Trailed air assist Stiletto 2000 litre sprayer with 161L/min diaphragm pump, electric controls, a Glideflex axle upgrade, wide angle shaft and a 900mm fan. Ideal for narrow vineyards and orchards. Additional model available with Bravo 180S automatic rate controller (DST23AB8G).
Specifications:
Market: Horticulture. Viticulture
Tank Size (L): 2000
Connection Type: Trailed
Min PTO HP: 60
Pump Size (L/min): 161
Height / Width / Length (mm): 1500 / 1540 / 3800
Product Weight (kg): 640 (dry)
Application: Vineyards and Orchards
Features:
Pump: Silvan oil-backed diaphragm type with nitrile diaphragms and corrosion resistant, cast anodised aluminium body with brass heads and manifolds. IDS1701: 161L/min. capacity 5000kPa pressure.
Fan Size: 900mm axial flow type, 10 bladed fan with curved nylon reinforced blades, air straightening vanes and protective mesh cover.
Nozzles: Flip-over type for dilute/concentrate spraying. Ceramic jets, stainless steel swirl-plates, 16 nozzles with twist on/off.
Gearbox: Oil-bath type, 2-speed with neutral position
Controls: 40 bar electric section valves, master valve, electric pressure regulator and in cab controls.
Tank: Polutuff impact resistant polyethylene construction, calibrated sight line, easy open lid, 40mm drain valve and built-in 15L fresh water tank.
Frame: Galvanised steel with jockey wheel & adjustable drawbar.
Agitation: Pump bypass plus venturi agitator
Pressure gauge: 100mm, 0-60 bar glycerine filled gauge.
Filtration: Lid strainer, suction line strainer & stainless steel nozzle filters.
Wheel Equipment: Glideflex suspension axle, 2x15" tubeless tyres on galvanised rims (max speed rating 30 km/h)
PTO Driveshaft: Quality Bondioli & Pavesi constant velocity driveshaft with quick release pins & safety cover.
HP Required: Min 60 PTO HP
Options:
- Twin nozzles (includes extra nozzles) (D99-182)
- Flotation tyres - 400/60 x 15.5" with fixed axle (in lieu of standard singles) (D99-80)
- Additional model available with Bravo 180S automatic rate controller (DST23AB8G).
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN 2,000L TRAILED STILETTO SPRAYER - MIN 60PTO HP

Silvan Quad Bike and Rakpak sprayers are designed to fit neatly on quad bikes and meet the strict weight requirement of these vehicles. The Wrap around design allows for a lower centre of gravity, essential for improved quad bike safety. UV stabilised polytuff tank.
Specifications:
Tank Size (L): 50
Pump Size (L/min): 5.3
Max pressure: 4 Bar / 60 psi
Product Weight (kg): 10
Height / Width / Length (mm): 250 / 850 / 775
Options:
M99-65 - boomless nozzle
RP1-24-3 - pressure regulator kit
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

SILVAN 50L QUAD BIKE SPRAYER

An adjustable shielded boom for spraying along fences, under tree lines and vine rows.
Features:
- boom with telescopic boom width adjustment from 2.3m to 3.2m total width
- spring loaded breakaways to protect the boom if an obstacle is struck
- durable boom shields to minimise spray drift and avoid snagging
- delivery hose, 1/2" (nut and tails to be ordered separately)
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

SILVAN 2.3M - 3.2M ADJUSTABLE DOUBLE SIDED UNDER VINE SHIELDED BOOM

Ideal for quick disconnection of spray guns from hose reels featuring liquid shut-off.
Manufactured from corrosion resistant materials. Provides instant liquid cut off when pistol is detached from spray hose.
- 1/2" BSP male with Female Coupling
- Max pressure 3,000 kPa / 435 psi
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

SILVAN BRASS HOSE SNAP COUPLING (FEMALE COUPLING ONLY)

