Tubeline Bale Wrapper TL1700SR
Hydraulically powered, the TL1700SR can easily switch between round and square bales by moving the secondary drive shaft on either of the appropriate stub shafts. Each stub shaft changes the drive ratio to provide the appropriate advancement of the bale. When the carrier arm is placed in the wrapping position, the carrier can be raised or lowered, centering the wrap on the bale to provide even plastic coverage throughout the wrapping process. The TL1700SR is also equipped with Tubelines Offset Twin Wrap Kit which laminates two layers together to form a stronger 2-ply layer of plastic. The offset provides up to a 4 lead increasing the amount of overlap for greater protection.
The wrappers integrated bale mat protects the wrapped bale from being punctured as it is dumped, while the bale bumper ensures the bale lands far enough away from the wrapper so the table can rotate while the next bale is started. After dumping the bale, one of the two integrated knives easily slices through the plastic wrap. An easy to use wrap counter allows you to set the desired number of rotations of wrap per bale and displays the current rotation.
Specifications:
Bale Size (Round): 4ft x 4ft (121cm x 121cm) to 5ft x 5ft 6in (152cm x 167cm)
Bale Size (Square): 3ft High x 3ft Wide Bales up to 7ft Long (91cm High x 91cm Wide Bales up to 213cm Long)
Film Width: 30in (x2) 76.2cm (x2)
Length: 192in (488cm)
Width: 82in (208cm)
Height: 95in (241cm)
Weight: 2,865 lbs. (1300kgs)
HP Required: 13 HP
hitch: Trailer (Clevis)
Drive Type: Hydraulic
Bale Guides: 2
Offset Twin Wrap: Standard
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

TUBELINE ROUND & SQUARE BALE WRAPPER - TL1700SR

Suitable for raking, turning and spreading hay crops, grain crops, stubble and sugar cane debris.
Construction: Simple robust construction requiring minimal maintenance.
Drive Line: Ground drive.
Control: Tractor three point linkage and adjustment of individual rake finger wheels.
Attachment: Cat. I three point linkage.
Specifications:
Type: Right Hand Linkage Mounted
Working Width (mm): 3500
Product Weight (kg): 200
Number of rake wheels : 5
Tynes Per Wheel : 40
Rake wheel diameter : 1400mm
Transport width : 2.3m
Note: Hayrakes Delivered Unassembled
* Maximum working width and speeds depend greatly upon product raked, volume and general conditions.

All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SITREX RP LINKAGE HAYRAKES - 5 RAKE WHEELS - SITREX - HR-RP5

Product of Canada, The TL1000R is a valuable addition to any hay producers arsenal. Easy to maintain and even easier to use, the TL1000R uses tractor hydraulics to spin and rotate the bale ensuring its completely wrapped every time.
To keep 4ft and 5ft bales centred the TL1000R is equipped with adjustable bale guides. It also features a wrap counter to ensure you get the right amount of wraps on each bale.
Add some value to your operation with a new Individual Bale Wrapper from Tubeline.
TL1000R Specifications:
Bale Size: 4ft x 4ft to 5ft x 5ft 6in
Film Width: 30in
Length: 104in
Width: 80in
Height: 84in
Weight: 1,600 lbs.
HP Required: 30 HP
Three Point Hitch: Category II
Drive Type: Hydraulic
Bale Guides: Adjustable (4ft or 5ft)
Operational Video: https://youtu.be/B78qiiijnU0
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

TUBELINE ROUND BALE WRAPPER

With its accurate tracking ability thanks to a new innovative QuattroLink suspension and a highly flexible working range, this mower provides unrivalled cutting performance.
Like a race car you want better tracking, ability to go at faster speed and adjust instantly to changing field conditions when operating your mower conditioner. (see pictures for examples)
These are the main benefits you will experience when running the 736T Vicon Mower.
Min 120hp required.
The Advantages:
- 3.18 and 3.50m working width.
- New innovative QuattroLink suspension concept.
- Flexible suspension 700mm movements, 400mm upwards and 300mm downwards.
- Hydraulic setting of ground pressure.
- NonStop BreakAway protection across full working width.
- 150mm mechanical adjustment of overlap.
- Minimum 500mm ground clearance during headland turns.
- Dual adjustment of conditioner hood - both front and rear end can be adjusted.
- Integrated parking feet for vertical storage.
- Vertical Transport Solution.
- Counter-rotating triangular discs
The 736T comes with a host of smart features that allow you to get the job done faster, smoother and more efficiently. When theres work to be done, you need a mower conditioner that is easily customised to the exact conditions facing you today.
Setting the conditioning intensity to crop density and conditions, changing between swathing and widespreading and checking discs and knives is done easily and quickly, taking the hassle out of the daily work optimisation.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

VICON 3.5M VICON 736T EXTRA MOWER CONDITIONER (QUATTROLINK)

Burder feedout wagon is built to be rust resistant ensuring that they will last. The independent rear suspension provides a smooth ride when trailing and reduces stress through the frame from shock loadings. It comes with a bi-directional high torque motor and it allows the feeder to feed from either side.

