The rigid chisel plough is used in a similar fashion to the stump jump as a primary cultivator.
The rigid tine is harder to pull as it has not got the jack hammering effect of the stump jump tine. It should also be used in country which is known to be clean, as the tine is clamped onto the frame and will only shear the clamp bolts under load.
The tines are extremely strong for this reason, using the same tines as the stump jump plough. The machine is ideal for lighter sandy soils where penetration and draft are not a problem.
Features:
9 Tines at 12 adjustable spacings.
Heavy duty 100x100x6mm frame.
Overall width of the machine is 9 wider than the cut width ie 5 tine is 5 9, 7 tine is 79 and so on.
Cat 1 & 2 Linkage.
65mm Reversible Points as standard.
Silicone chrome spring steel shanks.
Available in 5, 7, 9 and 11 tine sizes with tines at 12 adjustable spacings.
Horsepower requirements vary widely but 10 HP per tine is a rough guide.
Excellent underframe trash clearance of 520mm.
Adjustable spring is designed to give a longer, more progressive action, actually chiselling as the machine moves through the ground.
The wheel kit consists of a pair of 14 Holden wheels, height adjustable, fitted on the outside of the machine (increasing the overall width approx 450mm (18).
Options:
0200 Depth Wheels (Pair Holden)
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

JOHN BERENDS RIGID TINE CHISEL PLOUGHS 9'9" (2.9M) - 0184

Features:
- Single bidirectional rotation reel arm
- Generous tyne spacing's for clean rock removal
- High torque motor and pressure relief valve
- Rock solid European build
- Includes mount, hoses and couplings
- Single bidirectional arm
- Up to 1000 kg load Capacity
- Optimal rock size: 100 - 500 mm
Specifications:
Suits: 40 - 140 hp
Oil Flow required = 45 - 70 LPM
Volume = 0.75 m3
Tyne Spacing's = 70 mm
Working Width = 2,000 mm
Weight = 560 kg
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available.
Contact Farm Supplies today for sale or more information.
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

HIMAC EURO HITCH ROCK PICKER (2,210 MM)

The Deep Tillage plough is designed for shattering compact ground with minimal disturbance to the sub soil. Ideal for ripping hard ground prior to cultivation and for aerating pastures, therefore increasing water absorption and improving the profile of the soil.
Can be used to renovate pastures or for bed renovation. Broad acre application and row cropping. High tensile cast shank assembly with 24 underframe clearance with 1 shear pin protection. Replaceable points and shin guards, also available with tungsten tips.
Optional crumbler rollers also available to help create a level surface and reduce crusting in the surface.
Optional coulters available to reduce surface disturbance in pasture (must be ordered with machine).
Specifications:
Heavy duty 100 x 100 x 9mm tine mounting frame.
High tensile cast shank assembly with 24in (610mm) underframe clearance with 1in shear pin protection. Replaceable points and shin guards also available with tungsten tips.
Breakout force approx. 4000 ft. / lbs.
Tine spacing set at 12in (300mm).
Approx 15HP required per tine.
Adjustable pair of Holden wheel for depth control available as an option.
Optional coulters available to reduce surface disturbance in pasture.
Available in 2, 3, 5, 7, 9 or 11 tine models with other sizes made on request. 2 and 3 tine models are fitted on a single row frame. Trailing units also available.
Optional crumbler rollers also available to help create a level surface and reduce crusting in the surface.
Options:
0327 14in Coulters (must be ordered with machine) priced per coulter unit.
0355 Optional Hydraulic Phasing Cylinders to replace ratchets.
0200 Depth Wheels (Pair Holden) optional normally mounted outside frame.
0354 9 Tine Crumbler (ratchet adjustment).
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

JOHN BERENDS DEEP TILLAGE PLOUGHS 9 TINE - 0324, MIN 135+HP

Made in Australia
Features:
- Dual independent grapples, cylinder covers
- 115 mm tyne spacing's
- Inc hoses, fittings & couplings
- Rock solid design for extreme duty applications
- 40 x 40 mm high tensile solid bar tynes
- Greasable pivot points
Dimensions:
Suits: 80 - 180 hp
Max Opening = 930 mm
Tyne Spacing's = 115 mm
Max Width = 2,100 mm
Weight = 635 kg
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available.
Contact Farm Supplies today for sale or more information.
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

