as having high UV resistance.
All hoppers are made from thick heavy duty UV resistant plastic to cope with the harsh extremes in the Australian & New Zealand environments plus are internally braced with solid galvanised steel bars.
Dual triangular apertures enable the even spreading of a vast array of fertilisers and also grass seeds.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

RATA 750L 3PL FERTILIZER SPREADER

EX500 Spreader - Made in New Zealand.
The EX500 is the ultimate in ATV and quad bike tow-behind fertiliser spreaders. It features a double shutter plate to regulate the spread pattern to the left or right by altering the fertiliser drop position - this is a feature normally reserved for larger bulk spreaders.
The flagship of all ATV fertiliser spreaders - built tough.
Capacity (500L) or (360kg)
Max Spread Width (3m Mag) or (15m Urea)
Dry Weight (134kg)
Overall Width (1,800mm)
Loading Height (1,350mm)
Optional - 12v Shutter Control (see pictures)
Optional - Side Chute
Vogal EX500 spreaders feature the 'Easy Lock' drive system. This means drive engagement is by a handle at the front of the spreader which moves the slider to engage or disengage with minimal effort. Steel bash plates protect the drive slider
Includes a greaseable swivel tow coupling. Swivel tow couplings are ideal on undulating and hilly ground to allow the spreader to follow the terrain independently of the towing machine.
Features six fins on the spreading disc to ensure optimal spreading of both powdered products such as Causmag (Magnesium Oxide) and Lime flour along with standard pellet fertilisers.
Dual triangular apertures enable the even spreading of a vast array of fertilisers and also grass seeds.
A Removable agitator that's secured onto the drive shaft via a linch pin. The purpose is to provide an easy way of removing the agitator to enable easy cleaning of the spreaders hopper base.
A heavy duty galvanised frame with extensive gusseting and bracing to ensures high strength and durability for handling large loads of fertiliser on bumpy ground.
As with other sized EX series spreaders, the EX500 features an adjustable drawbar to keep the spinner disc level regardless of how high the vehicle tow ball is to ensure even spreading.
The drive line features extra support along the drive shaft/ drive line via two fully greasable and sealed bearings, this reduces load on the gearbox.
All controls and adjustments fare located at the front in and easy to use Index and Control box. This includes a quick reference guide for spreading rates and settings along with the aperture and spinner control levers.
Gearbox protection - stainless steel plates are bolted over the top and around the spinner shaft, between the plates and gear box is an oil soaked felt washer to prevent fertiliser dust getting in the gearbox.
Galvanised steel mudguards are included as standard on the EX500 fertiliser spreader. These mudguards are manufactured from plate steel for durability and galvanised for protection against corrosion.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

RATA 500L (EASY LOCK DRIVE) FERTILIZER & MAG TOW SPREADER (EX.500)

The Silvan Volumex range uses a patented design to accurately distribute granulated fertiliser, insecticides, herbicides and seeds.
The volumetric conveyor belt and calibrated metering adjustments ensure the product is applied at correct doses.
Each Volumex distributor permits fitment of two dropper hoses which direct the measured product exactly where it is required.
Features:
- The hopper is constructed from stainless steel and the distributor from non-corrosive polypropylene.
- Precision calibrated manual adjustment dial.
- Compact size allows easy attachment to many types of equipment.
Specifications:
Capacity = 100 L
Distributors / Outlets = 1 / 2
NOTE Mounting brackets and hoses not supplied with the Volumex.
NOTE 12 Volt drive motor is not supplied with Volumex Applicator. If required, please select from Option Listed below.
12V Motor Options:
- 12v Single Speed or Vari Speed Motor.
- MV-SS Micro Volumex Single Speed.
- MV-VS Micro Volumex Vari-Speed 3-20rpm.
- MV-VS2 Micro Volumex Vari-Speed 3-35rpm.
Dimensions:
Length: 730 mm
Width: 370 mm
Height: 580 mm
Distributor / Outlets: 1 / 2
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available
Contact Farm Supplies today for sale or more information
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN 100L VOLUMEX GRANULAR APPLICATOR (1 OR 2 DROPPERS) 12V MOTOR NOT INCLUDED