The large track width combined with its low centre of gravity ensures that you have a piece of mind when venturing onto undulating terrain. All Burder feedout wagons are finished with 2 pack epoxy paint which is much stronger than normal paint thus keeping the machine looking its best longer. The feedout extensions enables the feeder to throw out the shredded bale out beyond the track of the wheels, ensuring the cleanest feed for stock.

BURDER 1,200KG (520CM X 230CM X 120CM) FEEDOUT WAGON

Models:
3PBS-2 1,000kg 44kg 25HP Black Powder Coat
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

FIELDQUIP 3PL BALE SPEAR CAT 1 AND 2 - 3PBS-2

Suitable for raking, turning and spreading hay crops, grain crops, stubble and sugar cane debris.
Construction: Simple robust construction requiring minimal maintenance.
Drive Line: Ground drive.
Control: Tractor three point linkage and adjustment of individual rake finger wheels.
Attachment: Cat. I three point linkage.
Specifications:
Type: Right Hand Linkage Mounted
Working Width (mm): 4100
Product Weight (kg): 250
Number of rake wheels : 6
Tynes Per Wheel : 40
Rake wheel diameter : 1400mm
Transport width : 2.3m
Note: Hayrakes Delivered Unassembled
* Maximum working width and speeds depend greatly upon product raked, volume and general conditions.

All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SITREX RP LINKAGE HAYRAKES - 6 RAKE WHEELS - SITREX - HR-RP6

Portable Hay Moisture Tester specifications shown in images.
Technical Information:
https://22df4504011deb964a17-39bee0485bf754a0e77a8d4deb668d89.ssl.cf4.rackcdn.com/product_data/au/28717_en_is.pdf
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SPAREX PORTABLE HAY MOISTURE TESTER (24" PROBE)

The most complete universal Haymaker for crops. Excellent job in spreading, tedding or windrowing. High rate performance, very simple operation and study construction.
All these qualities can be found in the Haymaker 300.
The Haymaker 300 is fitted with wide tyres in order to improve ground adherence and obtain a better performance on rough terrains.
Tines are positioned by centrifugal force and float at forage cut level to collect the whole crop.
Spreading and tedding: evenly moving and spreading of hay.
Raking at high working speeds you will get a soft and loose swath and a precise windrow separation. Adjustable deflectors: to prevent losses on terrain boundaries.
Specifications:
Working Width: 3m
Transport Width: 2.3m
Weight: 330kg
Features:
Application: Suitable for tedding, windrowing and spreading hay crops.
Construction: Simple robust construction requiring minimal maintenance.
Drive Line: PTO drive at 540rpm (min. 20HP required).
Control: Tractor three point linkage.
Ground Wheels: 2 x 15/6.00
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

SITREX 3M TEDDER RAKE (MIN 20HP)

- Working width = 7.8m
- Weight = 2,065kg
- Swath Width = 1.2m - 2.2m
- Transport width = 2.8m
- Capacity = 8.8 Ha/hr or 21.74 Acres/hr (in theory)
- Compact Line maintenance-friendly gearbox.
- Hydraulic adjustable working width.
- Active wheel steering with 80° turning angle for easy manoeuvrability
The Andex 804 excels both with its extensive working width and compact transport dimensions. The new design of the wheel axles allows for the addition of generous 380/55 wheels as standard, whilst still offering a narrow outer track width, making it the perfect match for narrow roads and tight gateways.
Transport height is below 4.00m, even with all tine arms attached. No need to leave the tractor, just fold and go.
Add in the 80° turning headstock and active wheel steering, and you have a highly manoeuvrable machine both on the road and in the field.
The 804 heavy-duty two-rotor rake are designed for the toughest conditions and feature a high-performance oil-bath gearbox and a strong carrier frame. The hydraulically adjustable working and swath width with the ability to make sharp turns of up to 80°, are important features of these rakes.
Newly designed wheel axles provide a transport height below 4m, even with tine arms mounted.
On-the-Go Rotor Height Adjustment.
A Comfort Kit is optionally available for the 804 model. This includes a handheld joystick control, where the height of each rotor is controlled electronically and shown on the screen of the control box.
The ProLine rakes feature a unique drive system which comprises oil-immersed pinion and crown wheels. The fully enclosed design ensures full and permanent lubrication, and makes the entire system absolutely maintenance-free.
The hardened cam track is adjustable, and features a flat curve and an extremely large 400 mm diameter, providing positive guidance to the steel rollers, and promoting quiet machine running.
Aluminium bearing housings, with two integral ball bearings and wide support, provide solid and maintenance-free tine arm mounting.
The centre swath rakes offer hydraulic adjustable working width. This enables varying swath width, ensuring a perfect match to the pick-up width of loader wagons, balers and foragers.
Vicon rotary rakes are designed to do well-shaped and clean swaths, achieved with precision in every part of the raking.
The ability to follow ground contours is important to avoid dirt in the swath - especially in uneven field conditions.
The TerraLink Quattro system controls the rotor in 3 dimensions, with a unique combination of an undercarriage with 4 wheels and a specially designed rotor suspension system. This ensures superb raking performance, even at higher forward speeds.
Maintenance-free system - no pivots or joints to wear out.
Automatic rotor suspension, ensuring smooth operation.
Built-in pressure bias on front wheels prevents lifting and tine bounce.
Optimal ground following for clean raking at high forward speeds. All wheels are positioned close to the tines.
The rear carrier frame with controlled steering facility allows tight turns on headlands and loss free swathing, even in awkwardly shaped fields.
Even if the rotors are lifted on a steep slope, the steering system reliably counteracts any deviation.
The ability to make sharp turns up to 80° and the cross stabilizer in the headstock are unique Vicon features.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

