Trailed air assist 5,000 litre sprayer with 161 L/min diaphragm pump, electric controls, a Glideflex axle upgrade, wide angle shaft and Powerhead conveyor with 920mm fan.
Ideal for orchards with trees up to 5 metres high.
Specifications:
Market: Horticulture
Tank Size (L): 5000
Connection Type: Trailed
Min PTO hp: 95
Pump Size (L/min): 161
Height / Width / Length (mm): 2300 / 1880 / 5400
Product Weight (kg): 1,220 (dry)
Application: Orchards
Features:
Pump: Silvan oil-backed diaphragm type with nitrile diaphragms and corrosion resistant, cast aluminium body with brass heads & manifolds. IDS1701:161L/min. capacity, 5000kPa pressure.
Fan Size: 920mm or 1000mm axial flow type, 10 bladed fan with curved nylon reinforced blades, centrifugal clutch for soft engagement / disengagement and protective mesh cover.
Nozzles: 24 flip-over nozzle bodies for dilute/concentrate spraying with on/off. 12 Ceramic hollow cone nozzles per side and 12 ceramic jets with stainless steel swirl plates per side. (16 per side with the Radak conveyor).
Gearbox: Oil-bath type, 2-speed with neutral position
Controls: 40 Bar electric section valves with master valve, electric pressure regulator and in cab controls.
Main Tank: Polytuff impact resistant polyethylene construction with calibrated sight line. 50mm Camlock top & bottom fill.
Hand Wash Tank: 15L polytuff tank filled through cap. Located next to bottom fill.
Chemical Induction: Venturi suction probe.
Frame: Galvanised steel, heavy duty stand & adjustable drawbar.
Agitation: Pump bypass plus venturi agitator.
Pressure gauge: Glycerine filled gauge located on valve bank.
Filtration: Suction line filter, pressure filter, nozzle cap strainers.
Wheel Equipment: Glideflex axle fitted with 558-400/60 - 22.5" flotation tyres (speed rating 30 km/h)
PTO Driveshaft: Quality Bondioli & Pavesi constant velocity driveshaft with quick release pins & safety cover.
HP Required: Min 95 PTO HP
Options:
- Hydraulic kit for Radak Conveyor (top wings) (D99-155B)
- SCRAM Jet (to suit Radak conveyor) (D99-180)
- AVO Jet (to suit Radak conveyor) (D99-187)
- Leaf guard (to suit Powerhead & Radak) (D99-176)
- Double spray lines (Powerhead - includes upgrade to 1000mm fan) (D99-189)
- Double spray lines (Radak) (D99-190)
- Bravo 180S automatic rate controller (D99-143)
- Tandem suspnsion axle with 13.0/65 - 18" implement tyres (D99-191)
- IDS2001 pump,182L/min. capacity, 5000kPa pressure (D99-148)
- IDS2600 pump,249L/min. capacity, 5000kPa pressure (D99-149)
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

