RM40 22 Plate Heavy Duty Trailing Offset 0823
The RM40 is one of the most popular of our wide range of offset and tandem disc cultivating ploughs.
Features:
Great digging ability ideal for primary and secondary tillage using 40Hp to 90HP tractors.
Twin pressure screws each side can be adjusted individually.
Easy gang adjustment for the perfect level finish.
Solid cast spools individually machined to suit the disc for extra strength.
Triple sealed bearings.
230mm (9 inch) disc spacing.
Fitted with 560mm x 5mm (22 inch x 3/16 inch) scalloped discs.
28mm square high tensile gang bolts.
Weight where it counts in the gang not ballast on the frame (which adds load to the bearings) like most other machines.
Prong type scrapers are standard equipment formed scrapers available on request.
Fully adjustable drawbar adjustable offset ideal for orchards.
Fitted with Holden type tyres.
Specifications:
Approx Weight 1170kg
No. Bearings 8
Cutting Width 2.5m (8ft 6in)
No. Axles 4
Options:
0951 Optional Jack
0953 Optional Furrow filler (not sold separately)
* Upgrade to 24 inch x 5mm discs POA

All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

JOHN BERENDS RM40 22 PLATE HEAVY DUTY TRAILING OFFSET - 0823, SUIT 40-90HP

Features:
- 150 x 100 x 8mm chassis
- 200 x 120 x 8mm gang beams
- 28 (710mm) scalloped discs on this CVH-71 model (8mm thick)
- Disc scrapers
- 10 (260mm) disc spacing
- Eight double taper roller bearings with a 5 year warranty
- Reinforced bearing protectors
- Manual gang angle adjustment from 8 - 24 degrees
- Manual fore/aft adjustment with spring
- 40mm square silicon manganese steel disc axles
- 400 / 60 x 15.5 flotation tyres
- Swivel hitch
Super heavy offset discs for demanding agricultural and cropping applications. High quality French manufactured with a 5 year bearing warranty.
Working Width = 4,000 mm
Overall Width = 4,250 mm
Required HP Range = 200 - 250 hp
Weight = 3,100 kg
Number of Discs = 32
Options available:
- Hydraulic fore/aft adjustment
- Hydraulic drawbar adjustment
- Hydraulic gang angle adjustment
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

GB 4M, 32 DISCS (200-250HP) HEAVY DUTY OFFSET DISCS

The RM80 offset disc cultivating plough is similar to the RM75 with the main difference being in the greater number of bearings and shorter axles in the disc gang assemblies.
Features:
Ideal for primary and secondary tillage for 75-165 HP tractors.
Fitted with 26inch x 6mm scalloped discs. All discs are European Bellota Boron discs which carry a lifetime warranty against manufacturing failure.
Fitted with two 11×16 flotation wheels on a 5 tonne axle. Hydraulic wheel lift is standard. All models fitted with 8inch Australian made Eaton Rams.
40mm square high tensile gang bolts.
Single pressure screw can be adjusted to transfer weight to the rear of the cultivator, resulting in even disc penetration. Option of fixed or floating position.
Flanged disc bearings designed specifically for severe tillage applications. The bearings are encapsulated in two case hardened zinc plated stampings. Two nitrile O rings are fitted to exclude contaminants and provide a grease seal to ensure lubricant goes directly into the bearing.
Fully adjustable drawbar.
Solid cast spools throughout the gangs provide ballast weight in the gangs, where it counts, rather than the main frame. Each is individually machined to suit the disc for extra strength.
9 inch disc spacing.
Australian made Ryco hoses are used with a minimum burst pressure of 20,400 psi.
Prong type scrapers are standard formed scrapers available on request.
Parking jack is standard.
Optional furrow fillers available.
Specifications:
Approx Weight: 2510kg
No of bearings: 16
No of axles: 8
Cutting width: 3.66m (12ft)
Options:
0953 Optional Furrow filler (not sold separately)
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

