O.D = 1 "
Maintaining a leak free and smooth liquid flow by using quality components and fittings is essential for maximum performance from all installations.
Selectas range of fittings are manufactured from high quality polypropylene and are compatible with fungicides, herbicides, chemical fertilisers etc, and will withstand temperatures of up to 100ºC.
Standard BSP male and female threads can be used in conjunction with each other to construct assorted types and sizes of inlets, outlets, suction fittings and hose unions or they can be used with standard brass, galvanised and other fittings.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN 1" O-RING (O.D)

Linkage 800 litre Slimline sprayer with 132 L/min pump, NO boom.
Specifications:
Market: Ag Lifestyle. Dairy & Livestock.
Tank Size (L): 800
Connection Type: Linkage
Pump Size (L/min): 132
Height / Width / Length (mm): 1370 / 980 / 1330
Product Weight (kg): 120
Application: Pasture and Ag Lifestyle spraying.
Features:
Pump: Silvan self-priming oil-backed diaphragm type with nitrile diaphragms and corrosion resistant, cast anodised aluminium body with raised pump mount (1000L only). BP60/20: 58L/min. capacity 2000kPa pressure. BP130/20: 132 L/min. capacity 2000kPa pressure.
Controls: BP60/20: 3 outlet control valve with pressure regulation. BP130/20: 1 lever, 4 outlet control valve with pressure regulation.
Tank: Polytuff impact resistant polyethylene construction, moulded litre calibrations and non spill screw-down lid with single breather.
Frame: 800L model: Galvanised steel, cat. 1 & II linkage. 1000L model: Galvanised steel with adjustable cat II hitch system. Vertical boom channel for positioning the boom at the optimum spray height.
Agitation: Bypass agitation.
Pressure Gauge: 0-25 Bar dual stage glycerine filled gauge.
Filtration: Lid strainer, suction line strainer.
PTO Driveshaft: Quality driveshaft with quick release pins & safety cover.
Options:
- 6m Field boom
- 8m Field boom
- 10m Field boom
- 12m Fieldmaster boom with suspension (1000L only)
- 6m Hydraulic fold boom
- 8m Devil boom with hydraulic fold
- 10m HD Devil boom with hydraulic fold
- 12m HD Devil boom with hydraulic fold
- 14mHD Devil boom with hydraulic fold
- 15m HD Devil boom with hydraulic fold
- Hydraulic lift, galvanised single hydraulic system - 10, 12, 14 & 15m devil booms
- Hydraulic lift, with airbag suspension - 10, 12, 14 & 15m HD devil booms
- Parellelogram airbag suspension - 10, 12, 14 & 15m HD devil booms (no hydraulic lift)
- 8 Jet vine boom
- 10 Jet vine boom
- Olive boom (Used with BP130/20 pump only)
- Undervine & mid row boom
- 70L flush tank kit to flush the filter, spraylines and nozzles (1000L only)
- 16L foam marker (double side)
- 57L Paddock marker foam marker
- Economy hosereel, 20m hose (12mm ID) & Jetpro spraygun
- Electric control 3 section with in cab pressure adj
- Bravo 180S automatic rate controller
- Silmix chemical hopper
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN 800L SLIMLINE LINKAGE SPRAYER - BP130/20 PUMP, NO BOOM

ID = 10 mm
OD = 3/4 "
Maintaining a leak free and smooth liquid flow by using quality components and fittings is essential for maximum performance from all installations.
Selectas range of fittings are manufactured from high quality polypropylene and are compatible with fungicides, herbicides, chemical fertilisers etc, and will withstand temperatures of up to 100ºC.
Standard BSP male and female threads can be used in conjunction with each other to construct assorted types and sizes of inlets, outlets, suction fittings and hose unions or they can be used with standard brass, galvanised and other fittings.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN 10MM (ID) FLAT GASKET

Manufactured from high quality brass and can be used in conjunction with BSP fittings.
Hose Size = 12.5 mm
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

SILVAN 12.5 MM BRASS HOSE CONNECTOR (NUT & ELBOW)

