4.19m Murray Series 03 Levelling Harrow 4 Rank Deep Sections & Standard Drawbar, Heavy Duty. Complete Set.
3609 - 4.19m (13ft 9in)(20 Row) 2/12 Tine, 3/16 Tine - 100kg.
Murray Levelling Harrows are an excellent choice to complement sowing or cultivation implements. Designed to level soil and seedbeds, the flexible frame design provides durability in all soil types. 3 and 4 rank versions are suitable for use to cover seed in light to medium soils in conjunction with combines and seed drills. The 5 rank model is used in heavier soils to counter weed growth and break down large clods. It is a popular implement that complements cultivators, scarifiers or chisel plows.
If you require additional weight to work your land, a Heavy version of our Series 03 Levelling Harrows is available. Made from heavier High Carbon Steel, the Tine Spacing remains the same as the standard version.
The Series 03 Levelling Harrow is available in either 3 or 4 row widths allowing extensions in increments of 235mm (9 ¼) to suit primary machines of almost any width. This allows a combination of harrow sections to be configured to suit your application.
A full range of standard and heavy duty drawbars are available to correctly match your soil conditions and available working width of your equipment. Harrow sets complete with drawbars range from 2.31m (77) to 5.58m (184) in width.
Specifications:
- Tine Spacing 76mm (3in).
- Tine Length 190mm (7 1/2in) approx.
- Centre to centre of Front Hooks 235mm (9 1/4in).
Features:
- High Carbon Cut Tines.
- Light models manufactured from 25 x 6mm carbon steel and Heavy models from 32 x 6mm.
* Murray Harrows must be pulled (towed) by a tractor correctly fitted with an approved rollover protection structure. Murray Harrows are NOT intended for use with an ATV or Ride On Lawn Mower.

All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

MURRAY SERIES 03 LEVELLING HARROW 4.19M, 4 RANK DEEP SECTIONS & STD DRAWBARS-HEAVY DUTY-COMPLETE SET

Series 56 Murray Hydraulic Bale Brab - 12 bale.
Features:
- High Strength Steel Bale Hooks
- Heavy Duty Frame & Bale Fence
- Fence is removable or able to swapped from R/ hand to L/ hand
- Able to be fitted with appropriate attachment mechanism to suit tractor, load or telehandler.
Specifications:
- 12 bale
- Weight: 620kg
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

MURRAY HYDRAULIC BALE GRAB- 15 BALE, 3PL- SERIES 56

The Deep Tillage plough is designed for shattering compact ground with minimal disturbance to the sub soil.
Ideal for ripping hard ground prior to cultivation and for aerating pastures, therefore increasing water absorption & improving the profile of the soil.
Can be used to renovate pastures or for bed renovation. Broad acre application and row cropping. High tensile cast shank assembly with 24 underframe clearance with 1 shear pin protection.
Replaceable points and shin guards, also available with tungsten tips.
Optional crumbler rollers also available to help create a level surface and reduce crusting in the surface.
Optional coulters available to reduce surface disturbance in pasture (must be ordered with machine).
Specifications:
Heavy duty 100 x 100 x 9mm tine mounting frame.
High tensile cast shank assembly with 24in (610mm) underframe clearance with 1in shear pin protection. Replaceable points and shin guards also available with tungsten tips.
Breakout force approx. 4000 ft. / lbs.
Tine spacing set at 12in (300mm).
Approx 15HP required per tine.
Adjustable pair of Holden wheel for depth control available as an option.
Optional coulters available to reduce surface disturbance in pasture.
Available in 2, 3, 5, 7, 9 or 11 tine models with other sizes made on request. 2 and 3 tine models are fitted on a single row frame. Trailing units also available.
Options:
0327 14in Coulters (must be ordered with machine) priced per coulter unit.
0355 Optional Hydraulic Phasing Cylinders to replace ratchets.
0200 Depth Wheels (Pair Holden) optional normally mounted outside frame.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