EX750 Spreader - Made in New Zealand.
The huge 750 litre thick moulded polyethene hopper has been designed to be used in conjuction with 500 kg bulk bags of Urea.
Packed with features such as 3 fin marine grade aluminium spinner discs complete with stainless steel fasteners and shutter plates. Plastic spinner shield to protect operator from debris and shield spinner from turbulence.
Easy lock drive engagement system and wide track width.
The EX750 is a cost effective solution to those who do not require the stability and low ground pressure features of the 'TT750' for soft &/or undulating ground.
Holding 500 kg bags of Urea with ease.
Capacity (750L) or (520kg)
Max Spread Width (15m Urea)
Dry Weight (152kg)
Overall Width (1,800mm)
Loading Height (1,500mm)
Optional - 12v Shutter Control (see pictures)
Optional - Side Chute
Vogal EX750 spreaders feature the 'Easy Lock' drive system. This means drive engagement is by a handle at the front of the spreader which moves the slider to engage or disengage with minimal effort. Steel bash plates protect the drive slider
Includes a greaseable swivel tow coupling. Swivel tow couplings are ideal on undulating and hilly ground to allow the spreader to follow the terrain independently of the towing machine.
Features six fins on the spreading disc to ensure optimal spreading of both powdered products such as Causmag (Magnesium Oxide) and Lime flour along with standard pellet fertilisers.
Dual triangular apertures enable the even spreading of a vast array of fertilisers and also grass seeds.
A Removable agitator that's secured onto the drive shaft via a linch pin. The purpose is to provide an easy way of removing the agitator to enable easy cleaning of the spreaders hopper base.
A heavy duty galvanised frame with extensive gusseting and bracing to ensures high strength and durability for handling large loads of fertiliser on bumpy ground.
As with other sized EX series spreaders, the EX750 features an adjustable drawbar to keep the spinner disc level regardless of how high the vehicle tow ball is to ensure even spreading.
The drive line features extra support along the drive shaft/ drive line via two fully greasable and sealed bearings, this reduces load on the gearbox.
All controls and adjustments fare located at the front in and easy to use Index and Control box. This includes a quick reference guide for spreading rates and settings along with the aperture and spinner control levers.
Gearbox protection - stainless steel plates are bolted over the top and around the spinner shaft, between the plates and gear box is an oil soaked felt washer to prevent fertiliser dust getting in the gearbox.
Galvanised steel mudguards are included as standard on the EX500 fertiliser spreader. These mudguards are manufactured from plate steel for durability and galvanised for protection against corrosion.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

RATA 750L (EASY LOCK DRIVE) FERTILIZER & MAG TOW SPREADER (EX.750)

11 Tonne Heavy duty multi spreader suitable to spread all types of dairy and feed pad waste. Ideal for contractors or large dairy operations.
Water tight construction.
Features:
Large 23.1 R 26 flotation tyres
Hydraulic brakes
LED lights
Wide angle driveshaft
Winding jack
Hydraulic door
Hardened reversible rotor tips
Reversible rotor
Stone trap
Dual shearbolt system
Heavy duty gearbox drive
Models:
AP 900 Capacity 9 Ton Height 2.46m
AP 1100 Capacity 11 Ton Height 2.6m
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

