Linkage 400 litre Super sprayer with 58 L/min pump, without boom. Ideal for spraying pasture and ag lifestyle use.
Specifications:
Market: Dairy & Livestock
Tank Size (L): 400
Connection Type: Linkage
Pump Size (L/min): 58
Height / Width / Length (mm): 1200 / 1020 / 930
Product Weight (kg): 90
Application: Pasture spraying.
Features:
Pump: Silvan self-priming oil-backed diaphragm type with nitrile diaphragms and corrosion resistant, cast anodised aluminium body with raised pump mount. BP60/20: 58L/min. capacity 2000kPa pressure. BP130/20: 132 L/min. capacity 2000kPa pressure.
Controls: 3 outlet manual control valve with pressure regulator.
Tank: Low profile, 400 and 600L Polytuff impact resistant polyethylene construction, external
sightline with floating ball and non-spill offset screw-down lid with single breather. 15L freshwater tank with screw-down lid and on/off tap. 4L toolbox with polyethylene lid.
Frame: Galvanised steel with adjustable cat I & II hitch on 400L and cat II hitch on 600L. Vertical boom channel for positioning the boom at the optimum spray height.
Agitation: Bypass agitation.
Pressure Gauge: 0-25 Bar dual stage glycerine filled gauge.
Filtration: Lid strainer, suction line strainer with stop valve fitted at the side of the tank to enable ease of filter maintenance.
PTO Driveshaft: Quality driveshaft with quick release pins & safety cover.
Options:
- 6m Field boom
- 8m Field boom
- 10m Field boom
- 12m Fieldmaster boom with suspension (600L only)
- 6m Hydraulic fold boom
- 8m Devil boom with hydraulic fold
- 8 Jet vine boom
- 10 Jet vine boom
- Olive boom (Used with BP130/20 pump only)
- Undervine and mid row boom
- Boomless nozzle mounting kit (brass nozzle not included)
- 70L flush tank kit to flush the filter, spraylines and nozzles (600L only)
- 14L foam marker (single side)
- 16L foam marker (double side)
- 57L Paddock marker foam marker
- Economy hose reel, 20m hose (12mm ID) with Jetpro spray gun
- Reel tuff 12V remote reel with Turbo 400 spray gun (600L only) (inc. APS41 pump upgrade)
- Electric on/off control 3 section
- Electric control 3 section with in cab pressure adjustment
- Bravo 180S automatic rate controller
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN 400L SUPER SERIES LINKAGE SPRAYER - BP60/20 PUMP, NO BOOM

Easy to use. Strong. Rust proof.
Looking for a strong D-shackle for heavy lifting and towing? Our load rated D-shackles are perfect for supporting a heavy load.
Our shackles are perfect for heavy lifting and static systems where a reliable strong D-shackle is needed.
Each load rated screw pin shackle comes with a galvanised steel body and yellow screw pin.
They can be used the same as regular D-shackles however, the rating means you know how much load they will safely be able to handle.
Price quoted is for one item.
Discounts apply for bulk kit purchases of 10+ & 20+.
Specifications:
- 19mm shackle O.D
- 22mm pin O.D
- 32mm internal width
- 4.7 tonne working load limit
Features:
- Extremely strong
- Easy to use
- Rust resistant
How To Choose A D-SHACKLE
A D-shackle is a great option if you want to attach your chain to other objects. However, you will want to make sure you pick the right D-shackle for your chain.
When choosing a D-shackle, you will need to find out the inside width of the chain link. The pin of the D-shackle will need to be smaller than this width in order for it to fit through your chain link.
To find the inside width of the chain, simply subtract 2x the chain link diameter from the total width. For example, here is how you would calculate the inside width of an 8mm chain:
27mm (width) 2 x 8mm (diameter) = 11mm (inside width)
In this example, the inside width of an 8mm chain is 11mm. This means you would want to get a D-shackle with a pin diameter (Ø) of 10mm or less. (An 11mm pin might be too tight a fit).
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