JOHN BERENDS DEEP TILLAGE PLOUGHS 2 TINE - 0321, MIN 30HP

Specifications:
Market: Viticulture.
Tank Size = 2,000 L
Connection Type: Trailed
Min PTO hp: 60
Pump Size : 500+ LPM
Application: Vineyards
Dimensions - Length measured with linkage hitch:
Length: 4,680 mm
Width Less Head: 1,800 mm
Width Folded: 2,490 mm
Height: 3,330 mm
Weight 990 kg (Dry)
Includes spray heads, independent 320mm hydraulic fans, hydraulic drive stainless steel pump, automatic spray rate controller, self contained hydraulic drive system and tandem suspension axle. Ideal for vineyards.
Model Specifications
- Head Two row spraying head: 28 venturi air shear adjustable nozzles with individual metering and on/off taps. Left and right arms are independent hydraulic folding with adjustable width and centre frame. Boom frame is galvanised.
- Pump Multi-stage hydraulic drive pump, multiple impellers made with highly resistant engineering plastic for excellent chemical compatibility. 500+L/min. Driven by tractor remotes.
- Fan Size 320mm turbine fan, one per air tube, 3600rpm. Power consumed 29kw/38HP.
- Hydraulic Control Hitch mounted hydraulic power pack with: 40L oil reservoir with cartridge particulate filter, motors fitted with case drain, hydraulic distribution block incorporates anti-cavitation and pressure relief valves, 12V oil cooler.
- Nozzles Air shear.
- Controls Electric section valves with Bravo 180S automatic rate controller. Large 100mm pressure gauge.
- Tank Polytuff impact resistant polyethylene construction, calibrated sight line, flip top easy open lid, 50mm camlock bottom fill and 40L fresh water hand wash tank.
- Frame Galvanised steel chassis, linkage hitch fitted with hydraulic power pack.
- Agitation Venturi agitator.
- Filtration Lid strainer and large capacity suction filter.
- Wheel Equipment Tandem suspension with 10x15inch wheels and tyres.
- PTO Driveshaft Quality Bondioli & Pavesi driveshaft with quick release pins and safety cover.
- HP Required Minimum 60 PTO HP
Factory Options
- Hydraulic pump driven through power pack.
- Hydraulic Height Adjustment phased or independent.
- Hydraulic Row width adjustment phased or independent.
- Bravo 180S spray rate controller with hydraulic controls (in lieu) up to 5 sections.
- Bravo 180S spray rate controller with hydraulic controls (in lieu) 7 sections.
- Bravo 400S automatic rate controller with GPS guidance (in lieu) 7 spray sections.
- Bravo 400S automatic rate controller with hydraulic controls, GPS guidance (in lieu) 7 spray sections + 7 hydraulic sections.
- IBX 100 ISOBUS controller (in lieu requires compatible in-cab console).
- Delta 80 Universal Terminal to suit ISOBUS control.
- Quick turning hitch.
- Electric braked tandem suspension axle via trailer plug in lieu of standard axle.
- Hydraulic braked tandem suspension axle in lieu requires compatible tractor remotes.
- 100L Flush Tank
- Road Kit Brake and indicator lights with folding Oversize sign.
- Tail Light Kit Brake and indicator lights via trailer plug.
NOTE: Not all options will fit all models. Extra charges may apply to fitment of some options.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available
Contact Farm Supplies today for sale or more information
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN 2,000L (2 ROW) TRAILED SCRAM CROSS - MIN 60PTO HP