12-Volt Smoothflo Spotpak 50L 7L/min Sprayer.
Combining the best features of our popular Spotpak range with the new constant flow technology.
Ideal for weed control, spot & fence line spraying applications, the Smoothflo series deliver constant flow, no pulsation and the highest pressure for distance spraying. Suitable for use on quad bikes, side by side utes, trays & trailers, with UV stabilised Polytuff tanks to ensure long life.
Specifications:
Tank Size: 50 litres
Pump Size: 7 L/min
Height/Width/Depth: 300mm / 400mm / 700mm
Product Weight: 6 KG
Features:
UV stabilised Polytuff tank suitable for agricultural chemical spraying.
7 L/min open flow (690 kPa/120 psi) Smoothflo Pump (DDP-552), Viton valves and Santoprene diaphragm ON/OFF Switch.
6 metres of 8mm delivery hose.
Quality Spotjet spray gun with adjustable spray nozzle.
3 metre wiring harness with in line fuse and alligator clips.
No pressure regulator required to deliver constant flow without pulsation.
Options:
474-196 - Brass 1/4" Female x 3/8" hose barb (2 required)
187-MH05 - SS hose clamp 6-16mm (2 required)
RP1-34 - boomless nozzle towbar boom
RP1-20 - 1.5m towbar boom
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

SILVAN 50L SMOOTHFLO SPOTPAK SPRAYERS - 12V

PSS30B 4 inch Adaptor
Suits Udder Gun.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

REGA UDDER GUN - PARTS - 4 INCH ADAPTOR - REGA - PSS30B

Trailed over row 2 row 3,000 litre turbowrap turbomiser sprayer with a hydraulic drive 350 L/min stainless steel pump, 500mm turbine fan, sprayheads, automatic spray rate controller, wide angle shaft and tandem suspension axle.
Ideal for vineyards. Note: pictured is 3,000L Tri-Wrap.
Specifications:
Market: Viticulture.
Tank Size (L): 3,000
Connection Type: Trailed
Min PTO hp: 75
Pump Size (L/min): 350
Height / Width / Length (mm): 3480 / 1755 (less head), 2576 (folded) / 4850
Product Weight (kg): 1,500 (dry)
Application: Vineyards
Features:
Head: Two row spraying head: 28 venturi air shear nozzles with individual metering and on/off taps. Three row spraying head: 42 venturi air shear adjustable nozzles with individual metering and on/off taps. Left & right arms have independent hydraulic folding with adjustable width & centre frame. Boom frame is fully galvanised.
Pump: Stainless steel, hydraulic drive centrifugal pump, 350 L/min. Stainless steel shaft and Viton/ceramic seal.
Fan Size: 500mm twin impeller turbine fan. Power cons. 48 kw/64HP.
Nozzles: Air shear.
Gearbox: 2-speed with neutral position, oil-bath type
Controls: Electric section valves with Bravo 180S automatic rate controller. Large 100mm pressure gauge.
Main Tank: Polytuff impact resistant polyethylene construction, calibrated sightline, flip top lid, 50mm camlock bottom fill, and hand wash tank. 205L flush tank on 3,000L.
Frame: Galvanised steel chassis, adjustable drawbar with jockey wheel.
Tank: Polytuff impact resistant polyethylene construction, calibrated sight line, flip top easy open lid, 50mm camlock bottom fill and 40L fresh water hand wash tank.
Chem Induction: Venturi suction probe.
Agitation: Venturi agitator.
Pressure Gauge: Glycerine filled gauge located on the valve bank.
Filtration: Suction line filter and pressure filter
Wheel Equipment: Tandem suspension axle with 10 x 15" tyres (3000L) or 11.5 x 15.3" tyres (4000L).
PTO Driveshaft: Quality Bondioli & Pavesi constant velocity (wide angle) driveshaft with quick release pins and safety cover.
HP Required: Minimum 75 PTO HP (2 row), Minimum 90 PTO HP (3 row).
Options:
- Quick turning hitch (D99-170)
- Hydraulic row width/height adjustment
- Bravo 180S spray rate controller with hydraulic controls (in lieu) (J99-180)
- Road kit (D99-151)
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN 3,000L (2 ROW) TRAILED TURBOWRAP - MIN 75PTO HP

Thread Size = 1/2 "
Suits 10mm tails
Maintaining a leak free and smooth liquid flow by using quality components and fittings is essential for maximum performance from all installations.
Selectas range of fittings are manufactured from high quality polypropylene and are compatible with fungicides, herbicides, chemical fertilisers etc, and will withstand temperatures of up to 100ºC.
Standard BSP male and female threads can be used in conjunction with each other to construct assorted types and sizes of inlets, outlets, suction fittings and hose unions or they can be used with standard brass, galvanised and other fittings.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