ROTECH RURAL 19MM LOAD RATED D-SHACKLES (W.L.L 4.7T) -DS19R

Specifications:
Pump Size (L/min) : 150
Max Pressure: 20 Bar / 290 psi
Hose Inlet: 19mm
Size Outlet: 13mm
Bypass Hose: 23mm
Control Valve: 4 Outlet
Pump App: BP60/20, BP125/20
Control valves regulate spray pressure, direct the flow of spray liquid from the pump to the spray nozzles and bypass excess liquid back to the tank, in most cases through an agitator.
All feature adjustable pressure regulator, glycerine filled gauge, hose connections, mounting kits where applicable, on/off directional valves and bypass lock position. One lever 4 outlet control shuts all boom sections off by simply flicking main lever to one side, standard with dual stage gauge.
Supplied with remote bracket kit (C5004-05).
Features:
To suit BP60/20 (CBP06020)
To suit BP125/20 (CBP12520)
One lever 4 outlet control shuts all boom sections off by simply flicking main lever to one side
Standard with dual stage gauge
19mm inlet / 13mm outlet
23mm Bypass hose size
20 bar / 290 psi Max pressure
150 L/min max flow
Supplied with remote bracket kit (C5004-05)
Capacity 150 Litres
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

SILVAN 4 OUTLET CONTROL VALVE

3.96m Murray Series 03 Levelling Harrow 3 Rank Deep Sections & Standard Drawbar, Heavy Duty. Complete Set.
3408 - 3.96m (13ft) - 3/9 Tine, 2/12 Tine - 75kg.
Murray Levelling Harrows are an excellent choice to complement sowing or cultivation implements. Designed to level soil and seedbeds, the flexible frame design provides durability in all soil types. 3 and 4 rank versions are suitable for use to cover seed in light to medium soils in conjunction with combines and seed drills. The 5 rank model is used in heavier soils to counter weed growth and break down large clods. It is a popular implement that complements cultivators, scarifiers or chisel plows.
If you require additional weight to work your land, a Heavy version of our Series 03 Levelling Harrows is available. Made from heavier High Carbon Steel, the Tine Spacing remains the same as the standard version.
The Series 03 Levelling Harrow is available in either 3 or 4 row widths allowing extensions in increments of 235mm (9 ¼) to suit primary machines of almost any width. This allows a combination of harrow sections to be configured to suit your application.
A full range of standard and heavy duty drawbars are available to correctly match your soil conditions and available working width of your equipment. Harrow sets complete with drawbars range from 2.31m (77) to 5.58m (184) in width.
Specifications:
- Tine Spacing 76mm (3in).
- Tine Length 190mm (7 1/2in) approx.
- Centre to centre of Front Hooks 235mm (9 1/4in).
Features:
- High Carbon Cut Tines.
- Light models manufactured from 25 x 6mm carbon steel and Heavy models from 32 x 6mm.
* Murray Harrows must be pulled (towed) by a tractor correctly fitted with an approved rollover protection structure. Murray Harrows are NOT intended for use with an ATV or Ride On Lawn Mower.

All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

MURRAY SERIES 03 LEVELLING HARROW 3.96M, 3 RANK DEEP SECTIONS & STD DRAWBARS-HEAVY DUTY-COMPLETE SET

Ideally suited to any machine fitted with 24 volt DC system eg. bulldozers, trucks and road sweepers.
Available in 11.3 L/min, 3 bar / 45 psi open flow with On/Off demand pressure switch.
Features:
Santoprene valve material
Santoprene diaphragm material
On/Off demand Pressure switch
Intermittent duty rating
1/2 BSP Male ports
Pump Size 11.3 L/min
Pressure Rate 3.1 bar 45 psi
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN 24 VOLT SHURFLO DC PUMP - 11.3L/MIN - SILVAN - 361-2088-474-144

