Linkage 400 litre Slimline sprayer with 58 L/min pump, NO boom.
Specifications:
Market: Ag Lifestyle. Dairy & Livestock.
Tank Size (L): 400
Connection Type: Linkage
Pump Size (L/min): 58
Height / Width / Length (mm): 1310 / 740 / 1105
Product Weight (kg): 75
Application: Pasture and Ag Lifestyle spraying.
Features:
Pump: Silvan self-priming oil-backed diaphragm type with nitrile diaphragms and corrosion resistant, cast anodised aluminium body. BP20/15: 20L/min. capacity 1500kPa pressure. BP60/20: 58L/min. capacity 2000kPa pressure.
Controls: BP20/15: 2 outlet control valve with pressure regulation. BP60/20: 3 outlet control valve with pressure regulation.
Tank: Polytuff impact resistant polyethylene construction, moulded litre calibrations and non-spill screw-down lid with single breather.
Frame: Fully galvanised steel, cat. I & II linkage.
Agitation: Bypass agitation.
Pressure Gauge: 0-25 Bar dual stage glycerine filled gauge.
Filtration: Lid strainer, suction line strainer.
PTO Driveshaft: Quality driveshaft with quick release pins & safety cover.
Options:
- 6m Field boom
- 8m Field boom
- 8 Jet vine boom (Used with BP60/20 pump only)
- 10 Jet vine boom (Used with BP60/20 pump only)
- Undervine & mid row boom
- Boomless nozzle mounting kit (brass nozzle not included)
- 14L foam marker (single side)
- 16L foam marker (double side)
- Economy hosereel, 30m hose (12mm ID), PA spray gun & extension lance
- Electric on/off control-3 section (GOYEN solenoids)
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN 400L SLIMLINE LINKAGE SPRAYER - BP60/20 PUMP, NO BOOM

Specifications:
Market: Viticulture.
Tank Size = 2,000 L
Connection Type: Trailed
Rows = 3
Min PTO hp: 80
Pump Size : 500+ LPM
Application: Vineyards
Dimensions - Length measured with linkage hitch:
Length: 4,680 mm
Width Less Head: 1,800 mm
Width Folded: 2,490 mm
Height: 3,330 mm
Weight 990 kg (Dry)
Includes spray heads, independent 320mm hydraulic fans, hydraulic drive stainless steel pump, automatic spray rate controller, self contained hydraulic drive system and tandem suspension axle. Ideal for vineyards.
Model Specifications
- Head Two row spraying head: 28 venturi air shear adjustable nozzles with individual metering and on/off taps. Left and right arms are independent hydraulic folding with adjustable width and centre frame. Boom frame is galvanised.
- Pump Multi-stage hydraulic drive pump, multiple impellers made with highly resistant engineering plastic for excellent chemical compatibility. 500+L/min. Driven by tractor remotes.
- Fan Size 320mm turbine fan, one per air tube, 3600rpm. Power consumed 29kw/38HP.
- Hydraulic Control Hitch mounted hydraulic power pack with: 40L oil reservoir with cartridge particulate filter, motors fitted with case drain, hydraulic distribution block incorporates anti-cavitation and pressure relief valves, 12V oil cooler.
- Nozzles Air shear.
- Controls Electric section valves with Bravo 180S automatic rate controller. Large 100mm pressure gauge.
- Tank Polytuff impact resistant polyethylene construction, calibrated sight line, flip top easy open lid, 50mm camlock bottom fill and 40L fresh water hand wash tank.
- Frame Galvanised steel chassis, linkage hitch fitted with hydraulic power pack.
- Agitation Venturi agitator.
- Filtration Lid strainer and large capacity suction filter.
- Wheel Equipment Tandem suspension with 10x15inch wheels and tyres.
- PTO Driveshaft Quality Bondioli & Pavesi driveshaft with quick release pins and safety cover.
- HP Required Minimum 60 PTO HP
Factory Options
- Hydraulic pump driven through power pack.
- Hydraulic Height Adjustment phased or independent.
- Hydraulic Row width adjustment phased or independent.
- Bravo 180S spray rate controller with hydraulic controls (in lieu) up to 5 sections.
- Bravo 180S spray rate controller with hydraulic controls (in lieu) 7 sections.
- Bravo 400S automatic rate controller with GPS guidance (in lieu) 7 spray sections.
- Bravo 400S automatic rate controller with hydraulic controls, GPS guidance (in lieu) 7 spray sections + 7 hydraulic sections.
- IBX 100 ISOBUS controller (in lieu requires compatible in-cab console).
- Delta 80 Universal Terminal to suit ISOBUS control.
- Quick turning hitch.
- Electric braked tandem suspension axle via trailer plug in lieu of standard axle.
- Hydraulic braked tandem suspension axle in lieu requires compatible tractor remotes.
- 100L Flush Tank
- Road Kit Brake and indicator lights with folding Oversize sign.
- Tail Light Kit Brake and indicator lights via trailer plug.
NOTE: Not all options will fit all models. Extra charges may apply to fitment of some options.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN 2,000L (3 ROW) TRAILED SCRAM CROSS - MIN 80 PTO HP

Pressure Switch to suit DDP-552A Smoothflo pump - Max Pressure 120 psi
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