The Silvan Volumex range uses a patented design to accurately distribute granulated fertiliser, insecticides, herbicides and seeds.
The volumetric conveyor belt and calibrated metering adjustments ensure the product is applied at correct doses.
Each Volumex distributor permits fitment of two dropper hoses which direct the measured product exactly where it is required.
Features:
- The hopper is constructed from stainless steel and the distributor from non-corrosive polypropylene.
- Precision calibrated manual adjustment dial.
- Compact size allows easy attachment to many types of equipment.
Specifications:
Capacity = 180 L
Distributors / Outlets = 2 / 4
NOTE Mounting brackets and hoses not supplied with the Volumex.
NOTE 12 Volt drive motor is not supplied with Volumex Applicator. If required, please select from Option Listed below.
12V Motor Options:
- 12v Single Speed or Vari Speed Motor.
- MV-SS Micro Single Speed.
- MV-VS Micro Vari-Speed 3-20rpm.
- MV-VS2 Micro Vari-Speed 3-35rpm.
Dimensions:
Length: 735 mm
Width: 510 mm
Height: 730 mm
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available
Contact Farm Supplies today for sale or more information
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN 180L VOLUMEX GRANULAR APPLICATOR (2 -4 DROPPERS) 12V MOTOR NOT INCLUDED

2.4m General Purpose Telehandler Bucket - Made in New Zealand.
These Buckets are made from high quality steel plate & also feature bracing throughout.
Please see the table (in pictures) to choose a bucket size that best suits your needs.
As well as high tensile wear resistant cutting edges along the front engaging edges of the bucket opening, Rata Buckets also feature wear strips along the base to protect the skin itself.
These Buckets are made from high quality steel plate & also feature bracing throughout - such as the extra wear plates on the bucket sides & a strong top cross section.
x1 Optional item:
Double Bevel Bolt on Cutting Edge - Although cutting edges are standard on Rata buckets, a double bevel bolt on cutting edge is also available. This extends the life of cutting edges in high use & wear environments.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

RATA 2.4M TELEHANDLER ROUNDED SHELL BUCKET

Series 30 2.84m Mounted Spring Tine Harrow System - Light Duty 2 Rank- Straight Tines.
The Series 30 Light Duty is the perfect implement for sandy to light soils. Specifically designed to increase trash flow using wide spacing between each straight tine, the 2 rank is a lighter duty harrow available in five sizes ranging from 1.78m (510) to 3.20m (106). Each section is supplied complete with two mount arms.
Harrow depth control is adjustable by means of specially designed cam-action fitting within the mount arm.
Specifications:
- Coverage: 2.84m
- Weight: 76kg
- Tine spacing 85mm (3 3/8) 2 Rank.
- Tine Diameter 10mm Straight Tine.
- Tine length 385mm (15) approx.
- Rank Spacing 324mm (12 3/4").
- 2 Mount Arms per unit.
- Mount clamp suits 81mm to 100mm (3 1/4 to 4) square frame positioned on the flat or on the edge (Spacers
required for 75mm [3] square frame).
Features:
- May be attached to the rear bar of light duty cultivators, seeding drills, etc.
- Unit features two Series 30 Mount Arms.
- A cam incorporated in the mount clamp adjusts the height of the Harrow Tine Section.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

MURRAY 2.84M MOUNTED SPRING TINE HARROW SYSTEM - LIGHT DUTY - 2 RANK

A robust medium duty slasher to suit small to medium size tractors. Australian made using high quality European components. Excellent value for money.
Features:
Body designed to take real punishment. 3mm top plate and strong 6mm thick side panels prevent denting.
Bondioli & Pavesi Series 4 pto driveshaft with 2 plate slip clutch protects slasher and tractor. Optional over-run clutch to suit tractors with single stage clutch.
40 HP oil lubricated Comer gearbox. Optional Italian manufactured gearbox upgrade.
Hardened and tempered stepped/bushed slasher blades.
Available in 5 widths with dual mounting (centre or offset).
Floating headstock for working on undulating ground.
Optional pneumatic wheelkits available for depth control.
Fitted with front and rear chain guards.
Cat 1/2 linkage.
Optional galvanising available.
Full 12 month warranty on design and manufacture.
Specifications:
Centre Mount
Cutting Width 1030mm
Overall Width 1120mm
Overall Length 1120mm
Tractor HP 18-30
Cutting Height 25-100mm
Weight 185kg
Options:
1588UG Italian Manufactured 40HP Gearbox Upgrade
0065 EP Slasher Wheel Kit (Pneumatic Wheel)
0148 Additonal over-run clutch (suits tractors with single stage clutch)
0051GAL EP100 with Galvanised Deck
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