1,300L Linkage sprayer with BP130/20, 132 L/min diaphragm pump.
Specifications:
Tank Size (L): 1,300
Connection Type: Linkage
Pump Size (L/min): 132
Height / Width / Length (mm): 2140 / 2300 / 1480
Product Weight (kg): 635
Features:
Pump: Silvan self-priming oil-backed diaphragm type with nitrile diaphragms and corrosion resistant, cast anodised aluminium body with raised pump mount. BP130/20: 132 L/min. capacity 2000kPa pressure.
Controls: 3 section Silvamatic electric controls with pressure compensating direct acting valves. On/off and pressure adjustment in cab.
Tank: Polytuff impact resistant polyethylene construction, external sightline with floating ball and non-spill offset screw-down lid with single breather. 10L hand wash tank with screw-down lid and on/off tap. 150L flush tank with screw down lid and external sightline. 50mm Camlock bottom fill.
Frame: Galvanised steel, with adjustable cat II & cat III hitch. Vertical boom channel positions boom at optimum spray height.
Agitation: Bypass agitation.
Chemical Induction: 30L Silmix chemical hopper mounted on side of tank.
Pressure Gauge: 0-25 Bar dual stage glycerine filled gauge.
Filtration: Lid strainer, suction line strainer with stop valve fitted at the side of the tank to enable ease of filter maintenance.
PTO Driveshaft: Quality driveshaft with quick release pins & safety cover.
Options:
- BP200/20 pump, 195L/min. capacity, 2000kPa pressure
- Hydraulic drive centrifugal pump
- 10m HD Devil boom with hydraulic fold
- 12m HD Devil boom with hydraulic fold
- 14m HD Devil boom with hydraulic fold
- 15m HD Devil boom with hydraulic fold
- Hydraulic lift, galvanised single hydraulic system - 10, 12, 14 & 15m HD Devil booms
- Parellelogram airbag suspension - 10, 12, 14 & 15m HD Devil booms (no hydraulic lift)
- 57L Paddock marker foam marker
- Bravo 180S automatic rate controller
- Bravo 400S automatic rate controller with GPS guidance (in lieu)
- IBX 100 ISOBUS controller (in lieu - requires compatible in-cab console)
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available
Contact Farm Supplies today for sale or more information
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN 1,300L SUPER LINKAGE SPRAYER - BP130/20 PUMP, NO BOOM

Maintaining a leak free and smooth liquid flow by using quality components and fittings is essential for maximum performance from all installations.
Selectas range of fittings are manufactured from high quality polypropylene and are compatible with fungicides, herbicides, chemical fertilisers etc, and will withstand temperatures of up to 100ºC.
Standard BSP male and female threads can be used in conjunction with each other to construct assorted types and sizes of inlets, outlets, suction fittings and hose unions or they can be used with standard brass, galvanised and other fittings.
Suit Hose Size of 12.5 mm
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

SILVAN BARBED TEE PIECE (SUIT 12.5 MM HOSE)

Size = 1 1/4 "
Suits 30mm hose
Maintaining a leak free and smooth liquid flow by using quality components and fittings is essential for maximum performance from all installations.
Selectas range of fittings are manufactured from high quality polypropylene and are compatible with fungicides, herbicides, chemical fertilisers etc, and will withstand temperatures of up to 100ºC.
Standard BSP male and female threads can be used in conjunction with each other to construct assorted types and sizes of inlets, outlets, suction fittings and hose unions or they can be used with standard brass, galvanised and other fittings.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN 1 1/4" HOSETAIL (SUIT 30MM HOSE)

ID = 2 "
Maintaining a leak free and smooth liquid flow by using quality components and fittings is essential for maximum performance from all installations.
Selectas range of fittings are manufactured from high quality polypropylene and are compatible with fungicides, herbicides, chemical fertilisers etc, and will withstand temperatures of up to 100ºC.
Standard BSP male and female threads can be used in conjunction with each other to construct assorted types and sizes of inlets, outlets, suction fittings and hose unions or they can be used with standard brass, galvanised and other fittings.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN 2" (ID) FLAT GASKET

