Specifications:
Market: Viticulture.
Tank Size (L): 4,000
Connection Type: Trailed
Min PTO hp: 80
Pump Size (L/min): 500+
Height / Width / Length (mm): 3160 / 1935 (less head), 2490 (folded) / 5340
Product Weight (kg): 1,820 (dry)
Application: Vineyards
Features:
Head: Three row spraying head: 28 venturi air shear adjustable nozzles with individual metering and on/off taps. Three row spraying head: 42 venturi air shear adjustable nozzles with individual metering and on/off taps. Left & right arms are independent hydraulic folding with adjustable width & centre frame. Boom frame is galvanised.
Pump: Multi-stage hydraulic drive pump, multiple impellers made with highly resistant engineering plastic for excellent chemical compatibility. 500+ L/min. Driven by tractor remotes.
Fan Size: 320 mm turbine fan, one per air tube, 3600 rpm. Power consumed 29 kw / 38HP.
Hydraulic Control: Hitch mounted hydraulic power pack with; 40L oil reservoir with cartridge particulate filter, motors fitted with case drain, hydraulic distribution block incorporates anti-cavitation and pressure relief valves, 12V oil cooler
Nozzles: Air shear.
Controls: Electric section valves with Bravo 180S automatic rate controller. Large 100mm pressure gauge.
Frame: Galvanised steel chassis, linkage hitch fitted with hydraulic power pack
Tank: Polytuff impact resistant polyethylene construction, calibrated sight line, flip top easy open lid, 50mm camlock bottom fill and 40L fresh water hand wash tank.
Agitation: Venturi agitator.
Filtration: Lid strainer and large capacity suction filter.
Wheel Equipment: Tandem suspension axle with 10 x 15" tyres (1500L & 2000L) or 11.5 x 15.3" tyres (3500L).
PTO Driveshaft: Quality Bondioli & Pavesi driveshaft with quick release pins and safety cover.
HP Required: Minimum 60 PTO HP (2 row), Minimum 80 PTO HP (3 row).
Options:
- IDS2600 pump, 249L/min capacity, 5000kPa pressure D99-149
- Hydraulic pump driven through power pack D99-185
- Hydraulic Height Adjustment - Phased or Independent TGS-LIFT
- Hydraulic Row Width Adjustment - Phased or Independent D99-186
- Bravo 180S spray rate controller with hydraulic controls (in lieu) - Up to 5 sections J99-180
- Bravo 180S spray rate controller with hydraulic controls (in lieu) - 7 sections D99-196
- Bravo 400S automatic rate controller with GPS guidance (in lieu) - 7 spray sections J99-192
- Bravo 400S automatic rate controller with hydraulic controls, GPS guidance (in lieu) - 7 spray sections + 7 hydraulic sections D99-197
- IBX 100 ISOBUS controller (in lieu - requires compatible in-cab console) J99-181
- Detla 80 Universal Terminal to suit ISOBUS control 4675103
- Quick turning hitch D99-170
- Electric Braked Tandem Suspension Axle via Trailer plug - in lieu of std axle. D99-193
- Hydraulic Braked Tandem Suspension Axle - in lieu - requires compatible tractor remotes D99-194
- 100L Flush Tank - to suit 1500L, 2000L, 3500L & 4000L J99-112
- Road kit - Brake & Indicator lights with folding Oversize sign. D99-151
- Tail Light Kit - Brake & Indicator lights via trailer plug
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN 4,000L (3 ROW) TRAILED SCRAM CROSS - MIN 80 PTO HP

Linkage 600L Pasturepak sprayer with 58L/min pump, reel, hose & gun and 10m Field boom. Ideal for pasture spraying.
Specifications:
Tank Size = 600L
Connection Type = 3 Point Linkage
Pump Size = 58 LPM
Height / Width / Length = 1,350 / 2,067 / 1,300 (mm)
Product Weight = 180 kg (dry)
Features:
Pump: Silvan self-priming oil-backed diaphragm type with nitrile diaphragms and corrosion resistant, cast anodised aluminium body with raised pump mount. BP60/20: 58 L/min. capacity 2000kPa pressure. BP75/20: 71 L/min. capacity 2000kPa pressure.
Boom: Field boom with stainless steel spray lines, non-drip nozzle holders, fully galvanised frame, nozzle protection and spring loaded safety break back/forward.
Nozzles: Air induction nozzles with strainer in bayonet fit non-drip nozzle holders at 50cm spacings.
Controls: 3 outlet manual control valve with pressure regulator. Mounted forward for easy access.
Tank: Low profile, 400/600/800L polytuff impact resistant polyethylene construction, external sightline with floating ball and non-spill offset screw-down lid with single breather. 15L fresh water tank with screw down lid and on/off tap. 4L toolbox with polyethylene lid.
Frame: Fully galvanised steel, cat I & II linkage on 400L, cat II linkage on 600L and 800L.
Agitation: Bypass agitation.
Pressure Gauge: 0-25 Bar dual stage glycerine filled gauge.
Filtration: Lid strainer, suction line strainer and nozzle strainers.
Hose Reel: Fitted with rear-mounted Eco hosereel, 30m of 10mm hose and Spotjet spraygun with adjustable spray nozzle.
PTO Driveshaft: Quality driveshaft with quick release pins & safety cover.
Options:
- 14L foam marker (single side)
- 16L foam marker (double side)
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN 600L (10M BOOM) PASTUREPAK LINKAGE SPRAYER