SILVAN 1/2" FLYNUT (SUIT 10MM TAILS)

Linkage 600 litre Super sprayer with 58 L/min pump, without boom. Ideal for spraying pasture and ag lifestyle use.
Specifications:
Market: Dairy & Livestock
Tank Size (L): 600
Connection Type: Linkage
Pump Size (L/min): 58
Height / Width / Length (mm): 1300 / 1150 / 1025
Product Weight (kg): 105
Application: Pasture spraying.
Features:
Pump: Silvan self-priming oil-backed diaphragm type with nitrile diaphragms and corrosion resistant, cast anodised aluminium body with raised pump mount. BP60/20: 58L/min. capacity 2000kPa pressure. BP130/20: 132 L/min. capacity 2000kPa pressure.
Controls: 3 outlet manual control valve with pressure regulator.
Tank: Low profile, 400 and 600L Polytuff impact resistant polyethylene construction, external
sightline with floating ball and non-spill offset screw-down lid with single breather. 15L freshwater tank with screw-down lid and on/off tap. 4L toolbox with polyethylene lid.
Frame: Galvanised steel with adjustable cat I & II hitch on 400L and cat II hitch on 600L. Vertical boom channel for positioning the boom at the optimum spray height.
Agitation: Bypass agitation.
Pressure Gauge: 0-25 Bar dual stage glycerine filled gauge.
Filtration: Lid strainer, suction line strainer with stop valve fitted at the side of the tank to enable ease of filter maintenance.
PTO Driveshaft: Quality driveshaft with quick release pins & safety cover.
Options:
- 6m Field boom
- 8m Field boom
- 10m Field boom
- 12m Fieldmaster boom with suspension (600L only)
- 6m Hydraulic fold boom
- 8m Devil boom with hydraulic fold
- 8 Jet vine boom
- 10 Jet vine boom
- Olive boom (Used with BP130/20 pump only)
- Undervine and mid row boom
- Boomless nozzle mounting kit (brass nozzle not included)
- 70L flush tank kit to flush the filter, spraylines and nozzles (600L only)
- 14L foam marker (single side)
- 16L foam marker (double side)
- 57L Paddock marker foam marker
- Economy hose reel, 20m hose (12mm ID) with Jetpro spray gun
- Reel tuff 12V remote reel with Turbo 400 spray gun (600L only) (inc. APS41 pump upgrade)
- Electric on/off control 3 section
- Electric control 3 section with in cab pressure adjustment
- Bravo 180S automatic rate controller
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN 600L SUPER SERIES LINKAGE SPRAYER - BP60/20 PUMP, NO BOOM

O.D = 1/2 "
Maintaining a leak free and smooth liquid flow by using quality components and fittings is essential for maximum performance from all installations.
Selectas range of fittings are manufactured from high quality polypropylene and are compatible with fungicides, herbicides, chemical fertilisers etc, and will withstand temperatures of up to 100ºC.
Standard BSP male and female threads can be used in conjunction with each other to construct assorted types and sizes of inlets, outlets, suction fittings and hose unions or they can be used with standard brass, galvanised and other fittings.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

SILVAN 1/2" O-RING (O.D)