JOHN BERENDS RM80 HD TRAILING OFFSET 32 PLATE 26 INCH 6MM SCALLOP DISCS - 0873, SUIT 75-165HP

The RM75 offset disc cultivating plough is a tough, rugged machine designed for Australian conditions. The RM75 is similar to the RM80 with the main difference being in the lesser number of bearings and longer axles. Ideal for primary and secondary tillage for 60HP-130HP tractors.
Features:
Fitted with 24 inch x 5mm scalloped discs. All discs are European Bellota Boron discs which carry a lifetime warranty against manufacture failure.
Fitted with two 750×16 Land Cruiser wheels on a 5 tonne axle. Hydraulic wheel lift is standard. All models fitted with 8 inch Australian made Eaton rams.
Australian made Ryco hoses are used with a minimum burst pressure of 20,400psi.
Twin pressure screws can be adjusted individually to transfer weight to the rear of the plough, resulting in even disc penetration.
40mm square high tensile gang bolts.
Flange disc bearings designed specifically for severe tillage applications. The bearings are encapsulated in two case hardened zinc plated stampings. Two nitrile O rings are fitted to exclude contaminants and provide a grease seal to ensure lubricant goes directly into the bearing.
Fully adjustable drawbar.
Solid cast spools throughout the gangs provide ballast weight in the gangs, where it counts, rather then the main frame. Each is individually machined to suit the disc for extra strength.
9 inch disc spacing.
Fitted with hydraulic lift as standard.
Prong type scrapers are standard formed scrapers on request.
Parking jack is optional.
Optional furrow fillers available.
Specifications:
Approx Weight: 1575kg
No of bearings: 6
No of axles: 2
Cutting width: 2.06m (6ft 9inch)
Options:
0951 Optional jack
0953 Optional Furrow filler (not sold separately)
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

JOHN BERENDS RM75 HD TRAILING OFFSET 18 PLATE 5MM DISCS - 0830, SUIT 60-130HP

Merbein ploughs consist of left hand and right hand, two or three disc units attached to a range of toolbar sizes, to create just the right bed or channel for your needs.
This item includes:
Two 0522 units with x3 Discs each side plus one 0530 7ft (2.1m) Toolbar.
Please specify left or right hand when ordering. Left hand throws dirt to the left hand side and right hand throws dirt to the right hand side.
Also Available:
0536 Merbein rear coulter (one side only)
Please specify left or right hand when ordering. Left hand throws dirt to the left hand side and right hand throws dirt to the right hand side.
0528 6ft (1.8m) merbein toolbar
0530 7ft (2.1m) merbein toolbar
0532 8ft (2.4m) merbein toolbar
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

JOHN BERENDS MERBEIN PLOUGHS 3 DISCS PER SIDE WITH 7FT TOOLBAR - 0522 X2 INCL 0530

Heavy duty trailing tandem disc plough designed for heavy cultivation in hard conditions. The angle is hydraulically adjusted and has a transport width of under 2.4m.
Features:
Available in 28, 32, 36, 40, 44 and 48 plate models at 9 inch disc spacing's.
Fitted with 24 inch x 6mm or 26 inch x 6mm scalloped discs. All discs are European Bellota Boron discs which carry a lifetime warranty against manufacturing failure.
All models are fitted with hydraulic gang adjustment which allows the gangs to be folded parallel with the main frame, to be under 2.4m overall width.
Gangs can also be opened right up to no angle at all when only a fine till of the topsoil is required.
Solid cast of spools throughout the gangs provide ballast weight in the gangs, where it counts, rather than in the main frame. Each is individually machined to suit the disc for extra strength.
Flanged disc bearings designed specifically for severe tillage applications. The bearings are encapsulated in two case hardened zinc plated stampings. Two nitrile O rings are fitted to exclude contaminants and provide a grease seal to ensure lubricant goes directly into the bearing.
Buster tine removes centre ridge to create a level finish.
Integrated furrow fillers are standard.
Fitted with four Land Cruiser wheels on a 5 tonne axle. Hydraulic wheel lift is standard.
40mm square high tensile gang bolts.
Fully adjustable drawbar height with parallel lift for better transportation.
Wheelkit locking arms reduce stress on the hydraulics when transporting.
Australian made Ryco hoses are used with a minimum burst pressure of 20,400 psi.
Australian made Eaton cylinders.
Prong type scrapers are standard formed scrapers on request.
Parking jack is standard.
Specifications:
Approx Weight: 4130kg
No. of Bearings: 24
No. of axles: 12
Cutting width: 5.71m (18ft 9inch)
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