JOHN BERENDS EP100 MEDIUM DUTY SLASHERS 1M - 0051- 18-30HP

Designed for small to medium size tractors.
Popular cultivation tool used to break up soil for preparing crops or controlling weeds. Discs can cut up and mix in trash, are very hard wearing, long lasting and easy to use.
Fitted with 28mm (1 1/8in) square high tensile gang bolt axles and high quality triple sealed bearings.
14-18 plate models fitted with 75x75x6mm double beam whilst 10-12 plate models are fitted with main single beam and angle support bracket.
Cat 1/2 linkage.
Clamped on by U-bolts for simple adjustment.
Bellota Boron discs are manufactured under strict quality specifications that ensure the right hardness and uniformity throughout the disc. This includes clamp hardening to prevent distortion, lathe turning of the edges and hardened to 50HRc for low wear and long life.
Features:
No of Discs 12
Disc Diameter 500mm (20inch)
Disc Thickness 4mm
HP (min) 25HP
No. Bearings 4
Working Width 1350mm (4ft 6in)
Weight 335kg
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

JOHN BERENDS MEDIUM DUTY OFFSET DISCS - 12 PLATE X 20 INCH DISCS - 0248, MIN 25HP

3,000L Paddock Pak. BP130/20 pump, 3 section electric valve controls, 18m boom.
Specifications:
Tank Size (L): 3,000
Connection Type: Trailed
Pump Size (L/min): 132
Features:
Pump: Silvan self-priming oil backed diaphragm pump. BP130/20: 132 L/min. capacity 2000kPa pressure.
Boom: Hydraulic lift, fold and tilt with parallel arm boom suspension, nitrogen accumulator and spring-loaded breakbacks. Galvanised boom with stainless steel spraylines. Minimum 3 sets of hydraulic remotes required.
Controls: 3 section Silvamatic electric controls with pressure compensating direct acting valves. In cab on/off & pressure adjustment with pressure gauge.
Tank: Polytuff impact resistant polyethylene construction with calibrated sight line & non-spill screw down lid.
Flush Tank: 100L
Frame: Galvanised RHS steel construction with adjustable drawbar and operator platform.
Agitation: 2 stage agitation. Bypass action and Venturi agitation.
Filtration: Lid strainer, suction line filter.
Wheel Equipment: 2m track axle with 14.9 x 24" lug tyre
Bottom Fill: Bottom fill valve with camlock coupling.
Options:
- BP200/20 pump, 195 L/min. capacity, 2000kPa pressure
- Hydraulic drive centrifugal pump
- 5 section Silvamatic electric controls (in lieu)
- Bravo 180S automatic rate controller (in lieu)
- Bravo 180S automatic rate controller to suit hydraulic control (in lieu)
- Bravo 400S automatic rate controller with GPS guidance (in lieu)
- IBX 100 ISOBUS controller (in lieu - requires compatible in-cab console)
- Mudguards (to suit 14.9 x 24 wheels)
- Adjustable track axle (minimum 1500mm) with 11.2 x 44 Lug tyres (2500L only)
- 57L Paddock Foam Marker
- Venturi suction probe
- Silmix Chemical Hopper
- 3 Section electric over hydraulic control
- 5 Section electric over hydraulic control
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN 3,000L PADDOCK PAK TRAILED SPRAYER (18M BOOM)