ABBEY 9M³ MULTI THROWING MUCK SPREADER

Product Specifications:
- 30Kg (Maximum) capacity, Poly UV Stabilised hopper
- Pneumatic wheels that provide improved grip and superior handling and balance all year round.
- Enhanced ground driven gearbox.
- Cushioned T on/off handle with solid rod linkage
- Powder coated frame with Parking stand.
- Spreads products from seed or micro granular to pelleted materials.
- Spreading width up to 4.5mtrs depending of product.
- 20 Adjustable settings to assist with accurate application rates & border control.
- Assembly & calibration instructions supplied.
Dimensions (Assembled) = Height 850mm x Width 510mm x Length 900mm
Dimensions (Unassembled) = Height 400mm x Width 600mm x Length 300mm
Weight = 7.5Kg
Warranty 12 months
Product overview: Where spreaders have consistently failed in the past is offering the ability to spread every type of Fertilizer or Grass seed with precision.
Products from 0.5mm up to 5.0mm can be used through this spreader.
Fertilizers come in all shapes, sizes, and weights. As a result, they fly off the impellor in different ways. This can cause more material to be spread to the right than to the left, or vice versa. To even the amount of material spread on both sides, adjustments must be made to the application holes on the bottom.
Our slider allows easy adjustment of the output holes.
Border control is achieved by pushing the border control slider across (as in the picture below), you can shut off one side of the spreader.
This helps save patio paths and flower borders from the spread of material where its not required.
The 20SW spreader has many other features including a powder
coated steel frame, pneumatic wheels for all year-round improved grip, an enhanced gearbox and solid rod throttle control.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN 30KG PUSH ALONG CRESCO SPREADER

The SuperVario is a premium, yet economical universal spreader driven by a 12V motor which makes it independent of other mechanisms such as the Kardan Drive or any Hydraulics system. This machine is available in three models and can be used to spread catch or cover crops, coated grass seeds, mouse bait, slug pellets, or even Silage Additives (depending on the configuration) which are two more functions compared to your average seeders.
The main difference among the three is their Hopper capacity which comes at 70L, 110L, and 170L depending on the model. SuperVario is equipped with the LAS 4 control to the width, spreading pattern, and dosage, as well as provide visual and aural error indicators. To maximize your investment, get the stainless steel frame for long lasting performance and the capability to handle Silage Additives without deterioration or corrosion.
Used primarily in agriculture. The main area of application for the SuperVario® is the spreading of:
- Cover crops
- Slug pellets
- Grass seeds for reseeding grassland
- Silage additive to prevent solidification in silo tanks
Features:
Stepless spreading width 2 - 24 metres
Robust 12-volt Bosch electric motor with 180 watts
Operation from driver's seat via the control panel
Visual and audible error message with two-lined display
Transparent supply hopper with 70, 110, or 170 litres
Standard power supply line with 4.0 mm² wire cross-section and 5 m length
10-time automatic control overdrive when the material in the hopper is excessively compressed.
Slide valves and spreading discs made of stainless steel
Stepless spreading volume adjustment from the driver's seat
Adjustable throwing vanes
Robust steel frame with mounting drill holes
Electric components waterproof (distribution box)
Digital start-up technology
Weight: 31 kg
6-meter-long cable from the spreader to tractor
Special agitator shaft for grasses
Hopper lid with quick-release fastener
Hopper with drainage opening/residue drainage
Spreading Widths:
The working width can be steplessly adjusted between 2 and 24 metres. The variable spreading width is achieved by steplessly controlling the SuperVario®'s spreading disk between 200 rpm and 3000 rpm from the comfort of the driver's cab. The control panel also comes as standard with various monitoring functions such as the empty indicator or automatic slider monitoring. The preparation for headland management (VGM) also comes as standard.
Slug pellets:
Steplessly adjustable from 3 to 24 m. With very finely-grained products, the ejector width may vary slightly, e.g. in the case of snail pellets.
Grasses:
The working width for lightweight grass seeds can be steplessly adjustable from 2 to 6 m. With heavy grass seeds (MG 500), a spreading width of up to 10 m is possible. This covers the most common working widths for smoothing, compacting, or harrowing. When spreading grass seeds, a special grass agitator is required, and this is supplied as standard.
Field mouse bait (Ratron):
In this case, the spreading width can be steplessly adjusted from 3 to 24 m. (Note - adhere to authorizations!)
As far as the spreading materials are concerned, the ejector vanes must be adjustable in a slotted hole. This allows the lateral distribution to be set with precision. Adhere to the indications in the spreading tables of the instructions manual or on the internet.
Note: The adjustment of the ejector vanes is only relevant to the lateral distribution. The spreading width is not altered by this.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