JOHN BERENDS TH100 HD TRAILING TANDEM DISCS - 48 PLATE X 26 INCH DISCS - 0965

Heavy duty trailing tandem disc plough designed for heavy cultivation in hard conditions. The angle is hydraulically adjusted and has a transport width of under 2.4m.
Features:
Available in 28, 32, 36, 40, 44 and 48 plate models at 9 inch disc spacing's.
Fitted with 24 inch x 6mm or 26 inch x 6mm scalloped discs. All discs are European Bellota Boron discs which carry a lifetime warranty against manufacturing failure.
All models are fitted with hydraulic gang adjustment which allows the gangs to be folded parallel with the main frame, to be under 2.4m overall width.
Gangs can also be opened right up to no angle at all when only a fine till of the topsoil is required.
Solid cast of spools throughout the gangs provide ballast weight in the gangs, where it counts, rather than in the main frame. Each is individually machined to suit the disc for extra strength.
Flanged disc bearings designed specifically for severe tillage applications. The bearings are encapsulated in two case hardened zinc plated stampings. Two nitrile O rings are fitted to exclude contaminants and provide a grease seal to ensure lubricant goes directly into the bearing.
Buster tine removes centre ridge to create a level finish.
Integrated furrow fillers are standard.
Fitted with four Land Cruiser wheels on a 5 tonne axle. Hydraulic wheel lift is standard.
40mm square high tensile gang bolts.
Fully adjustable drawbar height with parallel lift for better transportation.
Wheelkit locking arms reduce stress on the hydraulics when transporting.
Australian made Ryco hoses are used with a minimum burst pressure of 20,400 psi.
Australian made Eaton cylinders.
Prong type scrapers are standard formed scrapers on request.
Parking jack is standard.
Specifications:
Approx Weight: 3680kg
No. of Bearings: 16
No. of axles: 8
Cutting width: 4.33m (14ft 3inch)
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

JOHN BERENDS TH100 HD TRAILING TANDEM DISCS - 36 PLATE X 24 INCH DISCS - 0974

Designed for extremely tough conditions and is one of the strongest linkage disc ploughs available. Heavy weighted gangs provide excellent digging ability.
Features:
Each machine takes approximately 2-3HP per disc to pull, depending on conditions.
Prong scrapers are also available for heavy clay soil.
Twin spring loaded pressure screws prevent damage in rocky or undulating conditions.
Easy gang angle adjustment.
Fitted with hard wearing European Bellota Boron discs at 9 inch spacing. Available in 22x5mm(or optional 24x5mm sizes).
Cat 1 & 2 linkage.
28mm square high tensile axles.
Greaseable flanged disc bearings with excellent sealing to exclude contaminants.
Solid cast spools, individually machined, provide all the weight in the gangs rather than in the frame (which can add load onto the bearings.
Specifications:
Disc Size 22inch dia, 5mm thick, Scallop Disc
Approx Weight- 910kg
No. Bearings 8
No. Axles 4
Cutting Width 2.5m(8ft 3inch)
Options:
0949 Optional Scrapers suit 22 plate GM40.
0953 Optional Furrow filler (not sold separately).
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