This Low Profile 2,270L rainwater tank provides a handy supplement to your households main water supply for a range of uses such as garden irrigation and laundry. As with all Polymaster rainwater tanks, this certified tank is manufactured with strength in mind.
When you invest in a rainwater tank its important that you get one that lasts and is fit for purpose. Australian standards are put in place to give households, peace of mind when it comes a tanks usability.
Dimensions:
Capacity : 2,270 L (500 gallons)
Diameter: 1,700 mm
Inlet Height : 1,200 mm
Overall Height : 1,310 mm
Features:
- Self supporting roof means no support poles are necessary
- One piece construction means no joins or seams
- Solid brass threaded outlet & ball valve as standard
- Upgraded outlet and ball valves are available at an additional cost
- Certified to AS/NZS 4766:2006 Standard
- Outlet standard position 6 o'clock
- Outlet position can be moved from standard based on positions on the Fit Out Clock
- Replacement manhole covers and strainers available
- Available in 22 Colours
- 90mm overflow as standard
Standard Fit Out:
Strainer Position: 12 o'clock
Outlet Position: 6 o'clock
Overflow Position: 11 o'clock
Strainer Size: 400 mm
Outlet: 25 mm (brass)
Ball Valve : 25 mm
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available.
Contact Farm Supplies today for sale or more information.
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

POLYMASTER 2,270L RAINWATER TANK (LOW PROFILE)

This Low Profile 4,500L rainwater tank provides a handy supplement to your households main water supply for a range of uses such as garden irrigation and laundry. As with all Polymaster rainwater tanks, this certified tank is manufactured with strength in mind.
When you invest in a rainwater tank its important that you get one that lasts and is fit for purpose. Australian standards are put in place to give households, peace of mind when it comes a tanks usability.
Dimensions:
Capacity : 4,500 L (1,000 gallons)
Diameter: 2,150 mm
Inlet Height : 1,380 mm
Overall Height : 1,580 mm
Features:
- Self supporting roof means no support poles are necessary
- One piece construction means no joins or seams
- Solid brass threaded outlet & ball valve as standard
- Upgraded outlet and ball valves are available at an additional cost
- Certified to AS/NZS 4766:2006 Standard
- Outlet standard position 6 o'clock
- Outlet position can be moved from standard based on positions on the Fit Out Clock
- Replacement manhole covers and strainers available
- Available in 22 Colours
- 90mm overflow as standard
Standard Fit Out:
Strainer Position: 12 o'clock
Overflow Position : 11 o'clock
Outlet Position: 6 o'clock
Strainer Size: 400 mm
Outlet Size : 25 mm (brass)
Ball Valve: 25 mm
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available.
Contact Farm Supplies today for sale or more information.
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

POLYMASTER 4,500L RAINWATER TANK (LOW PROFILE)

Find Farm Machinery For Sale. Browse 7617 listings from Farm Supplies Machinery & Equipment.

New & Used Farm Machinery For Sale

Farm Supplies Machinery & Equipment

Sale Price

MURRAY SERIES 03 LEVELLING HARROW 4.19M, 4 RANK DEEP SECTIONS & STD DRAWBARS-HEAVY DUTY-COMPLETE SET

MURRAY HYDRAULIC BALE GRAB- 15 BALE, 3PL- SERIES 56

JOHN BERENDS DEEP TILLAGE PLOUGHS 2 TINE - 0321, MIN 30HP

SILVAN 2,000L (2 ROW) TRAILED SCRAM CROSS - MIN 60PTO HP

SILVAN 180L VOLUMEX GRANULAR APPLICATOR (2 -4 DROPPERS) 12V MOTOR NOT INCLUDED

RATA 2.4M TELEHANDLER ROUNDED SHELL BUCKET

MURRAY 2.84M MOUNTED SPRING TINE HARROW SYSTEM - LIGHT DUTY - 2 RANK

JOHN BERENDS EP100 MEDIUM DUTY SLASHERS 1M - 0051- 18-30HP

JOHN BERENDS MEDIUM DUTY OFFSET DISCS - 12 PLATE X 20 INCH DISCS - 0248, MIN 25HP

SILVAN 3,000L PADDOCK PAK TRAILED SPRAYER (18M BOOM)

POLYMASTER 2,270L RAINWATER TANK (LOW PROFILE)

POLYMASTER 4,500L RAINWATER TANK (LOW PROFILE)

Farm Supplies Machinery & Equipment

Dealer Address