The RM75 offset disc cultivating plough is a tough, rugged machine designed for Australian conditions. The RM75 is similar to the RM80 with the main difference being in the lesser number of bearings and longer axles.
Ideal for primary and secondary tillage with 60 -130 HP tractors.
Features:
Fitted with 24 inch x 6mm scalloped discs. All discs are European Bellota Boron discs which carry a lifetime warranty against manufacture failure.
Fitted with two 750×16 Land Cruiser wheels on a 5 tonne axle. Hydraulic wheel lift is standard. All models fitted with 8 inch Australian made Eaton rams.
Australian made Ryco hoses are used with a minimum burst pressure of 20,400psi.
Twin pressure screws can be adjusted individually to transfer weight to the rear of the plough, resulting in even disc penetration.
40mm square high tensile gang bolts.
Flange disc bearings designed specifically for severe tillage applications. The bearings are encapsulated in two case hardened zinc plated stampings. Two nitrile O rings are fitted to exclude contaminants and provide a grease seal to ensure lubricant goes directly into the bearing.
Fully adjustable drawbar.
Solid cast spools throughout the gangs provide ballast weight in the gangs, where it counts, rather then the main frame. Each is individually machined to suit the disc for extra strength.
9 inch disc spacing.
Fitted with hydraulic lift as standard.
Prong type scrapers are standard formed scrapers on request.
Parking jack is optional.
Optional furrow fillers available.
Specifications:
Approx Weight: 1930kg
No of bearings: 8
No of axles: 4
Cutting width: 2.74m (9ft)
Options:
0951 Optional jack
0953 Optional Furrow filler (not sold separately)
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

JOHN BERENDS RM75 HD TRAILING OFFSET 24 PLATE 6MM DISCS - 0842, SUIT 60-130HP

The Nobili BK series mulcher is a heavy duty multi-purpose machine, fitted with maintenance free bearings. The BK is fitted with an opening tailboard and a mulching bar is fitted to produce a fine mulch.
Suggested Use: Grass, stubble, pasture topping, vegetable topping, regrowth and green pruning's to 90mm diameter.
Construction: High profile body, opening tailboard and one mulching bar.
Control: Two position fixed headstock.
Drive Line: PTO drive shaft with durable safety cover, heavy duty oil bath gearbox with over running clutch, taper locked pulleys and electronically balanced rotor.
Attachment: Category II three point linkage, 2 position manual fixed headstock with floating top link.
Height Control: Skids.
Specifications:
Connection Type: Linkage
Tractor HP: 90-160 HP
Working Width (mm): 2792
Blades (Y with Straight): 64/32
Product Weight (kg): 1100
Width / Depth / Height (mm): 2998 / 1505 / 784
Options:
Full Width Roller
Semi Swivel Wheels
Wear Plate
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

NOBILI BK MULTI-PURPOSE MULCHERS 2.8M - BK280/012, 90-160HP

Series 30 2.48m Mounted Spring Tine Harrow System - Light Duty 2 Rank- Straight Tines.
The Series 30 Light Duty is the perfect implement for sandy to light soils. Specifically designed to increase trash flow using wide spacing between each straight tine, the 2 rank is a lighter duty harrow available in five sizes ranging from 1.78m (510) to 3.20m (106). Each section is supplied complete with two mount arms.
Harrow depth control is adjustable by means of specially designed cam-action fitting within the mount arm.
Specifications:
- Coverage: 2.48m
- Weight: 68kg
- Tine spacing 85mm (3 3/8) 2 Rank.
- Tine Diameter 10mm Straight Tine.
- Tine length 385mm (15) approx.
- Rank Spacing 324mm (12 3/4").
- 2 Mount Arms per unit.
- Mount clamp suits 81mm to 100mm (3 1/4 to 4) square frame positioned on the flat or on the edge (Spacers
required for 75mm [3] square frame).
Features:
- May be attached to the rear bar of light duty cultivators, seeding drills, etc.
- Unit features two Series 30 Mount Arms.
- A cam incorporated in the mount clamp adjusts the height of the Harrow Tine Section.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

MURRAY 2.48M MOUNTED SPRING TINE HARROW SYSTEM - LIGHT DUTY - 2 RANK

Strong compact tandem disc ideal for vineyards, orchards and horticulture.
Features:
Excellent digging ability.
Easy ratchet gang adjustment.
Available in 16, 20 and 24 plate models.
Buster tine removes centre ridge to create a level finish.
Solid cast spools are individually machined to suit the disc for
extra strength.
230mm (9 inch) spacing.
Fitted with 560mm x 5mm (22 inches x 3/16 inch) scalloped discs as standard.
28mm square high tensile gang bolts.
Triple sealed bearings.
Options:
0948 Optional Scrapers suit 20 plate TH30
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