HIMAC EURO HITCH DOUBLE CLAW POWER GRAPPLE (2.1M)

The RM80 offset disc cultivating plough is designed for extremely tough conditions. It is similar to the RM75 with the main difference being in the greater number of bearings and shorter axles in the disc gang assemblies.
Features:
Ideal for primary and secondary tillage for 75-165 HP tractors.
Fitted with 24inch x 5mm scalloped discs. All discs are European Bellota Boron discs which carry a lifetime warranty against manufacturing failure.
Fitted with two 11×16 flotation wheels on a 5 tonne axle. Hydraulic wheel lift is standard. All models fitted with 8inch Australian made Eaton Rams.
40mm square high tensile gang bolts.
Single pressure screw can be adjusted to transfer weight to the rear of the cultivator, resulting in even disc penetration. Option of fixed or floating position.
Flanged disc bearings designed specifically for severe tillage applications. The bearings are encapsulated in two case hardened zinc plated stampings. Two nitrile O rings are fitted to exclude contaminants and provide a grease seal to ensure lubricant goes directly into the bearing.
Fully adjustable drawbar.
Solid cast spools throughout the gangs provide ballast weight in the gangs, where it counts, rather than the main frame. Each is individually machined to suit the disc for extra strength.
9 inch disc spacing.
Australian made Ryco hoses are used with a minimum burst pressure of 20,400 psi.
Prong type scrapers are standard formed scrapers available on request.
Parking jack is standard.
Optional furrow fillers available.
Specifications:
Approx Weight: 1970kg
No of bearings: 12
No of axles: 6
Cutting width: 2.74m (9ft)
Options:
0953 Optional Furrow filler (not sold separately)
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

JOHN BERENDS RM80 HD TRAILING OFFSET 24 PLATE 24 INCH 5MM SCALLOP DISCS - 0851, SUIT 75-165HP

Lima Bean Seed Disc. 30.5cm spacing.
In addition to lima beans, will also plant peanuts and other large seeds 15.9mm in size
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

EARTHWAY LIMA BEAN (LARGE) SEED PLATE ES-1002-30

Trailed over row 4000 litre G2E Turbo Scram 2 row Turbowrap sprayer with sprayheads, 4 x 320mm fans, 350 L/min Hydraulic drive stainless steel pump, automatic spray rate controller, self contained hydraulic drive system and tandem suspension axle. Ideal for vineyards.
Note: infield image shows 2000L 2 row Turbo Scram and product image shows G2 model.
Specifications:
Market: Horticulture.
Tank Size (L): 4,000
Connection Type: Trailed
Min PTO HP: 65
Pump Size (L/min): 350
Height / Width / Length (mm): 3160 / 1935 (less head), 2490 (folded) / 5340
Product Weight (kg): 1,820 (dry)
Application: Vineyards
Features:
Head: Two row spraying head: 28 venturi air shear adjustable nozzles with individual metering and on/off taps. Three row spraying head: 42 venturi air shear adjustable nozzles with individual metering and on/off taps. Left & right arms are independent hydraulic folding with adjustable width & centre frame. Boom frame is galvanised.
Pump: Stainless steel, hydraulic drive centrifugal pump, 350 L/min. Stainless steel shaft and Viton/ceramic seal. Driven by tractor remotes.
Fan Size: 320 mm turbine fan, one per air tube, 3600 rpm. Power consumed 29 kw / 38HP
Hydraulic Control: Hitch mounted hydraulic power pack with; 40L oil reservoir with cartridge particulate filter, motors fitted with case drain, hydraulic distribution block incorporates anticavitation and pressure relief valves, 12V oil cooler
Nozzles: Air shear.
Controls: Electric section valves with Bravo 180S automatic rate controller. Large 100mm pressure gauge.
Frame: Galvanised steel chassis, linkage hitch fitted with hydraulic power pack
Tank: Polytuff impact resistant polyethylene construction, calibrated sight line, flip top easy open lid, 50mm camlock bottom fill and hand wash tank. (205L flush tank on 3000L)
Agitation: Venturi agitator.
Filtration: Lid strainer and large capacity suction filter.
Wheel Equipment: Tandem suspension axle with 10 x 15" tyres (3000L) or 11.5 x 15.3" tyres (4000L).
PTO Driveshaft: Quality Bondioli & Pavesi driveshaft with quick release pins and safety cover.
HP Required: Minimum 65 PTO HP (2 row), Minimum 80 PTO HP (3 row).
Options:
- Bravo 180S spray rate controller with hydraulic controls (in lieu) (J99-180)
- IBX 100 ISOBUS controller (in lieu - requires compatible in-cab console) (J99-181)
- Hydraulic row width/height adjustment
- Hydraulic pump driven through power pack (D99-185)
- 100L flush tank (to suit 4000L) (J99-112)
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN 4,000L (2 ROW) G2E TRAILED TURBO SCRAM TURBOWRAP - MIN 65PTO HP

