High capacity sprayer with a 12m galvanised boom and hose reel for field and spot spraying in one package.
Specifications:
Tank Size (L): 1,000
Connection Type: Linkage
Pump Size (L/min): 132
Height / Width / Length (mm): 2600 / 2200 / 2250
Features:
Pump: Silvan self-priming oil-backed diaphragm type with nitrile diaphragms and cast anodised aluminium body. BP130/20: 132 L/min. capacity 2000kPa pressure.
Boom: 12m Fieldmaster boom with stainless steel spraylines, non-drip nozzle holders, fully galvanised frame, nozzle protection, spring loaded safety break back/forward and suspension.
Nozzles: Air induction nozzles with strainer in bayonet fit non-drip nozzle holders at 50cm spacings.
Controls: 1 lever, 4 outlet control valves with pressure regulator.
Tank: Polytuff impact resistant polyethylene construction, moulded litre calibrations and non-spill screw-down lid with single breather.
Frame: Fully galvanised steel. 800L model : Cat I & II linkage 1000L model : Cat II linkage
Agitation: Bypass agitation.
Pressure Gauge: 0-25 Bar dual stage glycerine filled gauge.
Filtration: Lid strainer, suction line strainer and nozzle strainers.
Hose Reel: Fitted with rear-mounted hosereel, 20m of 12mm hose and JetPro spraygun with trigger action pattern adjustment.
PTO Driveshaft: Quality driveshaft with quick release pins & safety cover.
Options:
- 14L foam marker (single side)
- 16L foam marker (double side)
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN ECONOMAX 1000L 3PL SPRAYER INC 12M BOOM - SILVAN - KBD1000

2.4m Shear Grab (18 tines in base). Made in New Zealand.
Through the combination of the clean cut obtained from the unique serrated knife edge and rounded front design, the implement leaves a sealed pit face, eliminating secondary fermentation. The side walls and closely spaced cranked tines minimise silage/maize loss during transport.
High tensile steel
Robust frame
Powerful rams
Conserving feed with a Rata Silage Shear Grab.
Model (Code) SHG240
Width (m) 2.4m
Weight (kg) 830kg
Capacity (m³) 1.10
Number of Tines 18
Min Tractor HP 160
All Rata Silage Shear Grabs feature a serrated knife cutting edge. Serrated teeth cut the silage faster, stay sharper for longer, serrated teeth along with rounded grab face also help keep the stack sealed which prevents secondary fermentation.
Hydraulic rams on Grabs are large and powerful to cut through the most dense silage stacks. Models under 2.1m wide have 2 Rams. Models 2.1m wide and above come with 3 hydraulic rams.
Rata Grabs are designed and built heavy duty to cope with a long, hard working life. Heavy steel plate, bushes and bosses ensure maximum strength and support. Particularly around pivot points and high stress load areas.
Hydraulic hoses are routed to keep away from the working area of the Shear Grab. This ensures they are kept out of harms way whilst remaining easy to access.
An optional bucket insert is available upon request. This effectively turns the shear grab into a bucket shear grab for use on fine materials and feeds.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

RATA 2.4M SHEAR GRAB (ALSO SUITABLE FOR TELEHANDLERS)

Made in Europe
Features:
- Self-loading design, simply scoop and mix
- Hydraulic opening at bottom with unloading pipe
- Safety grill with built-in bag breaker
- Incredible European build quality
- Includes electric control kit, hoses and couplings
- Centre Discharge
Dimensions:
Width = 1,480 mm
Flow Range = 40-90 LPM
Full Capacity = 250 L
Full Weight = 980 kg
Empty Weight = 380 kg
Other capacities also available - 200L, 350L 450L & 600L. See picture/s for confirmation of those versions.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available.
Contact Farm Supplies today for sale or more information.
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

HIMAC EURO HITCH CONCRETE MIXER BUCKET (250L)

The reverse rotation stone burier is ideal for horticultural applications in a range of soil conditions.
Specifications:
Actual Width: 188cm
Working Width: 170cm
Required HP: 75-110hp
Weight: 1055kg
No of Blades: 48
Features:
Rotary hoe or reverse rotor rotation
Rated up to 80hp
Four speed gearbox
540 rpm
Category two hitch
Stone burier blades (90x10mm)
6 blades per flange
Rear tailgate with spring cushioned comb
Levelling bar
25cm working depth
Gear side drive
Cam clutch
Front sod breaking discs
Mesh roller
Options in Lieu of Standard:
Hydraulic roller adjustment
Oil cooler
Models:
ARES-BF130 1.3M 60-110HP 830kg 36 blades
ARES-B150 1.5M 65-110HP 920kg 42 blades
ARES-BF170 1.7M 75-110HP 1055kg 48 blades
ARES-BF185 1.85M 80-110HP 1157kg 54 blades
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

