A versatile compact hose reel ideal for air, water and spraying applications. Ideal to use with 25L & 55L Redline sprayers.
- 10m of 8mm delivery hose & hose stop
- 1.5m inlet hose with ¼ BSP M connectors
- Swivelling steel mount bracket
- Spring rewind with multi position latching
- Ideal to use with 25L/55L Redline sprayers
- *Extra fittings required to connect hosereel to sprayer
Specifications:
Max pressure: 16 Bar / 240 psi
Product Weight (kg) : 4.1kg
Height / Width / Length (mm): 290 / 140 / 360
Hose: 10m of 8mm delivery hose & hose stop
Options:
474-190 - Brass 1/4" Female x 1/4" hose barb (2 required)
187-MH05 - SS hose clamp 6-16mm (2 required)
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN 10M SPRING RETRACTABLE HOSE REEL (SUITS 25L & 55L REDLINE SPRAYERS)

The Silvan Selecta Spotpak range is the ideal unit for use on an ATV or similar mobile vehicle for spot spraying, fenceline, row or general maintenance needs.
Designated as the Spotpak 12V Redline model; the Sprayer has a 100L capacity UV stabalised polyethlyene tank and is supplied as a self contained complete unit.
Features:
Spot Spray gun with 550mm stainless steel lance extension with adjustable cone nozzle.
6m of delivery hose.
3 metres of battery cable with alligator clips.
Lid with anti-spill breather with lid retaining ring to prevent accidental loss.
Chemical Measuring Jug 650ml (keeps safely beneath the lid).
5.3L/min open flow or 60psi (max).
U.V. Stabilized Poly-tuff Tank, with clip in holding points for spray gun and inserts.
Specifications:
Tank Size: 100 litres
Pump Size: 5.3 L/min
Height/Width/Depth: 435mm / 470mm / 885mm
Product Weight: 9 KG
Options:
TR100 Trailer Kit
TR55-10 Boomless Nozzle Kit
WP2-T - optional 2 jet T boom
TR55-13C - spray boom 3 nozzle kit
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN 100L REDLINE SPRAYER - 12V

Ideal where exact measurements are required.
Both standard and dual pressure gauges for high and low pressure readings.
Feature a nominal size 100mm gauge, clear lens, glycerine filled, 1/2" BSP male thread in either bottom or back entry models.
Features:
Entry type: back
Pressure limit: 0-60 Bar
Optimum operating pressure: 30 bar
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

SILVAN 100MM FACE, BACK ENTRY TYPE (0-60 BAR PRESSURE LIMIT) PRESSURE GAUGE

ID = 1/2 "
OD = 1 "
Maintaining a leak free and smooth liquid flow by using quality components and fittings is essential for maximum performance from all installations.
Selectas range of fittings are manufactured from high quality polypropylene and are compatible with fungicides, herbicides, chemical fertilisers etc, and will withstand temperatures of up to 100ºC.
Standard BSP male and female threads can be used in conjunction with each other to construct assorted types and sizes of inlets, outlets, suction fittings and hose unions or they can be used with standard brass, galvanised and other fittings.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

SILVAN 1/2" (ID) FLAT GASKET

Ideal for spraying applications when you are using UTV's or side by sides.
The Towbar Boomless nozzle can be easily attached when spraying around obstacles that could damage a traditional boom such as fences, guardrails and power poles.
Features:
- Up to 7.4M Spray Swath
- 7L/min required to operate
- Compatible with Hayman Reese style Towbar
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