LEHNER 170L POWERAG SUPER VARIO ELECTRIC SPREADER

Vertical rear beater muck spreader with large capacity and robust construction. Ideal for agricultural contractors or large scale operations.
Specifications
Overall Length: 743cm
Unladen Weight: 5,100kg
Capacity: 12m³, 10ton
Features:
Vertical rear beaters
- ESP19 on RFC5012
- ESP21 on RF5517 & RF7322
Single axle (RFC5012 & RF5517)
Tandem fixed axle (RF7322)
Large flotation tyres:
- 620 75R 26 (RFC5012 & RF7322)
- 650 75R 32 (RF5517)
Slurry door with seal
2 x 16mm Marine chains
Demount bed slats
Electric in-cab controls
Sprung drawbar (RFC5012 & RF5517)
Hydraulic drawbar (RF7322)
Mudguards (RF5517 only)
Floor rotation indicator (RF5517 & RF7322 only)
Hydraulic jack
Wide angle driveshaft
Hydraulic brakes
Rear lights
Sandblasted, electroplated & powder coated
Bolted ring (RFC5012)
Swivel ring (RF5517 & RF7322)
Integrated hydraulic hoses
Front hose carrier
2-year warranty
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

ROLLAND 10 TONNE (12M3) ROLLFORCE VERTICAL MUCK SPREADER

The oscillating spreader is designed for precise application of fertiliser and seed at medium to low rates. The oscillating spout will apply product accurately from 5 to 14 metres depending on material being spread as well as left or right hand banding.
Spreader is supplied with spouts for banded spreading for either 3 metre or 7 metre wide rows. (Note: Banded spreading will still allow some product to spread in centre).
Construction: Heavy duty construction for long service life. The hopper is manufactured from non-corrosive UV stabilised impact resistant polyethylene. The frame is made of galvanised, high strength tubular steel. Spout formed from fibreglass reinforced nylon.
Driveline: Quality PTO driveshaft with approved safety cover. Continuous stroke flywheel with spring loaded drive coupling. Oscillating mechanism operates in oil bath for long service life.
Height Control: Single lever control for adjusting spreading volumes. Two spouts supplied for banding. Long agitator supplied as standard.
Specifications:
Market: Horticulture. Ag Lifestyle
Connection Type: Linkage
Product Weight (kg): 156
Height / Width / Length (mm): 1190 / 1510 / 1510
Capacity: 1000 L
Width of Throw : 6-14m
Options:
Hydraulic Control - 800 & 1000 litres models
Hopper Cover - 800 & 1000 litres models
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

SILVAN 1,000L SQTF OSCILLATING SPREADER

Cresco trailed spreaders are ideal if you are regularly spreading seed or fertiliser. Whether youre a professional landscaper or a home owner with a large garden, this trailed spreader offers a unique slide system that allows for a more uniform distribution of seed and granular materials. They are fitted with pneumatic wheels that provide improved grip in winter and superior handling and balance along with an enhanced gearbox for durability.
- 30kg capacity and travel speed of 6 km/hr (maximum), suitable for a ride on mower
- Pneumatic wheels that provide improved grip and superior handling and balance all year round
- Powder coated frame with tow hitch for a ride on mower
- Enhanced ground driven gearbox
- Cushioned T on/off handle with solid rod linkage
- Spreads products from seed or micro granular to pelleted materials (0.5mm to 5mm)
- Spreading width up to 4.5m depending on the product
- 20 adjustable settings to assist with accurate application rates & border control
- Easy assembly & calibration instructions supplied
- Optional rain cover product code CS-20SW-CR1050
# Important: The maximum tow speed is 6 km/hr. NEVER EXCEED the 6 km/hr speed as damage to the gearbox will occur #
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available
Contact Farm Supplies today for sale or more information
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