VICON 7.8M TWIN ROTOR RAKE (CENTRE DELIVERY)

2.42m 3PL Disc Mower
Features
VI Extra 124
Cutting Width 2.4m
Transport Hydraulically folds into vertical position behind tractor
Transport width 1.2m
Cutter bar - fully welded oil bath with top serviceable hubs
Number of discs 6
Number of blades 18
Pro fit blades N/A
PTO Speed 540 (6-spline 1-3/8)
Transmission 4-V-belts to right angle gearbox
PTO Shaft with freewheel Standard
Disc RPM 3000
Cutting speed (kph) 6-15
Blade type Twisted low horse power
Cutting height (mm) (With optional skids fitted) 20-50 (50-100 with 40mm skids, +100mm with 80mm skids)
Suspension Spring
Lift type Hydraulic via single acting remote
RH Swath Board Standard
RH High Cone Standard
Drive train Spur Gear
MIn PTO HP req = 34kw/46HP
Linkage 3 Point Linkage
Weight 450kg
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

VICON 3PL DISC MOWERS 2.4M - VI EXTRA 124, MIN 46HP

Suitable for raking, turning and spreading hay crops and grain crop stubble.
Construction: Simple robust construction requiring minimal maintenance.
Drive line: Ground drive.
Control: Single set hydraulics via tractor remote.
Attachment: Cat. II clevis to tractor drawbar.
Specifications:
Type: Inline Trailed
Working Width (m): 5.5
Product Weight (kg): 815
Number of rake wheels: 9
Tynes Per Wheel: 40
Rake wheel diameter: 1400mm
Transport width : 3.7m
Note: Hayrakes Delivered Unassembled
* Maximum working width and speeds depend greatly upon product raked, volume and general conditions.

All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

SITREX TR INLINE TRAILED HAYRAKES - 9 RAKE WHEELS - SITREX - HR-TR9

Find HAY Tools For Sale from Farm Supplies Machinery & Equipment.

New & Used HAY Tools For Sale in Australia

Farm Supplies Machinery & Equipment

Sale Price

TUBELINE ROUND & SQUARE BALE WRAPPER - TL1700SR

SITREX RP LINKAGE HAYRAKES - 5 RAKE WHEELS - SITREX - HR-RP5

TUBELINE ROUND BALE WRAPPER

VICON 3.5M VICON 736T EXTRA MOWER CONDITIONER (QUATTROLINK)

BURDER 1,200KG (520CM X 230CM X 120CM) FEEDOUT WAGON

FIELDQUIP 3PL BALE SPEAR CAT 1 AND 2 - 3PBS-2

SITREX RP LINKAGE HAYRAKES - 6 RAKE WHEELS - SITREX - HR-RP6

SPAREX PORTABLE HAY MOISTURE TESTER (24" PROBE)

SITREX 3M TEDDER RAKE (MIN 20HP)

VICON 7.8M TWIN ROTOR RAKE (CENTRE DELIVERY)

VICON 3PL DISC MOWERS 2.4M - VI EXTRA 124, MIN 46HP

SITREX TR INLINE TRAILED HAYRAKES - 9 RAKE WHEELS - SITREX - HR-TR9

Farm Supplies Machinery & Equipment

Dealer Address
