Versatile & Simple Gate Latch
Looking for a simple chain latch to attach to your gate? Our bolt-on double gate latch kits are perfect for secure two or more gates together particularly if they meet at a corner.
Do you have two or more gates that need to be secured shut?
These chain latch kits bolt onto your gate and can loop around a post or another gate. Its perfect if you have a two, three or four gates meeting at a corner.
Are you tired of gates swinging shut when you are running stock through? By having your latch attached to your gate, you can swing the gate open and then latch it onto your fence. This means it wont close at the most inconvenient of times.
Smooth Front Edge
When the latch is mounted, the hook is inside the gate rather than protruding out from the gate frame. This makes it less likely that livestock will be hurt or caught when moving through the gateway.
Adjustable
Our longer chain allows for adjustment as the gate way openings may increase over time.
Versatile
You can use the same latch to go around the post, for double gates, and even three-way gates. This is possible because of our unique 700mm long chains.
Price quoted is for one kit.
Includes gate clamp and spring latch.
Discounts apply for bulk purchases of 10+, 25+, 50+.
Specifications:
- 25NB gate
- 500mm chain length
- 1 x spring hook latch
- 1 x gate clamp
Features:
- Smooth front edge
- Adjustable
- Versatile
How The Latch Works
Our galvanised bolt-on latches are available with either a hook latch or a pin latch.
The pin latch is more secure. The end of the pin is pinched to a point, which is designed to only fit one way into the latch hole. To unlatch your double gates, the pin has to be spun around to be in the correct position in order to be opened.
With the hook latch, we have designed the ring to be on its side for extra security. If the hook accidently gets bumped up, it will hit the top of the ring and fall back down. Whereas, if the ring was horizontal then it would be easier for stock to accidently unlatch it.
By having the ring in a vertical position, it makes it more stock proof. The hook latch is also available as a spring hook.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

ROTECH RURAL 25NB BOLT-ON SPRING HOOK LATCH 500MM- BSCL500

The stump jump chisel plough is an ideal tool for primary cultivation. The spring action of the tines and chisel points have been proven to penetrate where many other machines find conditions too hard.
Features:
5 Tines at 12 adjustable spacings.
Heavy Duty 75x75x6mm Frame.
Cat 1 & 2 Linkage.
65mm Reversible Points as standard.
Silicone chrome spring steel shanks.
Horsepower requirement is approximately 8-10 HP per tine.
Excellent underframe trash clearance of 520mm.
Adjustable spring is designed to give a longer, more progressive action, actually chiselling as the machine moves through the ground.
The wheel kit consists of a pair of 14 Holden wheels, height adjustable, fitted on the outside of the machine (increasing the overall width approx 450mm (18)
Optional Points Available:
Depth Wheels (Pair Holden)
10x8mm Dart Point
16x8mm Sweep
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

JOHN BERENDS STUMP JUMP CHISEL PLOUGHS 5'9" (1.75M) WIDTH - 0192

Machine Suitability:
- Skid Steer Loaders & Excavators (2.5 - 4.5 Tonne)
Features:
- Oil Pressure Range: 160-240 bar
- Oil Flow Range: 35 - 65 lpm
- Unit Width: 850mm
- Unit Height: 736mm
- Unit Length: 1465mm
Please select the frame / hitch and chain suited to your machine and application (listed below in options).
All MT trenchers include Flat Face Couplers and Hydraulic Hoses.
Universal Frame Options (to suit MT range):
- Universal skid steer frame
- Universal mini loader frame
Hitches Options (to suit MT range):
- 30mm PIN
- 35mm PIN
- 38mm PIN
- 40mm PIN
- 45mm PIN
- 50mm PIN
600mm Trenching Depth Chains (to suit MT range):
- 100mm x 600mm - Earth
- 100mm x 600mm - Combination
- 100mm x 600mm - Tungsten
- 150mm x 600mm - Earth
- 150mm x 600mm - Combination
- 150mm x 600mm - Tungsten
- 200mm x 600mm - Earth
- 200mm x 600mm - Combination
- 200mm x 600mm - Tungsten
- 250mm x 600mm - Earth
- 250mm x 600mm - Combination
- 250mm x 600mm - Tungsten
- 300mm x 600mm - Earth
- 300mm x 600mm - Combination
- 300mm x 600mm - Tungsten
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

AUGER TORQUE MT600 TRENCHER SUIT EXCAVATORS / MINI LOADERS

Heavy duty model features a 50×50 RHS frame throughout with larger tines, providing a heavier and more rigid machine for hard ground and primary cultivation.