SILVAN TOWBAR BOOMLESS NOZZLE

Linkage air assist Suntuff 400 litre sprayer with a 67 L/min diaphragm pump and 700mm fan. Ideal for smaller vineyards or orchards and smaller horsepower tractors.
Specifications:
Market: Viticulture. Horticulture
Tank Size (L): 400
Connection Type: Linkage
Min PTO HP: 20
Pump Size (L/min): 67
Height / Width / Length (mm):1200 / 1190 / 1330
Product Weight (kg): 134
Application: Vineyards and Orchards
Features:
Pump: Silvan oil-backed diaphragm type with nitrile diaphragms and corrosion resistant, cast anodised aluminium body. APS71: 67L/min. capacity 5000kPa pressure. APS96: 88L/min. capacity 5000kPa pressure.
Fan Size: Axial flow type, fan with curved nylon reinforced blades, galvanised cowling and protective mesh cover. 600mm with 8 blades on 200L unit. 700mm with 8 blades on 400L unit. 800mm with 10 blades on 500L unit
Nozzles: Flip-over type for dilute/concentrate spraying, ceramic jets, stainless steel swirl-plates. 200L unit: 10 single nozzles (5 per side) twist on/off. 400L unit: 12 flip over nozzles (6 per side) twist on/off. 500L unit: 14 flip over nozzles (7 per side) twist on/off.
Gearbox: Single-speed with neutral position, oil-bath type.
Controls: 3 outlet with pressure regulator. 400/500L models standard with extra length hoses - for tractor control mount.
Tank: Polytuff, impact resistant, polyethylene construction with litre calibrations, non-spill screw-down lid.
Frame: Galvanised steel, suit cat I & II linkage (200L cat I linkage only).
Agitation: 200L: bypass, 400L / 500L: dual bypass.
Pressure Gauge: Glycerine filled gauge, located on the control valve.
Filtration: Lid strainer, suction line strainer and stainless steel nozzle filters.
PTO Driveshaft: Quality driveshaft with quick release pins & safety cover.
HP Required: 200/400L: Minimum 20 PTO HP, 500L: Minimum 40 PTO HP.
Fitment Options:
- Two sided deflector (600mm fan size)
- Two sided deflector (700mm fan size)
- Two sided conveyor (700mm / 800mm fan size)
- Two sided deflector (800mm fan size)
- Bottom air deflectors (600mm / 700mm / 800mm fan size)
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN 400L SUNTUFF LINKAGE SPRAYER - MIN 20PTO HP

Linkage 600 litre Super sprayer with 58 L/min pump, without boom. Ideal for spraying pasture and ag lifestyle use.
Specifications:
Market: Dairy & Livestock
Tank Size (L): 600
Connection Type: Linkage
Pump Size (L/min): 58
Height / Width / Length (mm): 1300 / 1150 / 1025
Product Weight (kg): 105
Application: Pasture spraying.
Features:
Pump: Silvan self-priming oil-backed diaphragm type with nitrile diaphragms and corrosion resistant, cast anodised aluminium body with raised pump mount. BP60/20: 58L/min. capacity 2000kPa pressure. BP130/20: 132 L/min. capacity 2000kPa pressure.
Controls: 3 outlet manual control valve with pressure regulator.
Tank: Low profile, 400 and 600L Polytuff impact resistant polyethylene construction, external
sightline with floating ball and non-spill offset screw-down lid with single breather. 15L freshwater tank with screw-down lid and on/off tap. 4L toolbox with polyethylene lid.
Frame: Galvanised steel with adjustable cat I & II hitch on 400L and cat II hitch on 600L. Vertical boom channel for positioning the boom at the optimum spray height.
Agitation: Bypass agitation.
Pressure Gauge: 0-25 Bar dual stage glycerine filled gauge.
Filtration: Lid strainer, suction line strainer with stop valve fitted at the side of the tank to enable ease of filter maintenance.
PTO Driveshaft: Quality driveshaft with quick release pins & safety cover.
Options:
- 6m Field boom
- 8m Field boom
- 10m Field boom
- 12m Fieldmaster boom with suspension (600L only)
- 6m Hydraulic fold boom
- 8m Devil boom with hydraulic fold
- 8 Jet vine boom
- 10 Jet vine boom
- Olive boom (Used with BP130/20 pump only)
- Undervine and mid row boom
- Boomless nozzle mounting kit (brass nozzle not included)
- 70L flush tank kit to flush the filter, spraylines and nozzles (600L only)
- 14L foam marker (single side)
- 16L foam marker (double side)
- 57L Paddock marker foam marker
- Economy hose reel, 20m hose (12mm ID) with Jetpro spray gun
- Reel tuff 12V remote reel with Turbo 400 spray gun (600L only) (inc. APS41 pump upgrade)
- Electric on/off control 3 section
- Electric control 3 section with in cab pressure adjustment
- Bravo 180S automatic rate controller
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN 600L SUPER SERIES LINKAGE SPRAYER - BP60/20 PUMP, NO BOOM