SILVAN 5,000L SUPAFLO TRAILED SPRAYER WITH POWERHEAD FAN - MIN 95PTO HP

Trailed over row TGS 2 row 3500 litre sprayer with 161 L/min pump, electric valve controls and 500mm twin turbine fan. Ideal for vineyards and berries. Note: infield product images are of 2 row 2000L TGS.
Specifications:
Market: Horticulture. Viticulture.
Tank Size (L): 3,500
Connection Type: Trailed
Min PTO hp: 75
Pump Size (L/min): 161
Height / Width / Length (mm): 3300 / 1800 (less head), 2800 (folded) / 5075
Product Weight (kg): 1,020 (dry)
Application: Vineyards, berries
Features:
Head: Multi row spraying head with air assist diffusers and twin spray nozzles. Each air diffuser features swivel adjustment and air deflector. Poly air tubes shaped to surround canopy. Both arms have independent hydraulic fold with manual width & height adjustment (2 tractor remote sets required).
Pump: Silvan oil-backed diaphragm type with nitrile diaphragms and corrosion resistant, cast anodised aluminium body with brass heads and manifolds. IDS1701: 161L/min. capacity 5000kPa pressure. IDS2001: 182L/min. capacity 5000kPa pressure.
Fan Size: 500mm twin impeller turbine fan, power consumed 48 kw (64HP).
Nozzles: Twin hollow cone ceramic nozzles per outlet with individual on/off non-drip taps.
Gearbox: 2-speed with neutral position, oil-bath type
Controls: 40 Bar electric section valves, master valve, electric pressure regulator and in cab controls
Frame: Galvanised steel chassis, adjustable drawbar with jockey wheel.
Tank: Polytuff impact resistant polyethylene construction, calibrated sight line, flip top easy open lid, 50mm camlock bottom fill and 40L fresh water hand wash tank.
Chem Induction: Suction probe with detachable hose.
Agitation: Pump bypass plus venturi agitator.
Pressure Gauge: 0-60 bar glycerine filled gauge fitted to pump.
Filtration: Lid strainer and large capacity suction filter.
Wheel Equipment: Tandem simplicity suspension with 10 x 15" wheels & tyres. (2000L & 3000L) or 11.5 x 15.3" wheels & tyres (3500L & 4000L)
PTO Driveshaft: Quality Bondioli & Pavesi driveshaft with quick release pins and safety cover.
HP Required: Minimum 75 PTO HP
Options:
- IDS2600 pump, 249L/min capacity, 5000kPa pressure (D99-149)
- Bravo 180S automatic rate controller (D99-143)
- Vertical lift head assembly (1 extra set of tractor remotes required) (TGS-LIFT)
- Quick turning hitch (D99-170)
- Hydraulic row width adjustment (1 extra set of tractor remotes required) (D99-186)
- Road kit (D99-151)
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN 3,500L (2 ROW) TGS TRAILED SPRAYER - MIN 75PTO HP

Trailed over row P55DSE 2 row 3,500 litre turbowrap sprayer with a hydraulic drive 350 L/min stainless steel pump, 550mm turbine fan, sprayheads, automatic spray rate controller, wide angle shaft and tandem suspension axle.
Ideal for vineyards.
Specifications:
Market: Viticulture.
Tank Size (L): 3,500
Connection Type: Trailed
min PTO hp: 70
Pump Size (L/min): 350
Height / Width / Length (mm): 3630 / 1935 (less head), 2605 (folded) / 5640
Product Weight (kg): 1,100 (dry)
Application: Vineyards
Features:
Head: Two row spraying head: 28 venturi air shear adjustable nozzles with individual metering and on/off taps. Three row spraying head: 42 venturi air shear adjustable nozzles with individual metering and on/off taps. Left & right arms are independent hydraulic folding with adjustable width & centre frame. Boom frame is galvanised.
Pump: Stainless steel, hydraulic drive centrifugal pump, 350 L/min. Stainless steel shaft and Viton/ceramic seal.
Fan Size: P55DSE: 550mm dia. turbine fan, 3700 rpm. Power consumed 50 kw / 67HP.
Nozzles: Air shear.
Gearbox: Multiplication type through multi-grip, multi-vee belt and pulley, over-run free wheeling hub and oil bath fan housing.
Controls: Electric section valves with Bravo 180S automatic rate controller. Large 100mm pressure gauge.
Frame: Galvanised steel chassis, adjustable drawbar with jockey wheel.
Tank: Polytuff impact resistant polyethylene construction, calibrated sight line, flip top easy open lid, 50mm camlock bottom fill and 40L fresh water hand wash tank.
Chem Induction: Suction probe with detachable hose.
Agitation: Venturi agitator.
Filtration: Lid strainer and large capacity suction filter.
Wheel Equipment: Tandem simplicity suspension with 10 x 15" wheels & tyres. (2000L) or 11.5 x 15.3" wheels & tyres (3500L)
PTO Driveshaft: Quality Bondioli & Pavesi driveshaft with quick release pins and safety cover.
HP Required: Minimum 70 PTO HP (2 row), Minimum 90 PTO HP (3 row).
Options:
- Quick turning hitch (D99-170)
- Hydraulic row width/height adjustment
- Bravo 180S spray rate controller with hydraulic controls (in lieu) (J99-180)
- Road kit (D99-151)
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN 3,500L (2 ROW) P55DSE TRAILED TURBOWRAP - MIN 70PTO HP