CELLI 1.7M (75-110HP) ARES STONE BURIER

Linkage turbomiser 400 litre sprayer with a 140 L/min centrifugal pump and a 450mm fan. Ideal for vineyards and greenhouses. Note: spray head not included
Specifications:
Market: Horticulture. Viticulture.
Tank Size (L): 400
Connection Type: Linkage
Min PTO hp: 45
Pump Size (L/min): 140
Height / Width / Length (mm): 1150 / 1100 / 1000
Product Weight (kg): 207 (dry)
Application: Vineyards, greenhouse
Features:
Pump: CD32 centrifugal pump 140L/min constructed from toughened nylon. Stainless steel shaft & viton/ceramic seal.
Fan Size: P42E: 420 mm dia. turbine fan, 3900 rpm. Power consumed 18 kw / 35HP. P45E: 450mm dia. turbine fan, 4500 rpm. Power consumed 34 kw / 45HP.
Nozzles: Air shear.
Gearbox: Multiplication type through multi-grip, multi-vee belt and pulley, over-run free wheeling hub and oil bath fan housing.
Controls: Two sided electric on/off control with control box mounted in cabin. Rotary plate distribution regulators with 15 settings and manual pressure adjustment.
Frame: Galvanised RHS steel construction, cat II linkage.
Tank: 400L Polytuff impact resistant polyethylene construction, calibrated sight line, non spill lids, hydro chemical mixer in larger basket, lids with basket strainers, seperate in-built 18L fresh water hand wash tank.
Agitation: Bypass and pneumatic
Pressure Gauge: Protected 100mm glycerine gauge fitted at front of sprayer
Filtration: Lid strainer and suction line strainer
PTO Driveshaft: Quality Bondioli & Pavesi driveshaft with quick release pins and safety cover.
HP Required: Minimum 25PTO HP (P42), 45 PTO HP (P45)
Options:
- Super cannon for P42E (GT42-1)
- Super cannon for P45E (GT45-1)
- Manual turntable for Super Cannon (GT55-4)
- Hydraulic turntable for Super Cannon (GT55-9)
- Double sided diffuser head (5 outlets per side) for P42E (GT40-2)
- Double sided diffuser head (5 outlets per side) for P45E (GT45-2)
- Vineyard head - 4 heads (4x4) for P45E (GT45-11)
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

SILVAN 400L P45E LINKAGE TURBOMISER - MIN 45PTO HP (SPRAY HEAD NOT INCLUDED)

Heavy duty rotary hoes intended for large farms, specialised operations and contractors. They are designed to work in heavy conditions with a wide choice of accessories.
The versatility allows better tillage results on many ground types.
Features:
170 HP multi speed gearbox with rear PTO (1000 RPM).
2540mm working width.
60 x L blades total.
Side gear drive.
CE safety guards.
Floating front hitches.
Rear door with spring and pin adjustment.
1 3/8in 21 spline PTO with slip clutch.
Features:
170 HP multi speed gearbox with rear PTO (1000 RPM).
2540mm working width.
60 x L blades total.
Side gear drive.
CE safety guards.
Floating front hitches.
Rear door with spring and pin adjustment.
1 3/8in 21 spline PTO with slip clutch.
Specifications:
Connection Type: Linkage
Min Tractor PTO HP: 70-170 HP
Working Width (mm): 2540
Working Depth (mm): 100-200
Product Weight (kg): 990
Total Width (mm): 2740
Weight with Optional Cage Roller:
Product Weight (kg): 1100
Weight with Optional Packer Roller:
Product Weight (kg): 1280
Options:
Front Depth Wheels
Pair of Side Discs
Wheel Track Eradicator
Double Flange
Note: An additional surcharge applies for machinery assembly.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

BREVIGLIERI 2.54M B170 ROTARY HOE (MIN 70-170HP)