JOHN BERENDS GM40 22 PLATE HEAVY DUTY OFFSET DISCS - 0812, 2-3HP PER DISC

Heavy duty trailing tandem disc plough designed for heavy cultivation in hard conditions. The angle is hydraulically adjusted and has a transport width of under 2.4m.
Features:
Available in 28, 32, 36, 40, 44 and 48 plate models at 9 inch disc spacing's.
Fitted with 24 inch x 6mm or 26 inch x 6mm scalloped discs. All discs are European Bellota Boron discs which carry a lifetime warranty against manufacturing failure.
All models are fitted with hydraulic gang adjustment which allows the gangs to be folded parallel with the main frame, to be under 2.4m overall width.
Gangs can also be opened right up to no angle at all when only a fine till of the topsoil is required.
Solid cast of spools throughout the gangs provide ballast weight in the gangs, where it counts, rather than in the main frame. Each is individually machined to suit the disc for extra strength.
Flanged disc bearings designed specifically for severe tillage applications. The bearings are encapsulated in two case hardened zinc plated stampings. Two nitrile O rings are fitted to exclude contaminants and provide a grease seal to ensure lubricant goes directly into the bearing.
Buster tine removes centre ridge to create a level finish.
Integrated furrow fillers are standard.
Fitted with four Land Cruiser wheels on a 5 tonne axle. Hydraulic wheel lift is standard.
40mm square high tensile gang bolts.
Fully adjustable drawbar height with parallel lift for better transportation.
Wheelkit locking arms reduce stress on the hydraulics when transporting.
Australian made Ryco hoses are used with a minimum burst pressure of 20,400 psi.
Australian made Eaton cylinders.
Prong type scrapers are standard formed scrapers on request.
Parking jack is standard.
Specifications:
Approx Weight: 3500kg
No. of Bearings: 16
No. of axles: 8
Cutting width: 3.88m (12ft 9inch)
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

JOHN BERENDS TH100 HD TRAILING TANDEM DISCS - 32 PLATE X 24 INCH DISCS - 0973

Designed for small to medium size tractors.
Popular cultivation tool used to break up soil for preparing crops or controlling weeds. Discs can cut up and mix in trash, are very hard wearing, long lasting and easy to use.
Fitted with 28mm (1 1/8in) square high tensile gang bolt axles and high quality triple sealed bearings.
14-18 plate models fitted with 75x75x6mm double beam whilst 10-12 plate models are fitted with main single beam and angle support bracket.
Cat 1/2 linkage.
Clamped on by U-bolts for simple adjustment.
Bellota Boron discs are manufactured under strict quality specifications that ensure the right hardness and uniformity throughout the disc. This includes clamp hardening to prevent distortion, lathe turning of the edges and hardened to 50HRc for low wear and long life.
Features:
No of Discs 18
Disc Diameter 550mm (22inch)
Disc Thickness 5mm
HP (min) 40HP
No. Bearings 6
Working Width 2050mm (6ft 9in)
Weight 465kg
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

JOHN BERENDS MEDIUM DUTY OFFSET DISCS - 18 PLATE X 22 INCH DISCS - 0252, MIN 40HP

The RM80 offset disc cultivating plough is similar to the RM75 with the main difference being in the greater number of bearings and shorter axles in the disc gang assemblies.
Features:
Ideal for primary and secondary tillage for 75-165 HP tractors.
Fitted with 26inch x 6mm scalloped discs. All discs are European Bellota Boron discs which carry a lifetime warranty against manufacturing failure.
Fitted with two 11×16 flotation wheels on a 5 tonne axle. Hydraulic wheel lift is standard. All models fitted with 8inch Australian made Eaton Rams.
40mm square high tensile gang bolts.
Single pressure screw can be adjusted to transfer weight to the rear of the cultivator, resulting in even disc penetration. Option of fixed or floating position.
Flanged disc bearings designed specifically for severe tillage applications. The bearings are encapsulated in two case hardened zinc plated stampings. Two nitrile O rings are fitted to exclude contaminants and provide a grease seal to ensure lubricant goes directly into the bearing.
Fully adjustable drawbar.
Solid cast spools throughout the gangs provide ballast weight in the gangs, where it counts, rather than the main frame. Each is individually machined to suit the disc for extra strength.
9 inch disc spacing.
Australian made Ryco hoses are used with a minimum burst pressure of 20,400 psi.
Prong type scrapers are standard formed scrapers available on request.
Parking jack is standard.
Optional furrow fillers available.
Specifications:
Approx Weight: 2190kg
No of bearings: 12
No of axles: 6
Cutting width: 3.2m (10ft 6inch)
Options:
0953 Optional Furrow filler (not sold separately)
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