Specifications:
Market: Viticulture.
Tank Size = 2,000 L
Connection Type: Trailed
Min PTO hp: 60
Pump Size : 500+ LPM
Application: Vineyards
Dimensions - Length measured with linkage hitch:
Length: 4,680 mm
Width Less Head: 1,800 mm
Width Folded: 2,490 mm
Height: 3,330 mm
Weight 990 kg (Dry)
Includes spray heads, independent 320mm hydraulic fans, hydraulic drive stainless steel pump, automatic spray rate controller, self contained hydraulic drive system and tandem suspension axle. Ideal for vineyards.
Model Specifications
- Head Two row spraying head: 28 venturi air shear adjustable nozzles with individual metering and on/off taps. Left and right arms are independent hydraulic folding with adjustable width and centre frame. Boom frame is galvanised.
- Pump Multi-stage hydraulic drive pump, multiple impellers made with highly resistant engineering plastic for excellent chemical compatibility. 500+L/min. Driven by tractor remotes.
- Fan Size 320mm turbine fan, one per air tube, 3600rpm. Power consumed 29kw/38HP.
- Hydraulic Control Hitch mounted hydraulic power pack with: 40L oil reservoir with cartridge particulate filter, motors fitted with case drain, hydraulic distribution block incorporates anti-cavitation and pressure relief valves, 12V oil cooler.
- Nozzles Air shear.
- Controls Electric section valves with Bravo 180S automatic rate controller. Large 100mm pressure gauge.
- Tank Polytuff impact resistant polyethylene construction, calibrated sight line, flip top easy open lid, 50mm camlock bottom fill and 40L fresh water hand wash tank.
- Frame Galvanised steel chassis, linkage hitch fitted with hydraulic power pack.
- Agitation Venturi agitator.
- Filtration Lid strainer and large capacity suction filter.
- Wheel Equipment Tandem suspension with 10x15inch wheels and tyres.
- PTO Driveshaft Quality Bondioli & Pavesi driveshaft with quick release pins and safety cover.
- HP Required Minimum 60 PTO HP
Factory Options
- Hydraulic pump driven through power pack.
- Hydraulic Height Adjustment phased or independent.
- Hydraulic Row width adjustment phased or independent.
- Bravo 180S spray rate controller with hydraulic controls (in lieu) up to 5 sections.
- Bravo 180S spray rate controller with hydraulic controls (in lieu) 7 sections.
- Bravo 400S automatic rate controller with GPS guidance (in lieu) 7 spray sections.
- Bravo 400S automatic rate controller with hydraulic controls, GPS guidance (in lieu) 7 spray sections + 7 hydraulic sections.
- IBX 100 ISOBUS controller (in lieu requires compatible in-cab console).
- Delta 80 Universal Terminal to suit ISOBUS control.
- Quick turning hitch.
- Electric braked tandem suspension axle via trailer plug in lieu of standard axle.
- Hydraulic braked tandem suspension axle in lieu requires compatible tractor remotes.
- 100L Flush Tank
- Road Kit Brake and indicator lights with folding Oversize sign.
- Tail Light Kit Brake and indicator lights via trailer plug.
NOTE: Not all options will fit all models. Extra charges may apply to fitment of some options.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available
Contact Farm Supplies today for sale or more information
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN 2,000L (2 ROW) TRAILED SCRAM CROSS - MIN 60PTO HP

Trailed 2,000 litre herbicide sprayer with 132 L/min pump (with under-vine and mid row booms). Designed for spraying herbicide in vineyards.
Specifications:
Market: Viticulture
Tank Size (L): 2000
Connection Type: Trailed
Pump Size (L/min): 132
Height / Width / Length (mm): 3300 / 1800 / 4600
Product Weight (kg): 990
Application: Herbicide sprayer for vineyards
Features:
Pump: Silvan self-priming oil-backed diaphragm type with nitrile diaphragms & corrosion resistant, cast anodised aluminium body. BP130/20: 132 L/min. capacity 2000kPa pressure.
Controls: Silvamatic 3 section electric valve on/off with in-cab electric pressure adjustment from control box.
Tank: Polytuff impact resistant polyethylene construction, calibrated sight line & flip-top easy open lid.
Frame: Galvanised RHS steel construction, jockey wheel & adjustable tow hitch.
Agitation: Bypass action.
Pressure Gauge: 0-25 Bar dual stage glycerine filled gauge.
Filtration: Lid strainer & suction line strainer.
Wheels: SINGLE ROW: 50mm Duraflex axle with 50mm drop and sliding adjustment. 15" tyres on galvanised rims (max. speed rating 30 km/h). 3 ROW: Tandem suspension axle with 10 x 15" wheels.
PTO Driveshaft: Quality driveshaft with quick release pins & safety cover.
Options:
- Undervine and mid row boom (to suit JB2000-125)
- Bravo 180S automatic spray rate controller
- Hydraulic drive centrifugal pump
- Hydraulic row width and height adjustment
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