Made in UK
Suits Tractors 55 - 80 LPM, or 135hp+
Features:
- Tie-rodless, solid body design
- Side mount for superior control and precision
- Fully serviceable using no specialist tools
- Line up and ram posts without digging
- Euro Hitch standard. Other hitches available at cost
Dimensions:
Weight = 210 kg
Max BPM = 1,400 BPM
Max energy per blow = 1200 J
Note:: 150 mm post driver Moil included. Other diameter (180mm, 200mm) Moils available at cost.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available.
Contact Farm Supplies today for sale or more information.
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

HIMAC EURO HITCH POST RAMMER (55 - 80 LPM)

Features:
90 HP single speed gearbox.
2050mm working width.
Side gear drive.
CE safety guards.
54 x C Blades.
Cat I or II three point linkage.
1 3/8in 6 spline PTO with slip clutch.
Specifications:
Connection Type: Linkage
Min Tractor PTO HP: 60-90 HP
Working Width: 2050mm
Working Depth: 100-200mm
Product Weight: 585kg
Total Width: 2300mm
Options:
Front Depth Wheels
Note: An additional surcharge applies for machinery assembly.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

BREVIGLIERI 2.05M B85 ROTARY HOE (MIN 60-90HP)

Trailed air assist Supaflo 1,500 litre sprayer with 161 L/min diaphragm pump, electric controls, a Glideflex axle upgrade, wide angle shaft and a 900mm fan.
Ideal for vineyards and orchards.
Specifications:
Market: Horticulture. Viticulture
Tank Size (L): 1500
Connection Type: Trailed
Min PTO HP: 60
Pump Size (L/min): 161
Height / Width / Length (mm): 1530 / 1540 / 3540
Product Weight (kg): 540 (dry)
Application: Vineyards and Orchards
Features:
Pump: Silvan oil-backed diaphragm type with nitrile diaphragms and corrosion resistant, cast anodised aluminium body with brass heads and manifold. IDS1701:161L/min. capacity, 5000kPa pressure.
Fan size: 900mm axial flow type, 10 bladed fan with curved nylon reinforced blades, air straightening vanes and protective mesh cover. Powerhead (920mm) & Radak (1,000mm) fitted with axial flow type, 10 bladed fan, centrifugal clutch and protective mesh cover.
Nozzles: Flip-over type for dilute/concentrate spraying. Ceramic jets, stainless steel swirl-plates. 16 double sided nozzles (8 per side) twist on/off. The Powerhead has 24 double sided nozzles (12 per side) and the Radak has 32 (16 per side).
Gearbox: 2-speed with neutral position, oil-bath type
Control: 40 bar electric section valves, master valve, electric pressure regulator and in cab controls.
Tank: Polytuff impact resistant polyethylene construction, calibrated sight line, flip-top easy open lids, 40mm drain valve and built-in chemical mixer. 40L fresh water hand wash tank.
Frame: Galvanised steel with jockey wheel & adjustable drawbar.
Agitation: Pump bypass plus venturi agitator.
Pressure gauge: 100mm, 0-60 bar glycerine filled gauge.
Filtration: Lid strainer, suction line strainer & stainless steel nozzle filters.
Wheel Equipment: Glideflex suspension axle, 2x15" tubeless tyres on galvanised rims (max speed rating 30 km/h)
PTO Driveshaft: Quality Bondioli & Pavesi constant velocity driveshaft with quick release pins & safety cover.
HP Required: Min 60 PTO HP
Options:
- Powerhead Conveyor (in lieu of standard fan cowling) (D99-184)
- Radak Conveyor - Manual adjustment of top and bottom wings (In lieu of standard fan cowling) (D99-135)
- Hydraulic kit for Radak Conveyor (top wings) (D99-155B)
- SCRAM Jet (to suit Radak Conveyor) (D99-180)
- One sided conveyor (D99-41)
- Leaf guard (to suit Powerhead & Radak) (D99-175)
- Twin nozzle (includes extra nozzles) (D99-182)
- Two-sided poly vineyard conveyor (D99-111)
- Bravo 180S automatic rate controller (D99-143)
- Flotation tyres - 400/60 x 15.5" with fixed axle (in lieu of standard singles) (D99-80)
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