The ultimate weapon when it comes to efficiently maintaining your lifestyle block. Pre-cutting is not necessary as branches simply flow through the large inlet chute. The momentum within the cantilevered cutting disk creates a strong draft to discharge high onto a stock pile or trailer.
The Hansa C7 easily mulches prunings, dropped branches, palm fronds, leaves, bark, paper, cardboard, hay, dried manure and kitchen waste.
Features:
Honda GX200 4 stroke petrol engine
Easy start
Heavy duty blades
Pneumatic wheels for easy manoeuvring by hand or by road in a trailer, ute or 4WD
Solid-steel casing
Twin belt drive
Adjustable output chute
Similar noise output to a domestic mower
Minimal cleaning and maintenance required for this garden shredder, mulcher & chipper.
Available in a standard or towbar version
On registration engine four years, chipper two years domestic warranty
Technical Specifications:
Max. chipping capacity: 70mm
Engine: Honda GX200
Max Power: 6.5HP
Fuel tank size: 3.6L
Starting system: Recoil
Inlet chute size: 130 x 150mm
Qty of knives: 2
Knife size: 110 x 42 x 9mm
Knife material: A8 modified tool steel
Cutting disk dimensions: 400 x 10mm
Cutting disk weight: 12.5kg
Cutting disk speed: 2850RPM
Beltdrive: Twin
Self-feeding: Yes
Wheels: 270mm pneumatic
Dimensions: L900 x W650 x H1200mm
Weight: 93kg
Outlet chute height: 780mm
Outlet chute type: Deflector
Optional Add-Ons and Spare Parts:
C7 Towbar Tongue
C7 Towbar Coupling
C7 Bumper
C7 Blades
C7 Anvil
C7 Belts
C7 Cover
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

HANSA C7 CHIPPER 70MM CHIPPING CAPACITY

Trailed turbomiser P50E 2000 litre sprayer with 140 L/min centrifugal pump, 500mm turbine fan, Glideflex axle and wide angle PTO shaft. Ideal for vineyards and orchards.
Note: Spray head not included. Images shown are of the 1500L model.
Specifications:
Market: Horticulture. Viticulture.
Tank Size (L): 2,000
Connection Type: Trailed
Min PTO hp: 65
Pump Size (L/min): 140
Height / Width / Length (mm): 1530 / 1540 / 3970
Product Weight (kg): 650 (dry)
Application: Vineyards, orchards.
Features:
Pump: CD32 centrifugal pump, 140L/min. constructed from toughened nylon. Stainless steel shaft & viton/ceramic seal
Fan Size: P50E: 500mm dia. turbine fan, 4000 rpm. Power consumed 40 kw / 55HP.
Nozzles: Air shear.
Controls: Two sided electric on/off control with pressure regulation operated from control box mounted in cabin. Rotary plate distribution regulators with 15 settings. Large 100 mm pressure gauge.
Frame: Galvanised steel chassis, adjustable drawbar with jockey wheel.
Tank: Polytuff impact resistant polyethylene construction, calibrated sight line, large non-spill flip top lid, built-in chemical mixer and 40L fresh water tank.
Agitation: Pump bypass plus venturi agitator.
Filtration: Lid strainer and large capacity suction filter
Wheel Equipment: Glideflex suspension axle, 2 x 15" tubeless tyres on galvanised rims (max speed rating 30 km/h).
PTO Driveshaft: Quality Bondioli & Pavesi driveshaft with quick release pins and safety cover.
HP Required: Minimum 65 PTO HP
Options:
- Vineyard head - 4 heads (4x4) (GT55-11)
- Bravo 180S automatic rate controller (GT-24)
- Hydraulic drive pump (GT55-22)
- Flotation tyres - 400/60 x 15.5" with fixed axle (in lieu of standard) (D99-80)
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN 2,000L P50E TRAILED TURBOMISER - MIN 65PTO HP (SPRAY HEAD NOT INCLUDED)