Trailed over row TGS 3 row 3500 litre sprayer with 161 L/min pump, electric valve controls and 500mm twin turbine fan. Ideal for vineyards and berries. Note: infield product images are of 2 row 2000L TGS.
Specifications:
Market: Horticulture. Viticulture.
Tank Size (L): 3,500
Connection Type: Trailed
Min PTO hp: 75
Pump Size (L/min): 161
Height / Width / Length (mm): 3300 / 1800 (less head), 2800 (folded) / 5075
Product Weight (kg): 1,020 (dry)
Application: Vineyards, berries
Features:
Head: Multi row spraying head with air assist diffusers and twin spray nozzles. Each air diffuser features swivel adjustment and air deflector. Poly air tubes shaped to surround canopy. Both arms have independent hydraulic fold with manual width & height adjustment (2 tractor remote sets required).
Pump: Silvan oil-backed diaphragm type with nitrile diaphragms and corrosion resistant, cast anodised aluminium body with brass heads and manifolds. IDS1701: 161L/min. capacity 5000kPa pressure. IDS2001: 182L/min. capacity 5000kPa pressure.
Fan Size: 500mm twin impeller turbine fan, power consumed 48 kw (64HP).
Nozzles: Twin hollow cone ceramic nozzles per outlet with individual on/off non-drip taps.
Gearbox: 2-speed with neutral position, oil-bath type
Controls: 40 Bar electric section valves, master valve, electric pressure regulator and in cab controls
Frame: Galvanised steel chassis, adjustable drawbar with jockey wheel.
Tank: Polytuff impact resistant polyethylene construction, calibrated sight line, flip top easy open lid, 50mm camlock bottom fill and 40L fresh water hand wash tank.
Chem Induction: Suction probe with detachable hose.
Agitation: Pump bypass plus venturi agitator.
Pressure Gauge: 0-60 bar glycerine filled gauge fitted to pump.
Filtration: Lid strainer and large capacity suction filter.
Wheel Equipment: Tandem simplicity suspension with 10 x 15" wheels & tyres. (2000L & 3000L) or 11.5 x 15.3" wheels & tyres (3500L & 4000L)
PTO Driveshaft: Quality Bondioli & Pavesi driveshaft with quick release pins and safety cover.
HP Required: Minimum 75 PTO HP
Options:
- IDS2600 pump, 249L/min capacity, 5000kPa pressure (D99-149)
- Bravo 180S automatic rate controller (D99-143)
- Vertical lift head assembly (1 extra set of tractor remotes required) (TGS-LIFT)
- Quick turning hitch (D99-170)
- Hydraulic row width adjustment (1 extra set of tractor remotes required) (D99-186)
- Road kit (D99-151)
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

SILVAN 3,500L (3 ROW) TGS TRAILED SPRAYER - MIN 75PTO HP

2,500L Paddock Pak. BP130/20 pump, 3 section electric valve controls, 18m boom.
Specifications:
Tank Size (L): 2,500
Connection Type: Trailed
Pump Size (L/min): 132
Height / Width / Length (mm): 2870 / 2500 / 5400
Product Weight (kg): 1400
Features:
Pump: Silvan self-priming oil backed diaphragm pump. BP130/20: 132 L/min. capacity 2000kPa pressure.
Boom: Hydraulic lift, fold and tilt with parallel arm boom suspension, nitrogen accumulator and spring-loaded breakbacks. Galvanised boom with stainless steel spraylines. Minimum 3 sets of hydraulic remotes required.
Controls: 3 section Silvamatic electric controls with pressure compensating direct acting valves. In cab on/off & pressure adjustment with pressure gauge.
Tank: Polytuff impact resistant polyethylene construction with calibrated sight line & non-spill screw down lid.
Flush Tank: 100L
Frame: Galvanised RHS steel construction with adjustable drawbar and operator platform.
Agitation: 2 stage agitation. Bypass action and Venturi agitation.
Filtration: Lid strainer, suction line filter.
Wheel Equipment: 2m track axle with 14.9 x 24" lug tyre
Bottom Fill: Bottom fill valve with camlock coupling.
Options:
- BP200/20 pump, 195 L/min. capacity, 2000kPa pressure
- Hydraulic drive centrifugal pump
- 5 section Silvamatic electric controls (in lieu)
- Bravo 180S automatic rate controller (in lieu)
- Bravo 180S automatic rate controller to suit hydraulic control (in lieu)
- Bravo 400S automatic rate controller with GPS guidance (in lieu)
- IBX 100 ISOBUS controller (in lieu - requires compatible in-cab console)
- Mudguards (to suit 14.9 x 24 wheels)
- Adjustable track axle (minimum 1500mm) with 11.2 x 44 Lug tyres (2500L only)
- 57L Paddock Foam Marker
- Venturi suction probe
- Silmix Chemical Hopper
- 3 Section electric over hydraulic control
- 5 Section electric over hydraulic control
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN 2,500L PADDOCK PAK TRAILED SPRAYER (18M BOOM)

Check Valve Kit to suit 2088 series pumps with Viton Valve Kits
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

SILVAN CHECK VALVE KIT TO SUIT 2088 SERIES PUMPS (VITON)