SILVAN PRESSURE SWITCH TO SUIT DDP-552A SMOOTHFLO

Powder coated upright hose reel. Ideal for spraying applications. Supplied with 30m of 10mm ID ag hose
Features:
Hose Reel free standing unit with brass hose swivel and hose connections.
Steel plate construction with rewind handle
PA Series Spray Gun
Max Pressure 2000 kPa / 290 psi
Supplied with 30 metres of 10mm ID ag hose
Specifications:
Height/Width/Depth 370mm / 350mm / 450mm
Product Weight 12 Kg
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

SILVAN HOSE REEL ECONOMY KIT - SILVAN - 180E03010C

Offers the advantages of low energy requirements, instant response and the ability to remain in an energised (open) state indefinitely without overheating or failing.
Suits 12-volt and 24-volt. 3/4 threaded inlet and outlet.
Max pressure = 8 Bar / 116 psi
Max flow Rate = 37 L/min
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN FOAM MARKER / SPRAYER SOLENOID

Feature continuous rolled thread with hex head for screwdriver or spanner tightening.
To fit Hose Size of 20mm (ID)
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

SILVAN 20MM HOSE CLAMP

Size = 3/4 "
Suits 19mm hose
Maintaining a leak free and smooth liquid flow by using quality components and fittings is essential for maximum performance from all installations.
Selectas range of fittings are manufactured from high quality polypropylene and are compatible with fungicides, herbicides, chemical fertilisers etc, and will withstand temperatures of up to 100ºC.
Standard BSP male and female threads can be used in conjunction with each other to construct assorted types and sizes of inlets, outlets, suction fittings and hose unions or they can be used with standard brass, galvanised and other fittings.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

SILVAN 3/4" ELBOW (SUIT 19MM HOSE)

Suction line filters provide filtration to remove larger particles of grit and are ideally mounted between the tank and pump. Featuring 8mm threaded brass inserts for easy adaptation to frames and chassis etc. Screw off bowl for easy cleaning.
Supplied with mesh elements and replacement elements are available.
Filter Type = SAR0
Mesh Size = 32
Flow Rate up to 60 L/min
Port Size = 1 1/4"
Mount inserts = 2
Width = 107mm
Height = 163mm
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

SILVAN G8072003 STAGE B SUCTION FILTER

- Suits 25L trolley sprayer SP25-TR3, 55L & 100L Redline sprayers
- Poly spray tube with flat fan spray nozzles
- 1m boom width, 1.5m spray swath
- Supplied with mounting & plumbing kit
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

SILVAN 3 NOZZLE 1M BOOM (1.5M SPRAY WIDTH) SUITS REDLINE SPRAYER)

For prevention of large particles or debris entering tank. Suits 355mm Lid.
OD = 300 mm
ID = 286 mm
Height = 254 mm
Mesh Size = 20
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

SILVAN 355 MM LID STRAINER

Hose I.D.: 19mm
Quality delivery hose for all diesel applications
(Available per meter).
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN 19MM I.D. DIESEL DELIVERY HOSE (AVAILABLE PER METER)

The Silvan Selecta Spotpak range is the ideal unit for use on an ATV or similar mobile vehicle for spot spraying, fenceline, row or general maintenance needs.
Designated as the Spotpak 12V Redline model; the Sprayer has a 100L capacity UV stabalised polyethlyene tank and is supplied as a self contained complete unit.
Features:
Spot Spray gun with 550mm stainless steel lance extension with adjustable cone nozzle.
6m of delivery hose.
3 metres of battery cable with alligator clips.
Lid with anti-spill breather with lid retaining ring to prevent accidental loss.
Chemical Measuring Jug 650ml (keeps safely beneath the lid).
5.3L/min open flow or 60psi (max).
U.V. Stabilized Poly-tuff Tank, with clip in holding points for spray gun and inserts.
Specifications:
Tank Size: 100 litres
Pump Size: 5.3 L/min
Height/Width/Depth: 435mm / 470mm / 885mm
Product Weight: 9 KG
Options:
TR100 Trailer Kit
TR55-10 Boomless Nozzle Kit
WP2-T - optional 2 jet T boom
TR55-13C - spray boom 3 nozzle kit
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN 100L REDLINE SPRAYER - 12V

Find Sprayers For Sale. Browse 700 Sprayers listings from Farm Supplies Machinery & Equipment.

New & Used Sprayers For Sale in Australia

Farm Supplies Machinery & Equipment

Sale Price

SILVAN 400L SLIMLINE LINKAGE SPRAYER - BP60/20 PUMP, NO BOOM

SILVAN 2,000L (3 ROW) TRAILED SCRAM CROSS - MIN 80 PTO HP

SILVAN PRESSURE SWITCH TO SUIT DDP-552A SMOOTHFLO

SILVAN HOSE REEL ECONOMY KIT - SILVAN - 180E03010C

SILVAN FOAM MARKER / SPRAYER SOLENOID

SILVAN 20MM HOSE CLAMP

SILVAN 3/4" ELBOW (SUIT 19MM HOSE)

SILVAN G8072003 STAGE B SUCTION FILTER

SILVAN 3 NOZZLE 1M BOOM (1.5M SPRAY WIDTH) SUITS REDLINE SPRAYER)

SILVAN 355 MM LID STRAINER

SILVAN 19MM I.D. DIESEL DELIVERY HOSE (AVAILABLE PER METER)

SILVAN 100L REDLINE SPRAYER - 12V

Farm Supplies Machinery & Equipment

Dealer Address