Next generation trailed air assist 4,000 litre G2 sprayer with 161 L/min diaphragm pump, electric controls, a Glideflex axle upgrade, wide angle shaft, flush tank, chemical induction hopper and Powerhead conveyor with 920mm fan.
Ideal for orchards with trees up to 5 metres high.
Specifications:
Market: Horticulture
Tank Size (L): 4000
Connection Type: Trailed
Min PTO hp: 80
Pump Size (L/min): 161
Height / Width / Length (mm): 2020 / 1880 / 5550
Product Weight (kg): 1400
Application: Orchards.
Features:
Pump: Silvan oil-backed diaphragm type with nitrile diaphragms and corrosion resistant, cast aluminium body with brass heads and manifolds. IDS1701:161L/min. capacity, 5000kPa pressure.
Fan size: 920mm or 1000mm axial flow type,10 bladed fan with curved nylon reinforced blades, centrifugal clutch for soft engagement/ disengagement and protective mesh cover.
Nozzles: 24 flip-over nozzle bodies for dilute/concentrate spraying with on/off. 12 Ceramic hollow cone nozzles per side and 12 ceramic jets with stainless steel swirl plates per side. (16 per side with the Radak conveyor).
Gearbox: 2-speed with neutral position, oil-bath type
Control: 40 Bar electric section valves with master valve, electric pressure regulator and in cab controls.
Main Tank: Polytuff impact resistant polyethylene construction with calibrated sight line. 50mm Camlock top & bottom fill.
Flush Tank: 330L polytuff tank with top fill. Used to flush pump, filter, spray lines and nozzles.
Hand Wash Tank: 60L polytuff tank filled through cap. Tap located next to chemical mixer hopper.
Main Tank: Chemical mixer hopper with tap controls for rinse, transfer and main tank rinse. Venturi transfer back to main tank.
Frame: Galvanised steel with jockey wheel & adjustable drawbar.
Agitation: Pump bypass plus venturi agitator.
Pressure gauge: Glycerine filled gauge located on valve bank.
Filtration: Suction line filter, pressure filter, nozzle cup strainers.
Wheel Equipment: Glideflex axle with 13.0/65 - 18" implement tyres (speed rating 30km/h).
PTO Driveshaft: Quality Bondioli & Pavesi constant velocity driveshaft with quick release pins & safety cover.
HP Required: Minimum 80 PTO HP (920mm fan), minimum 90 PTO HP (1000mm fan).
Options:
- Hydraulic kit for Radak Conveyor (top wings)
- SCRAM Jet (to suit Radak conveyor)
- AVO Jet (to suit Radak conveyor)
- Leaf guard (to suit Powerhead & Radak)
- Double spray lines (Powerhead - includes upgrade to 1000mm fan)
- Double spray lines (Radak)
- Bravo 180S automatic rate controller
- Tandem suspension axle with 11.5/80 - 15.3 tyres
- Flotation tyres - 558-400/60 - 22.5 (in lieu of standard)
- IDS2001 pump, 182L/min. capacity, 5000kPa pressure
- IDS2600 pump, 249L/min. capacity, 5000kPa pressure
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN 4,000L SUPAFLO G2 SPRAYER WITH POWERHEAD FAN - MIN 80HP

Silvan 600L Linkage Turbomiser (GTM-P55DS) with optional Super Cannon Head (GT55D-1) included

Linkage Turbomiser 600 litre sprayer with a 140L/min centrifugal pump and a 550mm fan.  Ideal for vineyards, orchards and greenhouses.

SILVAN SILVAN - 600L LINKAGE TURBOMISER WITH SUPER CANNON HEAD - GTM-P55DS

Find Sprayers For Sale. Browse 693 Sprayers listings from Farm Supplies Machinery & Equipment.

New & Used Sprayers For Sale in Australia

Farm Supplies Machinery & Equipment

Sale Price

SILVAN 2,000L TRAILED STILETTO SPRAYER - MIN 60PTO HP

SILVAN 50L QUAD BIKE SPRAYER

SILVAN 2.3M - 3.2M ADJUSTABLE DOUBLE SIDED UNDER VINE SHIELDED BOOM

SILVAN BRASS HOSE SNAP COUPLING (FEMALE COUPLING ONLY)

SILVAN 50L SMOOTHFLO SPOTPAK SPRAYERS - 12V

REGA UDDER GUN - PARTS - 4 INCH ADAPTOR - REGA - PSS30B

SILVAN 3,000L (2 ROW) TRAILED TURBOWRAP - MIN 75PTO HP

SILVAN 1/2" FLYNUT (SUIT 10MM TAILS)

SILVAN 600L SUPER SERIES LINKAGE SPRAYER - BP60/20 PUMP, NO BOOM

SILVAN 1/2" O-RING (O.D)

SILVAN 4,000L SUPAFLO G2 SPRAYER WITH POWERHEAD FAN - MIN 80HP

SILVAN SILVAN - 600L LINKAGE TURBOMISER WITH SUPER CANNON HEAD - GTM-P55DS

Farm Supplies Machinery & Equipment

Dealer Address