The professional tool for convenience, ideal for contract spraying or farm. This reel can be used for roadside spraying, through undulating scrub, poultry sheds or glasshouses.
Optional Turbo 400 spray gun (401-26brqs) not included in this price
Heavy duty high torque direct drive gearbox and electric motor.
Galvanised steel construction for corrosion & scratch resistance
Long range remote system with automatic frequency hopping technology for interference-free use, 915 mhz
100 metres of 1/2" nylon tubing
Optional Turbo 400 spray gun 401-26brqs
Snap lock connectors for neat storage, ratcheting pin for transport keeps hose on the spool.
No belts, chains or sprockets to maintain
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN REEL TUFF 12V HEAVY DUTY 100M REMOTE REEL (147R10012)

Female Thread = 1 1/2" BSP
Thread Length = 15 mm
Maintaining a leak free and smooth liquid flow by using quality components and fittings is essential for maximum performance from all installations.
Selectas range of fittings are manufactured from high quality polypropylene and are compatible with fungicides, herbicides, chemical fertilisers etc, and will withstand temperatures of up to 100ºC.
Standard BSP male and female threads can be used in conjunction with each other to construct assorted types and sizes of inlets, outlets, suction fittings and hose unions or they can be used with standard brass, galvanised and other fittings.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN 1 1/2" BACK NUT (FEMALE)

Replacement nozzle & cap for M99-75B
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN REPLACEMENT NOZZLE AND CAP (FOR M99-75B)

Ideal where exact measurements are required.
1/8" BSP Male Thread
Rear Mount
0 - 6 Bar Scale
Liquid filled for accuracy
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN 1/8" GAUGE TO SUIT PRESSURE REGULATOR

Thread size = 3/4" BSP
Overall Length = 60 mm
Maintaining a leak free and smooth liquid flow by using quality components and fittings is essential for maximum performance from all installations.
Selectas range of fittings are manufactured from high quality polypropylene and are compatible with fungicides, herbicides, chemical fertilisers etc, and will withstand temperatures of up to 100ºC.
Standard BSP male and female threads can be used in conjunction with each other to construct assorted types and sizes of inlets, outlets, suction fittings and hose unions or they can be used with standard brass, galvanised and other fittings.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN 3/4" NIPPLE (60MM LENGTH)

3,000L Paddock Pak. BP130/20 pump, 3 section electric valve controls, 18m boom.
Specifications:
Tank Size (L): 3,000
Connection Type: Trailed
Pump Size (L/min): 132
Features:
Pump: Silvan self-priming oil backed diaphragm pump. BP130/20: 132 L/min. capacity 2000kPa pressure.
Boom: Hydraulic lift, fold and tilt with parallel arm boom suspension, nitrogen accumulator and spring-loaded breakbacks. Galvanised boom with stainless steel spraylines. Minimum 3 sets of hydraulic remotes required.
Controls: 3 section Silvamatic electric controls with pressure compensating direct acting valves. In cab on/off & pressure adjustment with pressure gauge.
Tank: Polytuff impact resistant polyethylene construction with calibrated sight line & non-spill screw down lid.
Flush Tank: 100L
Frame: Galvanised RHS steel construction with adjustable drawbar and operator platform.
Agitation: 2 stage agitation. Bypass action and Venturi agitation.
Filtration: Lid strainer, suction line filter.
Wheel Equipment: 2m track axle with 14.9 x 24" lug tyre
Bottom Fill: Bottom fill valve with camlock coupling.
Options:
- BP200/20 pump, 195 L/min. capacity, 2000kPa pressure
- Hydraulic drive centrifugal pump
- 5 section Silvamatic electric controls (in lieu)
- Bravo 180S automatic rate controller (in lieu)
- Bravo 180S automatic rate controller to suit hydraulic control (in lieu)
- Bravo 400S automatic rate controller with GPS guidance (in lieu)
- IBX 100 ISOBUS controller (in lieu - requires compatible in-cab console)
- Mudguards (to suit 14.9 x 24 wheels)
- Adjustable track axle (minimum 1500mm) with 11.2 x 44 Lug tyres (2500L only)
- 57L Paddock Foam Marker
- Venturi suction probe
- Silmix Chemical Hopper
- 3 Section electric over hydraulic control
- 5 Section electric over hydraulic control
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN 3,000L PADDOCK PAK TRAILED SPRAYER (18M BOOM)

