Super heavy duty , high clearance folding rotary hoe (Spike & Anti-pan rotor options available , suitable for tractors up to 360 hp.
Specifications:
Actual Width: 516cm
Working Width: 491cm
Required HP: 200-360hp
Weight: Cage roller - 3300kg, Packer roller - 3600kg
No of Blades: 114
Features:
Rotary hoe
Rated up to 360 hp
Hydraulic folding with safety locks and 2.5m transport width
80 x 10mm 'L' or 'C' shaped blades(options for 10mm blades, spikes rotor or antispan rotor)
Double welded blade flanges
16mm blade bolts
1000 rpm
Unique central split gearbox system for high horsepower loading and efficient torque distribution
Two speed side gearboxes with available gear speeds of: 208,230,260,284,310,340,375,410
2 piece split tailgates with dual manual angle adjustment
High clearance under hood
Gear side drive
Category three hitch, suitable for quick hitch (floating or fixed bottom links)
Grease lubricated centre drive bearings
Central loosening tine for 5mm bed gap
250mm working depth
Cam clutches on side driveshafts
Rear light frame with LED lights and AU Hazard panels
1 3/4 20 spline heavy duty front driveshaft
2 year warranty
Accessories:
450hp gearbox
Oil cooler with reservoir on central gearbox
Oil coolers with reservoir on side gearboxes
Front sod breaking disks (pair)
Track eradicators (set of 4)
'C' (speed) blades in lieu of 'L' blades
Options in Lieu of Standard:
Rotor Options
Double flange rotor (c/w 10mm blades)
Spike rotor spike (30x30x195)
Anti-pan rotor (10mm straight blade)
Roller Options
Cage roller (500mm diameter) with hydraulic adjustment
Packer roller (555mm diameter) with hydraulic adjustment
Models:
SUPERTIGER360P-500 491cm Working Width 200-360HP 114 BLADES
SUPERTIGER360P-500 541cm Working Width 220-360HP 126 BLADES
SUPERTIGER360P-600 591cm Working Width 240-360HP 138 BLADES
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

CELLI 4.91M (200-360 HP) SUPER TIGER ROTARY HOE

Oval Head Bolt Square Collar with Nut. Specifications shown in images.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SPAREX OVAL HEAD BOLT SQUARE COLLAR WITH NUT - M12 X 60MM

4.64m Murray Series 03 Levelling Harrow 4 Rank Deep Sections & Standard Drawbar, Heavy Duty. Complete Set.
3611 - 4.64m (15ft 3in) 4/12 Tine, 2/16 Tine - 114kg.
Murray Levelling Harrows are an excellent choice to complement sowing or cultivation implements. Designed to level soil and seedbeds, the flexible frame design provides durability in all soil types. 3 and 4 rank versions are suitable for use to cover seed in light to medium soils in conjunction with combines and seed drills. The 5 rank model is used in heavier soils to counter weed growth and break down large clods. It is a popular implement that complements cultivators, scarifiers or chisel plows.
If you require additional weight to work your land, a Heavy version of our Series 03 Levelling Harrows is available. Made from heavier High Carbon Steel, the Tine Spacing remains the same as the standard version.
The Series 03 Levelling Harrow is available in either 3 or 4 row widths allowing extensions in increments of 235mm (9 ¼) to suit primary machines of almost any width. This allows a combination of harrow sections to be configured to suit your application.
A full range of standard and heavy duty drawbars are available to correctly match your soil conditions and available working width of your equipment. Harrow sets complete with drawbars range from 2.31m (77) to 5.58m (184) in width.
Specifications:
- Tine Spacing 76mm (3in).
- Tine Length 190mm (7 1/2in) approx.
- Centre to centre of Front Hooks 235mm (9 1/4in).
Features:
- High Carbon Cut Tines.
- Light models manufactured from 25 x 6mm carbon steel and Heavy models from 32 x 6mm.
* Murray Harrows must be pulled (towed) by a tractor correctly fitted with an approved rollover protection structure. Murray Harrows are NOT intended for use with an ATV or Ride On Lawn Mower.