SILVAN 1,500L SUPAFLO TRAILED SPRAYER - MIN 60PTO HP

Series 39 Hydraulic folding wing frame with 6 section folding S04 Diamond Harrow. 5.97m coverage. Transport width: 3.6m.
Please note that 3 point linkage pins are not supplied.
Murray Series 39 Hydraulic Folding Harrow Frames provide a solution to the transportation of multiple Harrow sections.
Designed to fit Category I or II three-point linkage systems, Murray Series 39 Harrow Frames allow transport between paddocks and through smaller sized gates.
Each unit features a top class frame designed and backed by Murrays years of experience.
Simplicity and strength are combined in a compact frame utilising a rigid linkage-mounted centre section and hydraulic folded wings.
Murray Series 39 Harrow Frames suit Category C Harrows including Series 04 Diamond Harrow sections and Series 08 Stump Jump Harrow sections.
Series 39 Folding Harrow Frames are supplied complete with centre section, wing attachments and all rings and links to suit your harrow type and size.
Specifications:
- Anchor points to suit desired Harrow
* Murray Harrows must be pulled (towed) by a tractor correctly fitted with an approved rollover protection structure. Murray Harrows are NOT intended for use with an ATV or Ride On Lawn Mower.

All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

MURRAY 5.97M HYDRAULIC FOLDING FRAME DIAMOND HARROW

AdBlue Bulk Storage Tank 5,000ltr Depot Model
Optimised Fleet Solutions for bulk AdBlue storage and dispensing to SCR/DEF equipped vehicles.
- Protects your AdBlue® from temperature damage
- Prevents contamination in handling and storage
- Simplifies dispensing operation
- Plug n play set up for fast installation
Dimensions:
Length: 4,140 mm
Width: 1,170 mm
Height: 2,110 mm
Features:
- 50mm (2) Stainless Steel Drybreak (fill)
- Digital tank volume measurement
- Mechanical overfill protection
- Power control panel with Emergency Stop
- Auto timeout (10mins)
- High/low level audible alarms
- Lockable cabinet
- 32 LPM Piusi AdBlue Pump 240V
- Digital flow meter
- 5 mtr hose
- Auto-shut off nozzle & holster
- Earth rod
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available.
Contact Farm Supplies today for sale or more information.
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

POLYMASTER 5,000L ADBLUE (CABINET) SLIMLINE TANK

Stony soil can be a major problem in the construction of parks, gardens, golf courses and any other designated green areas.
Breviglieri has engineered an efficient and functional appliance for burying stones. The robust system and oversized parts make the stone burier a dependable machine that can deal with even the toughest situations.
Stone buriers perform multiple functions in a single pass, delivering considerable agronomic and economic benefits:
- mills soil + seeds
- separates and buries soil + seeds
- levels tilled earth ready for seeding
- breaks up large clods
- facilitates drainage of the seed bed and improves water flow regulation
- reduces soil compaction
- generates significant labour savings
- speeds up soil preparation
- seeding
3 Types of SB60 Models: Please note the price listed is for model SB60 105.
- SB60 105: 35-40HP, 105cm working width, 36L blades, 485kg
- SB60 125: 40-45HP, 125cm working width, 36L blades, 517kg
- SB60 145: 45-50HP, 145cm working width, 42L blades, 550kg
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

BREVIGLIERI 145-185CM STONE BURIER (35-50HP)

Find Farm Machinery For Sale from $10,000 to $50,000. Browse 894 listings from Farm Supplies Machinery & Equipment.

Farm Machinery For Sale from $10,000 to $50,000

Farm Supplies Machinery & Equipment

Sale Price

SILVAN ECONOMAX 1000L 3PL SPRAYER INC 12M BOOM - SILVAN - KBD1000

RATA 2.4M SHEAR GRAB (ALSO SUITABLE FOR TELEHANDLERS)

HIMAC EURO HITCH CONCRETE MIXER BUCKET (250L)

CELLI 1.7M (75-110HP) ARES STONE BURIER

SILVAN 400L P45E LINKAGE TURBOMISER - MIN 45PTO HP (SPRAY HEAD NOT INCLUDED)

BREVIGLIERI 2.54M B170 ROTARY HOE (MIN 70-170HP)

HIMAC EURO HITCH POST RAMMER (55 - 80 LPM)

BREVIGLIERI 2.05M B85 ROTARY HOE (MIN 60-90HP)

SILVAN 1,500L SUPAFLO TRAILED SPRAYER - MIN 60PTO HP

MURRAY 5.97M HYDRAULIC FOLDING FRAME DIAMOND HARROW

POLYMASTER 5,000L ADBLUE (CABINET) SLIMLINE TANK

BREVIGLIERI 145-185CM STONE BURIER (35-50HP)

Farm Supplies Machinery & Equipment

Dealer Address