142 L/min pump with Male - Male shaft.
Silvan APS series high pressure diaphragm pumps are built for 540 RPM operation, are self-priming and feature a corrosion resistant cast anodised aluminium body. Tough and reliable they will run dry without risk of damage.
All pumps are supplied with appropriate hose connections, mounting base plates and 1 3/8 six splined shaft.
Specifications:
Pump Size (L/min): 142
Height / Width / Length (mm): 420 / 380 / 342
Product Weight (kg): 46
Max pressure : 5,000 (kPA)
Shaft: Male - Male
Diaphragms: 4
HP required at Max pressure: 18
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN HIGH PRESSURE DIAPHRAGM PUMP (142 LPM, MALE - MALE)

The Nobili VKD series mulchers are a medium duty, multi-purpose machine ideal for vineyard and orchard mulching, and for road side mulching by councils.
An adjustable tailboard is fitted for maintenance. A finer mulch is produced with two mulching bars, a restrictor bar and rakes. The VKD has side shift to the right with optional hydraulic side shift and height control is by an adjustable full width roller.
Features:
Suggested Use: Grass and green prunings up to 80mm diameter.
Construction: Low profile body, adjustable tailboard, two mulching bars and one restrictor bar.
ControlL: Manual side shift with optional hydraulic side shift.
Drive Line: PTO drive shaft with durable safety cover, heavy duty gearbox fitted with in-built over run clutch, taper locked pulleys and electronically balanced rotor.
Attachment: Cat. I and II three point linkage, floating top link.
Height Control: Roller (standard fitment).
Specifications:
Connection Type: Linkage
Blades (Cast Hammers): 20
Tractor HP: 65-100 HP
Working Width (mm): 1906
Product Weight (kg): 600
Width / Depth / Height (mm): 2040 / 1075 / 510
Options:
Hydraulic Side Shift
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

NOBILI 1.9M VKD ORCHARD MULCHERS (65-100HP)