3,000L Turbo Scram Trailed 2 Row Turbowrap: Includes sprayheads 4 x 320mm fans, Hydraulic drive stainless steel pump, automatic spray rate controller, self-contained hydraulic drive system, tandem suspension axle.
Specifications:
Market: Horticulture.
Tank Size (L): 3,000
Connection Type: Trailed
Min PTO HP: 65
Pump Size (L/min): 350
Height / Width / Length (mm): 3480 / 1755 (less head), 2576 (folded) / 4850
Product Weight (kg): 1,500 (dry)
Application: Vineyards
Features:
Head: Two row spraying head: 28 venturi air shear adjustable nozzles with individual metering and on/off taps. Three row spraying head: 42 venturi air shear adjustable nozzles with individual metering and on/off taps. Left & right arms are independent hydraulic folding with adjustable width & centre frame. Boom frame is galvanised.
Pump: Stainless steel, hydraulic drive centrifugal pump, 350 L/min. Stainless steel shaft and Viton/ceramic seal. Driven by tractor remotes.
Fan Size: 320 mm turbine fan, one per air tube, 3600 rpm. Power consumed 29 kw / 38HP
Hydraulic Control: Hitch mounted hydraulic power pack with; 40L oil reservoir with cartridge particulate filter, motors fitted with case drain, hydraulic distribution block incorporates anticavitation and pressure relief valves, 12V oil cooler
Nozzles: Air shear.
Controls: Electric section valves with Bravo 180S automatic rate controller. Large 100mm pressure gauge.
Frame: Galvanised steel chassis, linkage hitch fitted with hydraulic power pack
Tank: Polytuff impact resistant polyethylene construction, calibrated sight line, flip top easy open lid, 50mm camlock bottom fill and hand wash tank. (205L flush tank on 3000L)
Agitation: Venturi agitator.
Filtration: Lid strainer and large capacity suction filter.
Wheel Equipment: Tandem suspension axle with 10 x 15" tyres (3000L) or 11.5 x 15.3" tyres (4000L).
PTO Driveshaft: Quality Bondioli & Pavesi driveshaft with quick release pins and safety cover.
HP Required: Minimum 65 PTO HP (2 row), Minimum 80 PTO HP (3 row).
Options:
- Bravo 180S spray rate controller with hydraulic controls (in lieu) (J99-180)
- IBX 100 ISOBUS controller (in lieu - requires compatible in-cab console) (J99-181)
- Hydraulic row width/height adjustment
- Hydraulic pump driven through power pack (D99-185)
- 100L flush tank (to suit 4000L) (J99-112)
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN 3,000L (2 ROW) TRAILED TURBO SCRAM TURBOWRAP - MIN 65PTO HP

Linkage 300 litre Slimline sprayer with 58 L/min pump, no boom.
Specifications:
Market: Ag Lifestyle. Dairy & Livestock.
Tank Size (L): 300
Connection Type: Linkage
Pump Size (L/min): 58
Height / Width / Length (mm): 1070 / 740 / 1105
Product Weight (kg): 70
Application: Pasture and Ag Lifestyle spraying.
Features:
Pump: Silvan self-priming oil-backed diaphragm type with nitrile diaphragms and corrosion resistant, cast anodised aluminium body. BP20/15: 20L/min. capacity 1500kPa pressure. BP60/20: 58L/min. capacity 2000kPa pressure.
Controls: BP20/15: 2 outlet control valve with pressure regulation. BP60/20: 3 outlet control valve with pressure regulation.
Tank: Polytuff impact resistant polyethylene construction, moulded litre calibrations and non-spill screw-down lid with single breather.
Frame: Fully galvanised steel, cat. I & II linkage.
Agitation: Bypass agitation.
Pressure Gauge: 0-25 Bar dual stage glycerine filled gauge.
Filtration: Lid strainer, suction line strainer.
PTO Driveshaft: Quality driveshaft with quick release pins & safety cover.
Options:
- 6m Field boom
- 8m Field boom
- 8 Jet vine boom (Used with BP60/20 pump only)
- 10 Jet vine boom (Used with BP60/20 pump only)
- Undervine & mid row boom
- Boomless nozzle mounting kit (brass nozzle not included)
- 14L foam marker (single side)
- 16L foam marker (double side)
- Economy hosereel, 30m hose (12mm ID), PA spray gun & extension lance
- Electric on/off control-3 section (GOYEN solenoids)
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN 300L SLIMLINE LINKAGE SPRAYER - BP60/20 PUMP, NO BOOM