All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

MURRAY SERIES 03 LEVELLING HARROW 4.64M, 4 RANK DEEP SECTIONS & STD DRAWBARS-HEAVY DUTY-COMPLETE SET

Murray 2.28m, Series 06 Kinked Spring Tine 4 Rank Harrow System - Medium Duty- Complete Unit - 6021.
The Series 06 is a medium duty Spring Tine Harrow System popular with farmers for levelling operations in conjunction with primary and secondary tillage implements.
Series 06 Harrows employ double spring tines available in Kinked or Straight Tines, both 10mm in diameter. The tine angle is adjustable to suit your field conditions.
4 rank versions are available in three sizes ranging from 1.37m (4ft 6in) to 2.28m (7ft 6in). Murrays also manufacture an extra wide 14in (335mm) Rank Spacing Straight Tine units which seeks to provide superior trash flow handling capabilities.
Manual lifting has been eliminated with harrows able to be folded and travel with the principal implement.
Specificatons:
- 2.28m
- Weight: 143kg
- Tine Spacing for 4 rank models - 56mm (2 1/4in)
- Tine diameter is 10mm, Kinked (standard) or Straight Tine (Optional)
- Tine Length 450mm (17 3/4in) approx
- Rank Spacing 235mm (9 1/4in) STD 3 Rank
- 2 Mount ArmS per unit
Features:
- Kinked design Tines as standard.
- Straight design Tines optional.
- This Harrow is designed to fit on to the rear bar of scarifiers, chisel plows, cultivators etc.
- Adjustable Tine angle.
Optional:
- Straight Tines
* Murray Harrows must be pulled (towed) by a tractor correctly fitted with an approved rollover protection structure. Murray Harrows are NOT intended for use with an ATV or Ride On Lawn Mower.

All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

MURRAY 2.28M KINKED SPRING TINE 4 RANK HARROW MEDIUM DUTY COMPLETE UNIT - SERIES 06

Series 23 Small Acreage Chain Harrow. (1.22m x 0.76m)
Designed to be operated via UTV, 4WD or ride on Mower.
Specifications:
- Available in 0.76m (26) depth
- High Carbon 10mm Square Steel
- Weight: 78kg
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

MURRAY SMALL ACREAGE CHAIN HARROW (1.22M X 0.76M) - SERIES 23

Rotavator Tine.
Specifications shown in images.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SPAREX ROTAVATOR TINE TWISTED (LH)