Linkage 600 litre Casotti sprayer with 71 L/min pump and Casotti kit. Ideal for pasture spraying.
Specifications:
Market: Ag Lifestyle. Dairy & Livestock.
Tank Size (L): 600
Connection Type: Linkage
Pump Size (L/min): 71
Height / Width / Length (mm): 1300 / 1150 / 1025
Product Weight (kg): 105
Application: Pasture spraying
Features:
Pump: Silvan oil-backed diaphragm type with nitrile diaphragms and corrosion resistant, cast anodised aluminium body. APS71: 71L/min. capacity 5000kPa pressure.
Casotti Motor: An electric 12 volt motor is connected to the tractor battery which powers the oscillating movement of the nozzle arms. The arms swing 180º. This movement is symmetrical to the tractors passage.
Controls: 2 outlet brass manual control valve with pressure regulator. Mounted forward for easy access.
Tank: Low profile 600/800/1100L Polytuff impact resistant polyethylene construction, external sightline with floating ball and non-spill offset screw-down lid with single breather. 15L freshwater tank with screw-down lid and on/off tap. 4L toolbox with polythylene lid. 50mm Camlock bottom fill (1100L only).
Frame: Fully galvanised steel, cat II linkage.
Agitation: Bypass agitation.
Pressure Gauge: 0-60 Bar dual stage glycerine filled gauge.
Filtration: Lid strainer, suction line strainer with stop valve fitted at side of tank to enable ease of filter maintenance.
PTO Driveshaft: Quality driveshaft with quick release pins & safety cover.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN 600L CASOTTI LINKAGE SPRAYER

TV14 Spindle
Goes inside Trigger Valve on the Udder Gun.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

REGA UDDER GUN - PARTS - SPINDLE - REGA - TV14

Trailed over row G2E TGS 2 row 4000 litre sprayer with 182 L/min pump, 500mm twin turbine fan and electric valve controls. Ideal for vineyards.
Note: infield images show the 3 row 4000L G2E TGS.
Specifications:
Market: Viticulture.
Tank Size (L): 4,000
Connection Type: Trailed
Min PTO hp: 75
Pump Size (L/min): 182
Height / Width / Length (mm): 3160 / 1935 (less head), 2490 (folded) / 5340
Product Weight (kg): 1,820 (dry)
Application: Vineyards
Features:
Head: Multi row spraying head with air assist diffusers and twin spray nozzles. Each air diffuser features swivel adjustment and air deflector. Poly air tubes shaped to surround canopy. Both arms have independent hydraulic fold with manual width & height adjustment (2 tractor remote sets required).
Pump: Silvan oil-backed diaphragm type with nitrile diaphragms and corrosion resistant, cast anodised aluminium body with brass heads and manifolds. IDS1701: 161L/min. capacity 5000kPa pressure. IDS2001: 182L/min. capacity 5000kPa pressure.
Fan Size: 500mm twin impeller turbine fan, power consumed 48 kw (64HP).
Nozzles: Twin hollow cone ceramic nozzles per outlet with individual on/off non-drip taps.
Gearbox: 2-speed with neutral position, oil-bath type
Controls: 40 Bar electric section valves, master valve, electric pressure regulator and in cab controls
Frame: Galvanised steel chassis, adjustable drawbar with jockey wheel.
Tank: Polytuff impact resistant polyethylene construction, calibrated sight line, flip top easy open lid, 50mm camlock bottom fill and 40L fresh water hand wash tank.
Chem Induction: Suction probe with detachable hose.
Agitation: Pump bypass plus venturi agitator.
Pressure Gauge: 0-60 bar glycerine filled gauge fitted to pump.
Filtration: Lid strainer and large capacity suction filter.
Wheel Equipment: Tandem simplicity suspension with 10 x 15" wheels & tyres. (2000L & 3000L) or 11.5 x 15.3" wheels & tyres (3500L & 4000L)
PTO Driveshaft: Quality Bondioli & Pavesi driveshaft with quick release pins and safety cover.
HP Required: Minimum 75 PTO HP
Options:
- IDS2600 pump, 249L/min capacity, 5000kPa pressure (D99-149)
- Bravo 180S automatic rate controller (D99-143)
- Vertical lift head assembly (1 extra set of tractor remotes required) (TGS-LIFT)
- Quick turning hitch (D99-170)
- Hydraulic row width adjustment (1 extra set of tractor remotes required) (D99-186)
- Road kit (D99-151)
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN 4,000L (2 ROW) G2E TGS TRAILED SPRAYER - MIN 75PTO HP