JOHN BERENDS TH30 20 PLATE HEAVY DUTY TANDEM DISCS - 0815

The Vogal Baitmax is a 12 volt bait spreader for arable slug bait spreading - helping farmers to eliminate slugs & increase their pasture & crop yields.
It's built heavy duty from the ground up with an all stainless steel frame, heavy duty UV resistant hopper plus lid and a protective casing surrounding the motor. Adjustable disc angles and variable spread rates make it a flexible slug bait spreader/ broadcaster.
Mounting can either be on the back of your quad or seed drill, with a spread width of 12m to 18m
Its grass seed spreading capability ads further versatility for when you need to top up those 'thin' patches.
An "optional" auto on/off kit is available for when mounting to seed drills. This automatically turns the spreader off when the drill/seeder is out of the ground at headlands etc & turns it back on when its back in the ground. Saving you a job & preventing wastage of bait.
Capacity (45L)
Max Spread Width (18m)
Dry Weight (18kg)
Application Rate (2-20 kg/ha)
Min Mounting Height (800mm) (spinner disc to ground)
Vogal Baitmax hoppers are made from thick heavy duty UV resistant plastic to cope with the harsh extremes in Southern Hemisphere environments.
The heavy duty stainless steel frame ensures great strength along with high corrosion resistant properties. Mounted onto the frame is the powerful 12V electric motor that powers the spinner.
Application rates are easily adjustable via the front shutter lever. This rate controller sets the rate while the aperture controls the open and close.
The wiring loom and hand controller come standard allowing you to start and stop the spinners, open and close the aperture from the seat of you ATV or Tractor.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

RATA 45L 12V BAIT & SEED SPREADER

Thread size = 1/2" BSP
Overall Length = 75 mm
Maintaining a leak free and smooth liquid flow by using quality components and fittings is essential for maximum performance from all installations.
Selectas range of fittings are manufactured from high quality polypropylene and are compatible with fungicides, herbicides, chemical fertilisers etc, and will withstand temperatures of up to 100ºC.
Standard BSP male and female threads can be used in conjunction with each other to construct assorted types and sizes of inlets, outlets, suction fittings and hose unions or they can be used with standard brass, galvanised and other fittings.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

SILVAN 1/2" NIPPLE (75MM LENGTH)

Australian made Frame - German made Spears
Features:
- German-built Conus 2 removable spears
- Distance between spear - 950 mm
- Bright red colouring for maximum visibility
- Australian made compact frame
- Weight = 175 kg
- Suits up to 40 hp
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available.
Contact Farm Supplies today for sale or more information.
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

HIMAC EURO HITCH COMPACT BALE FORKS (DOUBLE SPEAR)

Find Farm Machinery For Sale. Browse 7628 listings from Farm Supplies Machinery & Equipment.

New & Used Farm Machinery For Sale

Farm Supplies Machinery & Equipment

Sale Price

SILVAN 400L SUPER SERIES LINKAGE SPRAYER - BP60/20 PUMP, NO BOOM

ROTECH RURAL 19MM LOAD RATED D-SHACKLES (W.L.L 4.7T) -DS19R

SILVAN 4 OUTLET CONTROL VALVE

MURRAY SERIES 03 LEVELLING HARROW 3.96M, 3 RANK DEEP SECTIONS & STD DRAWBARS-HEAVY DUTY-COMPLETE SET

SILVAN 24 VOLT SHURFLO DC PUMP - 11.3L/MIN - SILVAN - 361-2088-474-144

JOHN BERENDS RM75 HD TRAILING OFFSET 24 PLATE 6MM DISCS - 0842, SUIT 60-130HP

NOBILI BK MULTI-PURPOSE MULCHERS 2.8M - BK280/012, 90-160HP

MURRAY 2.48M MOUNTED SPRING TINE HARROW SYSTEM - LIGHT DUTY - 2 RANK

JOHN BERENDS TH30 20 PLATE HEAVY DUTY TANDEM DISCS - 0815

RATA 45L 12V BAIT & SEED SPREADER

SILVAN 1/2" NIPPLE (75MM LENGTH)

HIMAC EURO HITCH COMPACT BALE FORKS (DOUBLE SPEAR)

Farm Supplies Machinery & Equipment

Dealer Address