SILVAN 2,000L TRAILED VINEYARD HERBICIDE SPRAYER (3 ROW)

High capacity sprayer with a 12m galvanised boom and hose reel for field and spot spraying in one package.
Specifications:
Tank Size (L): 800
Connection Type: Linkage
Pump Size (L/min): 132
Height / Width / Length (mm): 2600 / 2200 / 1930
Product Weight (kg): To be confirmed.
Features:
Pump: Silvan self-priming oil-backed diaphragm type with nitrile diaphragms and cast anodised aluminium body. BP130/20: 132 L/min. capacity 2000kPa pressure.
Boom: 12m Fieldmaster boom with stainless steel spraylines, non-drip nozzle holders, fully galvanised frame, nozzle protection, spring loaded safety break back/forward and suspension.
Nozzles: Air induction nozzles with strainer in bayonet fit non-drip nozzle holders at 50cm spacings.
Controls: 1 lever, 4 outlet control valves with pressure regulator.
Tank: Polytuff impact resistant polyethylene construction, moulded litre calibrations and non-spill screw-down lid with single breather.
Frame: Fully galvanised steel. 800L model : Cat I & II linkage 1000L model : Cat II linkage
Agitation: Bypass agitation.
Pressure Gauge: 0-25 Bar dual stage glycerine filled gauge.
Filtration: Lid strainer, suction line strainer and nozzle strainers.
Hose Reel: Fitted with rear-mounted hosereel, 20m of 12mm hose and JetPro spraygun with trigger action pattern adjustment.
PTO Driveshaft: Quality driveshaft with quick release pins & safety cover.
Options:
- 14L foam marker (single side)
- 16L foam marker (double side)
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN 800L (12M GALVANISED BOOM) ECONOMAX LINKAGE SPRAYER

Linkage 1,100 litre Cane Boom sprayer with 71 L/min pump, NO boom.
Model Specifications:
Market: Dairy & Livestock. Sugarcane.
Tank Size (L): 1,100
Connection Type: Linkage
Pump Size (L/min): 71
Height / Width / Length (mm): 1610 / 1395 / 1350
Product Weight (kg): 160
Application: Sugarcane spraying.
Features:
Pump: Silvan self-priming oil-backed diaphragm type with nitrile diaphragms and corrosion resistant, cast anodised aluminium body. BP60/20: 58 L/min. capacity 2000kPa pressure. BP75/20: 71 L/min. capacity 2000kPa pressure. BP130/20: 132 L/min. capacity 2000kPa pressure.
Controls: Cane boom: 4 row or 6 row. Fully galvanised construction, to suit row widths from 1.5 - 1.8m with 500-1300mm shield spray head and brush skirts or spider spray head. Spray heads have heavy duty hinges to withstand drag, parallelogram tracking system.
Nozzles: 2 x twin nozzle bodies per shielded spray head and air induction nozzles.
Controls: 4 outlet single lever control valve with pressure regulation and gauge.
Tank: Low profile 600/800/1100L Polytuff impact resistant polyethylene construction, external sightline with floating ball and non-spill offset screw-down lid with single breather. 15L freshwater tank with screw-down lid and on/off tap. 4L toolbox with polyethylene lid. 50mm Camlock bottom fill and venturi chemical suction probe (1100L only).
Frame: Fully galvanised steel, cat II adjustable hitch.
Agitation: Bypass agitation.
Pressure Gauge: 0-25 Bar dual stage glycerine filled gauge.
Filtration: Lid strainer, suction line strainer.
PTO Driveshaft: Quality driveshaft with quick release pins & safety cover.
Boom Options:
- 4 row cane boom (spider) (035-4NL)
- 4 row cane boom (shielded) (035-4N)
- 6 row cane boom (spider) (035-6NL)
- 6 row cane boom (shielded) (035-6N)
- Broadacre boom attachment (to suit 4 row) (035-4B)
- Broadacre boom attachment (to suit 6 row) (035-6B)
- Hydraulic lift, galvanised single hydraulic system (032-40DL)
Factory Options:
- 70L flush tank kit to flush the filter, spraylines and nozzles (K99-47)
- Electric control 3 section with in cab pressure adjustment (K99-29)
- Electric control 4 section with in cab pressure adjustment (K99-49)
- Electric control 5 section with in cab pressure adjustment (K99-50)
- Bravo 180S automatic rate controller (J99-151)
- Silmix chemical hopper (K99-21)
- Additional model available K08N-125C with 121L/min (BP125/20) pump.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN 1,100L CANE BOOM SPRAYER - BP75/20 PUMP, NO BOOM