Linkage 1100 litre Super sprayer with 71 L/min pump, without boom. Ideal for pasture spraying.
Specifications:
Market: Dairy & Livestock
Tank Size (L): 1,100
Connection Type: Linkage
Pump Size (L/min): 71
Height / Width / Length (mm): 1610 / 1395 / 1350
Product Weight (kg): 160
Application: Pasture and ag lifestyle.
Features:
Pump: Silvan self-priming oil-backed diaphragm type with nitrile diaphragms and corrosion resistant, cast anodised aluminium body with raised pump mount. BP75/20: 71L/min. capacity 2000kPa pressure. BP130/20: 132 L/min. capacity 2000kPa pressure.
Controls: 3 outlet manual control valve with pressure regulator.
Tank: Low profile, 800 and 1100L Polytuff impact resistant polyethylene construction, external sightline with floating ball and non-spill offset screw-down lid with single breather. 15L freshwater tank with screw-down lid and on/off tap. 4L toolbox with polyethylene lid. 50mm Camlock bottom fill (1100L only).
Frame: Galvanised steel, with adjustable cat II hitch. Vertical boom channel positions boom at optimum spray height.
Chemical Induction: 1100L: Venturi suction probe with detachable hose.
Agitation: Bypass agitation.
Pressure Gauge: 0-25 Bar dual stage glycerine filled gauge.
Filtration: Lid strainer, suction line strainer with stop valve fitted at the side of the tank to enable ease of filter maintenance.
PTO Driveshaft: Quality driveshaft with quick release pins & safety cover.
Options:
- 6m Field boom
- 8m Field boom
- 10m Field boom
- 12m Fieldmaster boom with suspension
- 6m Hydraulic fold boom
- 8m Devil boom with hydraulic fold
- 10m HD Devil boom with hydraulic fold
- 12m HD Devil boom with hydraulic fold
- 14m HD Devil boom with hydraulic fold
- 15m HD Devil boom with hydraulic fold
- Hydraulic lift, galvanised single hydraulic system - 10, 12, 14 & 15m Devil booms
- 8 Jet vine boom (Used with BP60/20 pump only)
- 10 Jet vine boom (Used with BP60/20 pump only)
- Olive boom (Used with BP130/20 pump only)
- Undervine and mid row boom
- Boomless nozzle mounting kit (brass nozzle not included)
- 70L flush tank kit to flush the filter, spraylines and nozzles (600L only)
- 16L foam marker (double side)
- 57L Paddock marker foam marker
- Economy hose reel, 20m hose (12mm ID) with Jetpro spray gun
- Reel tuff 12V remote reel with Turbo 400 spray gun (600L only) (inc. APS41 pump upgrade)
- Electric on/off control 3 section
- Electric control 3 section with in cab pressure adjustment
- Bravo 180S automatic rate controller
- IBX 100 ISOBUS controller (in lieu - requires compatible in-cab console)
- Silmix chemical hopper
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN 1,100L SUPER SERIES LINKAGE SPRAYER - BP75/20 PUMP, NO BOOM

Find Sprayers For Sale. Browse 687 Sprayers listings from Farm Supplies Machinery & Equipment.

New & Used Sprayers For Sale in Australia

Farm Supplies Machinery & Equipment

Sale Price

SILVAN 1" O-RING (O.D)

SILVAN 800L SLIMLINE LINKAGE SPRAYER - BP130/20 PUMP, NO BOOM

SILVAN 10MM (ID) FLAT GASKET

SILVAN 12.5 MM BRASS HOSE CONNECTOR (NUT & ELBOW)

SILVAN 1,300L SUPER LINKAGE SPRAYER - BP130/20 PUMP, NO BOOM

SILVAN BARBED TEE PIECE (SUIT 12.5 MM HOSE)

SILVAN 1 1/4" HOSETAIL (SUIT 30MM HOSE)

SILVAN 2" (ID) FLAT GASKET

SILVAN 3,500L (3 ROW) TGS TRAILED SPRAYER - MIN 75PTO HP

SILVAN 2,500L PADDOCK PAK TRAILED SPRAYER (18M BOOM)

SILVAN CHECK VALVE KIT TO SUIT 2088 SERIES PUMPS (VITON)

SILVAN 1,100L SUPER SERIES LINKAGE SPRAYER - BP75/20 PUMP, NO BOOM

Farm Supplies Machinery & Equipment

Dealer Address