Series 05 Pastureland Harrow System - Light Duty.
Complete light duty harrow systems available from 1.52m (5ft) to 6.09m (20ft) configurations, in standard/single-mesh and super/double mesh versions. Each set of Murray Pastureland Harrows is supplied complete with a steel drawbar.
The Murray Pastureland Harrow System is recommended for pasture establishment, maintenance and renovation applications. Ideal for breaking down and distributing animal manures and other organic matter evenly across the whole pasture, using a Series 05 will encourage pasture growth. This light duty harrow is suitable generally for pasture areas of less than 100 acres (40 hectares) and tows easily behind small and medium size tractors.
Murray Series 05 Pastureland Harrows utilise four rows of double-sided tripod tine units which slice through patts, clods and coarse vegetation. The tripod section is followed by heavy steel square chain mesh which further pulverises and spreads the manure and organic matter and revitalises the pasture. The standard single-mesh chain Murray Pastureland Harrow has 8 rows of chain complete with a spreader bar and drag weights. Where greater penetration and a more aggressive action is needed, the Murray super double-mesh chain Pastureland Harrow may be used, which has 15 rows of square chain mesh. The extra chain length and weight ensure a thorough processing of material.
The Series 05 Pastureland Harrows can be used in conjunction with the Murray Series 21 3-point linkage Harrow Hoist Frame for ease of transportation.
For larger field operations, Murray Agricultural Equipment manufactures the Series 20 Heavy Duty Pasture Harrow System.
100% Australian made and owned.
Features:
- Tine Spacing 51mm (2in)
- Tine Length 85mm (3 11/32in) approx
- Centre to Centre of Front Hooks 305mm (12in)
Drag Type Standard 0.76m (2ft6in) Deep Mesh Chain:
Model 5020 Coverage: 1.52m (5ft) 82kg
Model 5006 Coverage: 1.83m (6ft) 99kg
Model 5021 Coverage: 2.44m (8ft) 129kg
Model 5022 Coverage: 3.04m (10ft) 172kg
Model 5023 Coverage: 3.65m (12ft) 213kg
Model 5024 Coverage: 4.57m (15ft) 269kg
Model 5003 Coverage: 6.09m (20ft) 380kg
Hoist Lift Type (Series 21) Standard 0.76m (2ft6in) Deep Mesh Chain:
Model 5025 Coverage: 5ft 132kg
Model 5007 Coverage: 6ft 147kg
Model 5026 Coverage: 8ft 179kg
Model 5027 Coverage: 10ft 222kg
Model 5028 Coverage: 12ft 263kg
Model 5029 Coverage: 15ft 332kg
Drag Type Super 1.5m (5ft) Deep Mesh Chain:
Model: 5067 Coverage: 1.52m (5ft) 123kg
Model: 5008 Coverage: 1.83m (6ft) 133kg
Model: 5030 Coverage: 2.44m (8ft) 173kg
Model: 5031 Coverage: 3.04m (10ft) 225kg
Model: 5032 Coverage: 3.65m (12ft) 292kg
Model: 5033 Coverage: 4.57m (15ft) 349kg
Model: 5004 Coverage: 6.09m (20ft) 490kg
Hoist Lift Type (Series 21) Super 1.5m (5ft) Deep Mesh Chain:
Model: 5068 Coverage: 5ft 170kg
Model: 5009 Coverage: 6ft 185kg
Model: 5034 Coverage: 8ft 230kg
Model: 5035 Coverage: 10ft 280kg
Model: 5036 Coverage: 12ft 347kg
Model: 5037 Coverage: 15ft 417kg
Complete Set Comprises of Front Drawbar, Tine section, Mesh Chain section (and Series 21 3-Point Linkage Hoist Frame and Lift connectors if Hoist Lift type specified.
Model Numbers 5029 and 5037 also feature a Model Number 5071 Rear Lift / Hoist extension bar.
Individual panels, chains and parts also available for sale.
* Murray Harrows must be pulled (towed) by a tractor correctly fitted with an approved rollover protection structure. Murray Harrows are NOT intended for use with an ATV or Ride On Lawn Mower.

All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

MURRAY SERIES 05 PASTURELAND LIGHT DUTY HARROW SYSTEMS - (1.52M - 6.09M) WIDTH

Round Countersunk Square Hex Bolt & Nut specifications shown in images.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SPAREX ROUND COUNTERSUNK SQUARE HEX BOLT & NUT - M12 X 45MM

Scraper Plate specifications shown in images.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SPAREX SCRAPER PLATE - 140 X 75 X 3MM

Hexagonal Head Bolt With Nut specifications shown in images.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SPAREX HEXAGONAL HEAD BOLT WITH NUT (TH) - M12 X 45MM

When a single row of gangs isnt enough to get the results you are hoping for, then its time to call on the literal earth-shattering power of Farmtechss Maxi series!
The Maxi series offers maximum aeration capability with its additional row of gangs that effectively doubles the effect especially in areas of cultivation by increasing the shattering effect of the soil.
The Maxi series boasts a standard lineup of 4 rigid frame models with working widths that range from between 3-meters to 5-meters. Each requires a tractor with a power output thats somewhere between 120-200 HP depending on the effective width of the model. Center Folding trailing models are also available
To achieve the best results, we highly recommend combining the Maxi series with an electric seeder and a spring tine harrow to create a true one-pass renovator so you can simultaneously perforate the soil as well as apply seeds on your paddock.
Specifications:
Size: 2400mm
Cultivation Width: 2300mm
No. Tines Per Rotor: 4
Rotors Per Gang: 6
No. Gangs: 4
Mounting: Linkage
Approx Weight: 1790kg
Min HP Req: 90
Standard Features:
- Hot dipped galv finish
- Two rows of gangs
- Tines are spaced at 95mm
- Large rotor bearings
- Multi-gang system
- Aeration and cultivation settings
- Gang angle adjustable from 0-10 degrees. (At 10 degrees the aervator will aggressively cultivate.
- Gang adjusting spanner supplied
- Rear tow hitch
- Cat 1-2 pick up
- Built-in weight trays
Available Configurations:
- 3PL or trailing
- Fixed or Folding frame
- 2.4 to 5-meter working width
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