Trailed over row G2E TGS 2 row 4000 litre sprayer with 182 L/min pump, 500mm twin turbine fan and electric valve controls. Ideal for vineyards.
Note: infield images show the 3 row 4000L G2E TGS.
Specifications:
Market: Viticulture.
Tank Size (L): 4,000
Connection Type: Trailed
Min PTO hp: 75
Pump Size (L/min): 182
Height / Width / Length (mm): 3160 / 1935 (less head), 2490 (folded) / 5340
Product Weight (kg): 1,820 (dry)
Application: Vineyards
Features:
Head: Multi row spraying head with air assist diffusers and twin spray nozzles. Each air diffuser features swivel adjustment and air deflector. Poly air tubes shaped to surround canopy. Both arms have independent hydraulic fold with manual width & height adjustment (2 tractor remote sets required).
Pump: Silvan oil-backed diaphragm type with nitrile diaphragms and corrosion resistant, cast anodised aluminium body with brass heads and manifolds. IDS1701: 161L/min. capacity 5000kPa pressure. IDS2001: 182L/min. capacity 5000kPa pressure.
Fan Size: 500mm twin impeller turbine fan, power consumed 48 kw (64HP).
Nozzles: Twin hollow cone ceramic nozzles per outlet with individual on/off non-drip taps.
Gearbox: 2-speed with neutral position, oil-bath type
Controls: 40 Bar electric section valves, master valve, electric pressure regulator and in cab controls
Frame: Galvanised steel chassis, adjustable drawbar with jockey wheel.
Tank: Polytuff impact resistant polyethylene construction, calibrated sight line, flip top easy open lid, 50mm camlock bottom fill and 40L fresh water hand wash tank.
Chem Induction: Suction probe with detachable hose.
Agitation: Pump bypass plus venturi agitator.
Pressure Gauge: 0-60 bar glycerine filled gauge fitted to pump.
Filtration: Lid strainer and large capacity suction filter.
Wheel Equipment: Tandem simplicity suspension with 10 x 15" wheels & tyres. (2000L & 3000L) or 11.5 x 15.3" wheels & tyres (3500L & 4000L)
PTO Driveshaft: Quality Bondioli & Pavesi driveshaft with quick release pins and safety cover.
HP Required: Minimum 75 PTO HP
Options:
- IDS2600 pump, 249L/min capacity, 5000kPa pressure (D99-149)
- Bravo 180S automatic rate controller (D99-143)
- Vertical lift head assembly (1 extra set of tractor remotes required) (TGS-LIFT)
- Quick turning hitch (D99-170)
- Hydraulic row width adjustment (1 extra set of tractor remotes required) (D99-186)
- Road kit (D99-151)
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN 4,000L (2 ROW) G2E TGS TRAILED SPRAYER - MIN 75PTO HP