1,600L Spray Pro, BP130/20 Pump, 18M Boom.
Specifications:
Tank Size (L): 1,600
Connection Type: Linkage
Pump Size (L/min): 132
Height / Width / Length (mm): 3410 / 2300 / 4100
Product Weight (kg): 1,335 (dry)
Features:
Pump: Silvan self-priming oil-backed diaphragm type with nitrile diaphragms and corrosion resistant, cast anodised aluminium body with raised pump mount. BP130/20: 132 L/min. capacity 2000kPa pressure.
Boom: Hydraulic lift, fold and tilt with parallel arm boom suspension, nitrogen accumulator and spring-loaded breakbacks. Galvanised boom with stainless steel spraylines. Minimum 3 sets of hydraulic remotes required.
Controls: 3 section Silvamatic electric controls with pressure compensating direct acting valves. On/off and pressure adjustment in cab.
Tank: 1600 and 1900L Polytuff impact resistant polyethylene construction, external sightline with floating ball and non-spill offset screw-down lid with single breather. 10L hand wash tank with screw-down lid and on/off tap. 150L flush tank with screw down lid and external sightline. 50mm Camlock bottom fill.
Frame: Galvanised steel, with adjustable cat II & cat III hitch. Vertical boom channel positions boom at optimum spray height.
Agitation: Bypass agitation.
Chemical Induction: 30L Silmix chemical hopper mounted on side of tank.
Pressure Gauge: 0-25 Bar dual stage glycerine filled gauge.
Filtration: Lid strainer, suction line strainer with stop valve fitted at the side of the tank to enable ease of filter maintenance
PTO Driveshaft: Quality driveshaft with quick release pins & safety cover.
Options:
- BP200/20 pump, 195 L/min. capacity, 2000kPa pressure (J99-82)
- Hydraulic drive centrifugal pump (J99-126)
- 57L Paddock marker foam marker (K99-43)
- Bravo 180S automatic rate controller (J99-146)
- Bravo 180S automatic rate controller to suit hydraulic control (in lieu) (J99-184)
- Bravo 400S automatic rate controller with GPS guidance (in lieu) (J99-182)
- IBX 100 ISOBUS controller (in lieu - requires compatible in-cab console) (J99-185)
- 3 Section electric over hydraulic control (J99-117)
- 5 Section electric over hydraulic control (J99-143)
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN 1,600L SPRAY PRO SPRAYER - BP130/20 PUMP, 18M BOOM

Find Sprayers For Sale. Browse 693 Sprayers listings from Farm Supplies Machinery & Equipment.

New & Used Sprayers For Sale in Australia

Farm Supplies Machinery & Equipment

Sale Price

SILVAN 4,000L (3 ROW) TRAILED SCRAM CROSS - MIN 80 PTO HP

SILVAN 600L (10M BOOM) PASTUREPAK LINKAGE SPRAYER

SILVAN REEL TUFF 12V HEAVY DUTY 100M REMOTE REEL (147R10012)

SILVAN 1 1/2" BACK NUT (FEMALE)

SILVAN REPLACEMENT NOZZLE AND CAP (FOR M99-75B)

SILVAN 1/8" GAUGE TO SUIT PRESSURE REGULATOR

SILVAN 3/4" NIPPLE (60MM LENGTH)

SILVAN 3,000L PADDOCK PAK TRAILED SPRAYER (18M BOOM)

SILVAN 600L CASOTTI LINKAGE SPRAYER

REGA UDDER GUN - PARTS - SPINDLE - REGA - TV14

SILVAN 4,000L (2 ROW) G2E TGS TRAILED SPRAYER - MIN 75PTO HP

SILVAN 1,600L SPRAY PRO SPRAYER - BP130/20 PUMP, 18M BOOM

Farm Supplies Machinery & Equipment

Dealer Address