AERVATOR GH SERIES 2.4M - GH-2404 MAXI. MIN 90+ HP (3PL)

Heavy duty , high clearance folding rotary hoe (Spike & Anti-pan rotor options available, suitable for tractors up to 280 hp.
Specifications:
Actual Width: 565cm
Working Width: 541cm
Required HP: 220-280hp
Weight: Cage roller - 3370kg, Packer roller - 3670kg
No of Blades: 126
Features:
Rotary hoe
Rated up to 280 hp
Hydraulic folding with safety locks and 2.5m transport width
80 x 8mm 'L' or 'C' shaped blades(options for 10mm blades,spikes rotor or antispan rotor)
Single blade flanges (options for double welded flanges)
14mm blade bolts
1000 rpm
Unique central split gearbox system for high horsepower loading and efficient torque distribution
Two speed side gearboxes with available gear speeds of: 208,230,260,284,310,340,375,410
2 piece split tailgates with dual manual angle adjustment
High clearance under hood
Gear side drive
Category three hitch, suitable for quick hitch (floating or fixed bottom links)
Central loosening tine for 5mm bed gap
250mm working depth
Cam clutches on side driveshafts
Rear light frame with LED lights and AU Hazard panels
1 3/4 20 spline heavy duty front driveshaft
2 year warranty
Accessories:
Oil cooler with reservoir on central gearbox
Oil cooler with reservoir on side gearboxes
Front sod breaking discs (pair)
Track eradicators (set of 4)
'C' (speed) blades in lieu of 'L' blades
Hydraulic tailgate adjustment
Options in Lieu with Standard:
Rotor Options
Double flange rotor (c/w 10mm blades)
Spike rotor spike (30x30x195)
Anti-pan rotor (10mm straight blade)
Roller Options
Cage roller (500mm diameter) with hydraulic adjustment
Packer roller (555mm diameter) with hydraulic adjustment
Models:
TIGER 280P-450 441cm Working Width 180-280 HP 102 BLADES
TIGER 280P-500 491cm Working Width 200-280 HP 114 BLADES
TIGER 280P-550 541cm Working Width 220-280 HP 126 BLADES
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

CELLI 5.41M (220-280 HP) TIGER FOLDING ROTARY HOE

Find Tillage AND Seeding For Sale. Browse 964 Tillage AND Seeding listings from Farm Supplies Machinery & Equipment.

New & Used Tillage AND Seeding For Sale in Australia

Farm Supplies Machinery & Equipment

Sale Price

CELLI 4.91M (200-360 HP) SUPER TIGER ROTARY HOE

SPAREX OVAL HEAD BOLT SQUARE COLLAR WITH NUT - M12 X 60MM

MURRAY SERIES 03 LEVELLING HARROW 4.64M, 4 RANK DEEP SECTIONS & STD DRAWBARS-HEAVY DUTY-COMPLETE SET

MURRAY 2.28M KINKED SPRING TINE 4 RANK HARROW MEDIUM DUTY COMPLETE UNIT - SERIES 06

MURRAY SMALL ACREAGE CHAIN HARROW (1.22M X 0.76M) - SERIES 23

SPAREX ROTAVATOR TINE TWISTED (LH)

MURRAY SERIES 05 PASTURELAND LIGHT DUTY HARROW SYSTEMS - (1.52M - 6.09M) WIDTH

SPAREX ROUND COUNTERSUNK SQUARE HEX BOLT & NUT - M12 X 45MM

SPAREX SCRAPER PLATE - 140 X 75 X 3MM

SPAREX HEXAGONAL HEAD BOLT WITH NUT (TH) - M12 X 45MM

AERVATOR GH SERIES 2.4M - GH-2404 MAXI. MIN 90+ HP (3PL)

CELLI 5.41M (220-280 HP) TIGER FOLDING ROTARY HOE

Farm Supplies Machinery & Equipment

Dealer Address