Linkage 600L Pasturepak sprayer with 58 L/min pump, reel, hose & gun and 6m Field boom. Ideal for pasture spraying.
Specifications:
Market: Dairy & Livestock
Tank Size (L): 600
Connection: Linkage
Pump Size (L/min): 58
Height / Width / Length (mm): 1300 / 2067 / 1350
Product Weight (kg): 180
Application: Pasture spraying.
Features:
Pump: Silvan self-priming oil-backed diaphragm type with nitrile diaphragms and corrosion resistant, cast anodised aluminium body with raised pump mount. BP60/20: 58 L/min. capacity 2000kPa pressure. BP75/20: 71 L/min. capacity 2000kPa pressure.
Boom: Field boom with stainless steel spray lines, non-drip nozzle holders, fully galvanised frame, nozzle protection and spring loaded safety break back/forward.
Nozzles: Air induction nozzles with strainer in bayonet fit non-drip nozzle holders at 50cm spacings.
Controls: 3 outlet manual control valve with pressure regulator. Mounted forward for easy access.
Tank: Low profile, 400/600/800L polytuff impact resistant polyethylene construction, external sightline with floating ball and non-spill offset screw-down lid with single breather. 15L fresh water tank with screw down lid and on/off tap. 4L toolbox with polyethylene lid.
Frame: Fully galvanised steel, cat I & II linkage on 400L, cat II linkage on 600L and 800L.
Agitation: Bypass agitation.
Pressure Gauge: 0-25 Bar dual stage glycerine filled gauge.
Filtration: Lid strainer, suction line strainer and nozzle strainers.
Hose Reel: Fitted with rear-mounted Eco hosereel, 30m of 10mm hose and Spotjet spraygun with adjustable spray nozzle.
PTO Driveshaft: Quality driveshaft with quick release pins & safety cover.
Options:
- 14L foam marker (single side)
- 16L foam marker (double side)
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN 600L (6M BOOM) PASTUREPAK LINKAGE SPRAYER

Linkage 1,100 litre Casotti sprayer with 71 L/min pump and Casotti kit. Ideal for pasture spraying.
Specifications:
Market: Ag Lifestyle. Dairy & Livestock.
Tank Size (L): 1,100
Connection Type: Linkage
Pump Size (L/min): 71
Height / Width / Length (mm): 1610 / 1395 / 1350
Product Weight (kg): 160
Application: Pasture spraying
Features:
Pump: Silvan oil-backed diaphragm type with nitrile diaphragms and corrosion resistant, cast anodised aluminium body. APS71: 71L/min. capacity 5000kPa pressure.
Casotti Motor: An electric 12 volt motor is connected to the tractor battery which powers the oscillating movement of the nozzle arms. The arms swing 180º. This movement is symmetrical to the tractors passage.
Controls: 2 outlet brass manual control valve with pressure regulator. Mounted forward for easy access.
Tank: Low profile 600/800/1100L Polytuff impact resistant polyethylene construction, external sightline with floating ball and non-spill offset screw-down lid with single breather. 15L freshwater tank with screw-down lid and on/off tap. 4L toolbox with polythylene lid. 50mm Camlock bottom fill (1100L only).
Frame: Fully galvanised steel, cat II linkage.
Agitation: Bypass agitation.
Pressure Gauge: 0-60 Bar dual stage glycerine filled gauge.
Filtration: Lid strainer, suction line strainer with stop valve fitted at side of tank to enable ease of filter maintenance.
PTO Driveshaft: Quality driveshaft with quick release pins & safety cover.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN 1,100L CASOTTI LINKAGE SPRAYER

Linkage 600L Superpak sprayer with 58 L/min pump and 6m hydraulic boom. Ideal for pasture spraying.
Specifications:
Market: Dairy & Livestock
Tank Size (L): 600
Connection Type: Linkage
Pump Size (L/min): 58
Height / Width / Length (mm): 1950 / 2067 / 1350
Product Weight (kg): 165
Application: Pasture spraying
Features:
Pump: Silvan self-priming oil-backed diaphragm type with nitrile diaphragms and corrosion resistant, cast anodised aluminium body with raised pump mount. BP60/20: 58 L/min. capacity 2000kPa pressure.
Boom: Hydraulic boom: 6m independent hydraulic fold boom (requires two sets of tractor remotes) with stainless steel spray lines, non-drip nozzle holders, fully galvanised frame, nozzle protection and spring loaded safety break back.
Nozzles: Air induction nozzles with strainer in bayonet fit non-drip nozzle holders at 50cm spacings.
Controls: 3 outlet manual control valve with pressure regulator. Mounted forward for easy access.
Tank: Low profile, 400/600/800L polytuff impact resistant polyethylene construction, external sightline with floating ball and non-spill offset screw-down lid with single breather. 15L fresh water tank with screw down lid and on/off tap. 4L toolbox with polyethylene lid.
Frame: Fully galvanised steel, cat I & II linkage on 400L, cat II linkage on 600L.
Agitation: Bypass agitation.
Pressure Gauge: 0-25 Bar dual stage glycerine filled gauge.
Filtration: Lid strainer, suction line strainer with stop valve fitted at side of tank to enable easy filter maintenance and nozzle cup strainers.
PTO Driveshaft: Quality driveshaft with quick release pins & safety cover.
Options:
- 14L foam sprayer (single side)
- 16L foam sprayer (double side)
- Electric on/off control 3 section
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN 600L (6M HYDRAULIC FOLD BOOM) SUPERPAK LINKAGE SPRAYER