Specifications:
Market: Viticulture.
Tank Size = 3,400 L
Connection Type: Trailed
Min PTO hp: 60
Pump Size : 500+ LPM
Flush Tank = 205L
Application: Vineyards
Dimensions - Length measured with linkage hitch:
Length: 4,850 mm
Width Less Head: 1,755 mm
Width Folded: 2,576 mm
Height: 3,480 mm
Weight 1,500 kg (Dry)
Includes spray heads, independent 320mm hydraulic fans, hydraulic drive stainless steel pump, automatic spray rate controller, self contained hydraulic drive system and tandem suspension axle. Ideal for vineyards.
Model Specifications
- Head Two row spraying head: 28 venturi air shear adjustable nozzles with individual metering and on/off taps. Left and right arms are independent hydraulic folding with adjustable width and centre frame. Boom frame is galvanised.
- Pump Multi-stage hydraulic drive pump, multiple impellers made with highly resistant engineering plastic for excellent chemical compatibility. 500+L/min. Driven by tractor remotes.
- Fan Size 320mm turbine fan, one per air tube, 3600rpm. Power consumed 29kw/38HP.
- Hydraulic Control Hitch mounted hydraulic power pack with: 40L oil reservoir with cartridge particulate filter, motors fitted with case drain, hydraulic distribution block incorporates anti-cavitation and pressure relief valves, 12V oil cooler.
- Nozzles Air shear.
- Controls Electric section valves with Bravo 180S automatic rate controller. Large 100mm pressure gauge.
- Tank Polytuff impact resistant polyethylene construction, calibrated sight line, flip top easy open lid, 50mm camlock bottom fill and 40L fresh water hand wash tank.
- Frame Galvanised steel chassis, linkage hitch fitted with hydraulic power pack.
- Agitation Venturi agitator.
- Filtration Lid strainer and large capacity suction filter.
- Wheel Equipment Tandem suspension with 10x15inch wheels and tyres.
- PTO Driveshaft Quality Bondioli & Pavesi driveshaft with quick release pins and safety cover.
- HP Required Minimum 60 PTO HP
Factory Options
- Hydraulic pump driven through power pack.
- Hydraulic Height Adjustment phased or independent.
- Hydraulic Row width adjustment phased or independent.
- Bravo 180S spray rate controller with hydraulic controls (in lieu) up to 5 sections.
- Bravo 180S spray rate controller with hydraulic controls (in lieu) 7 sections.
- Bravo 400S automatic rate controller with GPS guidance (in lieu) 7 spray sections.
- Bravo 400S automatic rate controller with hydraulic controls, GPS guidance (in lieu) 7 spray sections + 7 hydraulic sections.
- IBX 100 ISOBUS controller (in lieu requires compatible in-cab console).
- Delta 80 Universal Terminal to suit ISOBUS control.
- Quick turning hitch.
- Electric braked tandem suspension axle via trailer plug in lieu of standard axle.
- Hydraulic braked tandem suspension axle in lieu requires compatible tractor remotes.
- 100L Flush Tank
- Road Kit Brake and indicator lights with folding Oversize sign.
- Tail Light Kit Brake and indicator lights via trailer plug.
NOTE: Not all options will fit all models. Extra charges may apply to fitment of some options.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available
Contact Farm Supplies today for sale or more information
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN 3,400L (2 ROW) TRAILED SCRAM CROSS - MIN 60PTO HP

Micro Pressure Switch to suit 382-168 pump - Max Pressure 60psi
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

SILVAN MICRO PRESSURE SWITCH TO SUIT 382-168

Suitable for air, water or agricultural chemicals. Ideal for Linkage Sprayers, 100L Redline sprayer and Smoothflo sprayers.
Can also be mounted on workshop wall.
- 15m of 10m delivery hose & hose stop
- 1m inlet hose with ¼ BSP M connectors
- Swivelling steel mount bracket
- Spring rewind with multi position latching
- Ideal to use with 100L Redline & Smoothflo sprayers
- *Extra fittings required to connect hosereel to sprayer
Specifications:
Max pressure: 20 Bar / 290 psi
Product Weight (kg): 7
Height / Width / Length (mm): 450 / 160 / 360
Hose: 15m of 10mm ID hose
Inlet Hose: 1.5m
Options:
474-196 - Brass 1/4" Female x 1/4" hose barb (2 required)
187-MH05 - SS hose clamp 6-16mm (2 required)
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

SILVAN 15M SPRING RETRACTABLE HOSE REEL

Find Sprayers For Sale. Browse 700 Sprayers listings from Farm Supplies Machinery & Equipment.

New & Used Sprayers For Sale in Australia

Farm Supplies Machinery & Equipment

Sale Price

SILVAN 10M SPRING RETRACTABLE HOSE REEL (SUITS 25L & 55L REDLINE SPRAYERS)

SILVAN 100L REDLINE SPRAYER - 12V

SILVAN 100MM FACE, BACK ENTRY TYPE (0-60 BAR PRESSURE LIMIT) PRESSURE GAUGE

SILVAN 1/2" (ID) FLAT GASKET

SILVAN TOWBAR BOOMLESS NOZZLE

SILVAN 400L SUNTUFF LINKAGE SPRAYER - MIN 20PTO HP

SILVAN 600L SUPER SERIES LINKAGE SPRAYER - BP60/20 PUMP, NO BOOM

SILVAN 3,000L (2 ROW) TRAILED TURBO SCRAM TURBOWRAP - MIN 65PTO HP

SILVAN 300L SLIMLINE LINKAGE SPRAYER - BP60/20 PUMP, NO BOOM

SILVAN 3,400L (2 ROW) TRAILED SCRAM CROSS - MIN 60PTO HP

SILVAN MICRO PRESSURE SWITCH TO SUIT 382-168

SILVAN 15M SPRING RETRACTABLE HOSE REEL

Farm Supplies Machinery & Equipment

Dealer Address