JOHN BERENDS RM80 HD TRAILING OFFSET 28 PLATE 26 INCH 6MM SCALLOP DISCS - 0872, SUIT 75-165HP

RM40 18 Plate Heavy Duty Trailing Offset 0821
The RM40 is one of the most popular of our wide range of offset and tandem disc cultivating ploughs.
Features:
Great digging ability ideal for primary and secondary tillage using 40Hp to 90HP tractors.
Twin pressure screws each side can be adjusted individually.
Easy gang adjustment for the perfect level finish.
Solid cast spools individually machined to suit the disc for extra strength.
Triple sealed bearings.
230mm (9 inch) disc spacing.
Fitted with 560mm x 5mm (22 inch x 3/16 inch) scalloped discs.
28mm square high tensile gang bolts.
Weight where it counts in the gang not ballast on the frame (which adds load to the bearings) like most other machines.
Prong type scrapers are standard equipment formed scrapers available on request.
Fully adjustable drawbar adjustable offset ideal for orchards.
Fitted with Holden type tyres.
Specifications:
Approx Weight 1040kg
No. Bearings 6
Cutting Width 2.06m (6ft 9in)
No. Axles 2
Options:
0951 Optional Jack
0953 Optional Furrow filler (not sold separately)
* Upgrade to 24 inch x 5mm discs POA

All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

JOHN BERENDS RM40 18 PLATE HEAVY DUTY TRAILING OFFSET - 0821, SUIT 40-90HP

Find Offset Discs Tillage And Seeding Equipment For Sale from Farm Supplies Machinery & Equipment.

New & Used Offset Discs Tillage And Seeding Equipment For Sale

Farm Supplies Machinery & Equipment

Sale Price

JOHN BERENDS RM40 22 PLATE HEAVY DUTY TRAILING OFFSET - 0823, SUIT 40-90HP

GB 4M, 32 DISCS (200-250HP) HEAVY DUTY OFFSET DISCS

JOHN BERENDS RM80 HD TRAILING OFFSET 32 PLATE 26 INCH 6MM SCALLOP DISCS - 0873, SUIT 75-165HP

JOHN BERENDS RM75 HD TRAILING OFFSET 18 PLATE 5MM DISCS - 0830, SUIT 60-130HP

JOHN BERENDS MERBEIN PLOUGHS 3 DISCS PER SIDE WITH 7FT TOOLBAR - 0522 X2 INCL 0530

JOHN BERENDS TH100 HD TRAILING TANDEM DISCS - 48 PLATE X 26 INCH DISCS - 0965

JOHN BERENDS TH100 HD TRAILING TANDEM DISCS - 36 PLATE X 24 INCH DISCS - 0974

JOHN BERENDS GM40 22 PLATE HEAVY DUTY OFFSET DISCS - 0812, 2-3HP PER DISC

JOHN BERENDS TH100 HD TRAILING TANDEM DISCS - 32 PLATE X 24 INCH DISCS - 0973

JOHN BERENDS MEDIUM DUTY OFFSET DISCS - 18 PLATE X 22 INCH DISCS - 0252, MIN 40HP

JOHN BERENDS RM80 HD TRAILING OFFSET 28 PLATE 26 INCH 6MM SCALLOP DISCS - 0872, SUIT 75-165HP

JOHN BERENDS RM40 18 PLATE HEAVY DUTY TRAILING OFFSET - 0821, SUIT 40-90HP

Farm Supplies Machinery & Equipment

Dealer Address