Trailed 3,000 litre herbicide sprayer with 132 L/min pump (with under-vine and mid row booms). Designed for spraying herbicide in vineyards.
Specifications:
Market: Viticulture
Tank Size (L): 3000
Connection Type: Trailed
Pump Size (L/min): 132
Height / Width / Length (mm): 3300 / 1800 / 4600
Product Weight (kg): 990
Application: Herbicide sprayer for vineyards
Features:
Pump: Silvan self-priming oil-backed diaphragm type with nitrile diaphragms & corrosion resistant, cast anodised aluminium body. BP130/20: 132 L/min. capacity 2000kPa pressure.
Controls: Silvamatic 3 section electric valve on/off with in-cab electric pressure adjustment from control box.
Tank: Polytuff impact resistant polyethylene construction, calibrated sight line & flip-top easy open lid.
Frame: Galvanised RHS steel construction, jockey wheel & adjustable tow hitch.
Agitation: Bypass action.
Pressure Gauge: 0-25 Bar dual stage glycerine filled gauge.
Filtration: Lid strainer & suction line strainer.
Wheels: SINGLE ROW: 50mm Duraflex axle with 50mm drop and sliding adjustment. 15" tyres on galvanised rims (max. speed rating 30 km/h). 3 ROW: Tandem suspension axle with 10 x 15" wheels.
PTO Driveshaft: Quality driveshaft with quick release pins & safety cover.
Options:
- Undervine and mid row boom (to suit JB2000-125)
- Bravo 180S automatic spray rate controller
- Hydraulic drive centrifugal pump
- Hydraulic row width and height adjustment
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

SILVAN 3,000L TRAILED VINEYARD HERBICIDE SPRAYER (3 ROW)

Find Sprayers For Sale. Browse 693 Sprayers listings from Farm Supplies Machinery & Equipment.

New & Used Sprayers For Sale in Australia

Farm Supplies Machinery & Equipment

Sale Price

SILVAN 5,000L SUPAFLO TRAILED SPRAYER WITH POWERHEAD FAN - MIN 95PTO HP

SILVAN 3,500L (2 ROW) TGS TRAILED SPRAYER - MIN 75PTO HP

SILVAN 3,500L (2 ROW) P55DSE TRAILED TURBOWRAP - MIN 70PTO HP

SILVAN 2,000L (2 ROW) TRAILED SCRAM CROSS - MIN 60PTO HP

SILVAN 2,000L TRAILED VINEYARD HERBICIDE SPRAYER (3 ROW)

SILVAN 800L (12M GALVANISED BOOM) ECONOMAX LINKAGE SPRAYER

SILVAN 1,100L CANE BOOM SPRAYER - BP75/20 PUMP, NO BOOM

SILVAN 4,000L (2 ROW) G2E TGS TRAILED SPRAYER - MIN 75PTO HP

SILVAN 600L (6M BOOM) PASTUREPAK LINKAGE SPRAYER

SILVAN 1,100L CASOTTI LINKAGE SPRAYER

SILVAN 600L (6M HYDRAULIC FOLD BOOM) SUPERPAK LINKAGE SPRAYER

SILVAN 3,000L TRAILED VINEYARD HERBICIDE SPRAYER (3 ROW)

Farm Supplies Machinery & Equipment

Dealer Address