SILVAN 30KG CRESCO TOW SPREADER

The Silvan Volumex range uses a patented design to accurately distribute granulated fertiliser, insecticides, herbicides and seeds.
The volumetric conveyor belt and calibrated metering adjustments ensure the product is applied at correct doses.
Each Volumex distributor permits fitment of two dropper hoses which direct the measured product exactly where it is required.
Features:
- The hopper is constructed from stainless steel and the distributor from non-corrosive polypropylene.
- Precision calibrated manual adjustment dial.
- Compact size allows easy attachment to many types of equipment.
Specifications:
Capacity = 180 L
Distributors / Outlets = 3 / 6
NOTE Mounting brackets and hoses not supplied with the Volumex.
NOTE 12 Volt drive motor is not supplied with Volumex Applicator. If required, please select from Option Listed below.
12V Motor Options:
- 12v Single Speed or Vari Speed Motor.
- MV-SS Micro Single Speed.
- MV-VS Micro Vari-Speed 3-20rpm.
- MV-VS2 Micro Vari-Speed 3-35rpm.
Dimensions:
Length: 735 mm
Width: 510 mm
Height: 730 mm
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available
Contact Farm Supplies today for sale or more information
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN 180L VOLUMEX GRANULAR APPLICATOR (3-6 DROPPERS) 12V MOTOR NOT INCLUDED

Specifications:
Connection Type: Linkage
Weight: 104kg
Height / Width / Length (mm): 930 / 1100 / 1100
Capacity: 400L
Width of Throw: 6-14m
Key Features:
Construction: Heavy duty construction for long service life. The hopper is manufactured from non-corrosive UV stabilised impact resistant polyethylene. The frame is made of galvanised, high strength tubular steel. Spout formed from fibreglass reinforced nylon.
Drive Line: Quality PTO driveshaft with approved safety cover. Continuous stroke flywheel with spring loaded drive coupling. Oscillating mechanism operates in oil bath for long service life.
Height Control: Single lever control for adjusting spreading volumes. Two spouts supplied for banding. Long agitator supplied as standard.
The oscillating spreader is designed for precise application of fertiliser and seed at medium to low rates. The oscillating spout will apply product accurately from 5 to 14 metres depending on material being spread as well as left or right hand banding. Spreader is supplied with spouts for banded spreading for either 3 metre or 7 metre wide rows. (Note: Banded spreading will still allow some product to spread in centre)
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

SILVAN 400 LITRE OSCILLATING SPREADER -RON-SQTF400

Find Spreaders For Sale. Browse 105 Spreaders listings from Farm Supplies Machinery & Equipment.

New & Used Spreaders For Sale in Australia

Farm Supplies Machinery & Equipment

Sale Price

RATA 750L 3PL FERTILIZER SPREADER

RATA 500L (EASY LOCK DRIVE) FERTILIZER & MAG TOW SPREADER (EX.500)

SILVAN 100L VOLUMEX GRANULAR APPLICATOR (1 OR 2 DROPPERS) 12V MOTOR NOT INCLUDED

RATA 750L (EASY LOCK DRIVE) FERTILIZER & MAG TOW SPREADER (EX.750)

ABBEY 9M³ MULTI THROWING MUCK SPREADER

SILVAN 30KG PUSH ALONG CRESCO SPREADER

LEHNER 170L POWERAG SUPER VARIO ELECTRIC SPREADER

ROLLAND 10 TONNE (12M3) ROLLFORCE VERTICAL MUCK SPREADER

SILVAN 1,000L SQTF OSCILLATING SPREADER

SILVAN 30KG CRESCO TOW SPREADER

SILVAN 180L VOLUMEX GRANULAR APPLICATOR (3-6 DROPPERS) 12V MOTOR NOT INCLUDED

SILVAN 400 LITRE OSCILLATING SPREADER -RON-SQTF400

Farm Supplies Machinery & Equipment

Dealer Address