The Rollmaxx SW2000C, SW2000, SW2400EC and SW2400E models are designed for transportation of Mini Excavators. These compact Trailers maintain impressively low tare weights, yet are still wide enough to accommodate most excavators with operating weights up to 2,000kg.
The SW2000C and SW2000 Trailer give operators the advantage of towing equipment up to 1,900kg in weight, without the legal requirement for an electric brake system. These have a special application in the Hire Industry.
The SW2400EC and SW2400E Trailer, with its Electric Brakes and Break-away System, give even greater versatility, making it possible to carry up to 2,065kg with an Aggregate Trailer Mass [A.T.M] of only 2,400kg.
The SW3500ER, which is also included with Mini Loader Trailers, allows 2,850kg of equipment to be towed with an Aggregate Trailer Mass [A.T.M] of just 3,500kg.
The SW4100ER, which is also included with Mini Loader Trailers, allows 3,450kg of equipment to be towed with an [A.T.M] of just 4,100kg.
Specifications:
Aggregate Trailer Mass: 2,200kg
Allowable Payload: 1,900kg
Tare Weight: 280kg
Deck Width: 1,100mm
Deck Length: 1,900mm
Bucket Rest Length: 1,400mm
Total Trailer Length: 4,700mm
Features:
Aluminium Deck Construction
Top Quality Components including LED Lights
Hinged Aluminium Ramps
Robust Steel Mudguards, double coated in a Choice of Colours
HDPE Buffers on Bucket Rest area.
Options:
JCH2435 - Lockable Jerry Can Holder
LRK2435 - Load Restraint Kit
TC70 - Tow Coupling 70mm (non-standard)
TB70 - Tow Ball 70mm (non-standard)
WTU14 - Upgrade to 14" Alloy Wheels
WTU16 - Upgrade to 16" Alloy Wheels
WTS13 - Wheel & Tyre, Spare, 13" Steel (Supply only)
WTS14 - Wheel & Tyre, Spare, 14" Steel (Supply only)
WTS15 - Wheel & Tyre, Spare, 15" Steel (Supply only)
WTS16 - Wheel & Tyre, Spare, 16" Steel (Supply only)
WTA14 - Wheel & Tyre, Spare, 14" Alloy (Supply only)
WTA16 - Wheel & Tyre, Spare, 16" Alloy (Supply only)
WM1416 - Spare Wheel Mount
AM2435 - Auger Stands
RPU2435 - Roller Package Upgrade
Models:
SW2000C - 2,200kg Aggregate Trailer Mass, 1,900kg Allowable Payload, 280kg Tare Weight, 1,100mm Deck Width, 1,900mm Deck Length, 1,400mm Bucket Rest Length, 4,700mm Total Trailer Length.
SW2000 - 2,200kg Aggregate Trailer Mass, 1,860kg Allowable Payload, 340kg Tare Weight, 1,310mm Deck Width, 1,900mm Deck Length, 1,400mm Bucket Rest Length, 4,700mm Total Trailer Length.
SW2400EC - 2,400kg Aggregate Trailer Mass, 2,060kg Allowable Payload, 340kg Tare Weight, 1,100mm Deck Width, 1,900mm Deck Length, 1,400mm Bucket Rest Length, 4,700mm Total Trailer Length.
SW2400E - 2,400kg Aggregate Trailer Mass, 2,020kg Allowable Payload, 380kg Tare Weight, 1,310mm Deck Width, 1,900mm Deck Length, 1,400mm Bucket Rest Length, 4,700mm Total Trailer Length.
SW3500ER - 3,500kg Aggregate Trailer Mass, 2,850kg Allowable Payload, 620kg Tare Weight, 1,800mm Deck Width, 2,600mm Deck Length, 1,100mm Bucket Rest Length, 5,200mm Total Trailer Length.
SW4100ER - 4,100kg Aggregate Trailer Mass, 3,450kg Allowable Payload, 620kg Tare Weight, 1,800mm Deck Width, 2,600mm Deck Length, 1,100mm Bucket Rest Length, 5,200mm Total Trailer Length.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SUREWELD 1,900KG PAYLOAD MINI EXCAVATOR TRAILER WITH 2,200KG A.T.M AND 280KG TARE

Find Farm Machinery For Sale. Browse 7607 listings from Farm Supplies Machinery & Equipment.

New & Used Farm Machinery For Sale

Farm Supplies Machinery & Equipment

Sale Price

JOHN BERENDS RIGID TINE CHISEL PLOUGHS 9'9" (2.9M) - 0184

HIMAC EURO HITCH ROCK PICKER (2,210 MM)

JOHN BERENDS DEEP TILLAGE PLOUGHS 9 TINE - 0324, MIN 135+HP

HIMAC EURO HITCH DOUBLE CLAW POWER GRAPPLE (2.1M)

JOHN BERENDS RM80 HD TRAILING OFFSET 24 PLATE 24 INCH 5MM SCALLOP DISCS - 0851, SUIT 75-165HP

EARTHWAY LIMA BEAN (LARGE) SEED PLATE ES-1002-30

SILVAN 4,000L (2 ROW) G2E TRAILED TURBO SCRAM TURBOWRAP - MIN 65PTO HP

HANSA C7 CHIPPER 70MM CHIPPING CAPACITY

SILVAN 2,000L P50E TRAILED TURBOMISER - MIN 65PTO HP (SPRAY HEAD NOT INCLUDED)

SILVAN HIGH PRESSURE DIAPHRAGM PUMP (142 LPM, MALE - MALE)

NOBILI 1.9M VKD ORCHARD MULCHERS (65-100HP)

SUREWELD 1,900KG PAYLOAD MINI EXCAVATOR TRAILER WITH 2,200KG A.T.M AND 280KG TARE

Farm Supplies Machinery & Equipment

Dealer Address