Note: This model does include a crumbler.

JOHN BERENDS 2.4M S-TINE (16 TINES) HEAVY DUTY CULTIVATOR (WITH CRUMBLER) - MIN 48HP

Series 05 Pastureland Harrow System - Light Duty.
Complete light duty harrow systems available from 1.52m (5ft) to 6.09m (20ft) configurations, in standard/single-mesh and super/double mesh versions. Each set of Murray Pastureland Harrows is supplied complete with a steel drawbar.
The Murray Pastureland Harrow System is recommended for pasture establishment, maintenance and renovation applications. Ideal for breaking down and distributing animal manures and other organic matter evenly across the whole pasture, using a Series 05 will encourage pasture growth. This light duty harrow is suitable generally for pasture areas of less than 100 acres (40 hectares) and tows easily behind small and medium size tractors.
Murray Series 05 Pastureland Harrows utilise four rows of double-sided tripod tine units which slice through patts, clods and coarse vegetation. The tripod section is followed by heavy steel square chain mesh which further pulverises and spreads the manure and organic matter and revitalises the pasture. The standard single-mesh chain Murray Pastureland Harrow has 8 rows of chain complete with a spreader bar and drag weights. Where greater penetration and a more aggressive action is needed, the Murray super double-mesh chain Pastureland Harrow may be used, which has 15 rows of square chain mesh. The extra chain length and weight ensure a thorough processing of material.
The Series 05 Pastureland Harrows can be used in conjunction with the Murray Series 21 3-point linkage Harrow Hoist Frame for ease of transportation.
For larger field operations, Murray Agricultural Equipment manufactures the Series 20 Heavy Duty Pasture Harrow System.
100% Australian made and owned.
Features:
- Tine Spacing 51mm (2in)
- Tine Length 85mm (3 11/32in) approx
- Centre to Centre of Front Hooks 305mm (12in)
Drag Type Standard 0.76m (2ft6in) Deep Mesh Chain:
Model 5020 Coverage: 1.52m (5ft) 82kg
Model 5006 Coverage: 1.83m (6ft) 99kg
Model 5021 Coverage: 2.44m (8ft) 129kg
Model 5022 Coverage: 3.04m (10ft) 172kg
Model 5023 Coverage: 3.65m (12ft) 213kg
Model 5024 Coverage: 4.57m (15ft) 269kg
Model 5003 Coverage: 6.09m (20ft) 380kg
Hoist Lift Type (Series 21) Standard 0.76m (2ft6in) Deep Mesh Chain:
Model 5025 Coverage: 5ft 132kg
Model 5007 Coverage: 6ft 147kg
Model 5026 Coverage: 8ft 179kg
Model 5027 Coverage: 10ft 222kg
Model 5028 Coverage: 12ft 263kg
Model 5029 Coverage: 15ft 332kg
Drag Type Super 1.5m (5ft) Deep Mesh Chain:
Model: 5067 Coverage: 1.52m (5ft) 123kg
Model: 5008 Coverage: 1.83m (6ft) 133kg
Model: 5030 Coverage: 2.44m (8ft) 173kg
Model: 5031 Coverage: 3.04m (10ft) 225kg
Model: 5032 Coverage: 3.65m (12ft) 292kg
Model: 5033 Coverage: 4.57m (15ft) 349kg
Model: 5004 Coverage: 6.09m (20ft) 490kg
Hoist Lift Type (Series 21) Super 1.5m (5ft) Deep Mesh Chain:
Model: 5068 Coverage: 5ft 170kg
Model: 5009 Coverage: 6ft 185kg
Model: 5034 Coverage: 8ft 230kg
Model: 5035 Coverage: 10ft 280kg
Model: 5036 Coverage: 12ft 347kg
Model: 5037 Coverage: 15ft 417kg
Complete Set Comprises of Front Drawbar, Tine section, Mesh Chain section (and Series 21 3-Point Linkage Hoist Frame and Lift connectors if Hoist Lift type specified.
Model Numbers 5029 and 5037 also feature a Model Number 5071 Rear Lift / Hoist extension bar.
Individual panels, chains and parts also available for sale.
* Murray Harrows must be pulled (towed) by a tractor correctly fitted with an approved rollover protection structure. Murray Harrows are NOT intended for use with an ATV or Ride On Lawn Mower.

All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

MURRAY SERIES 05 PASTURELAND LIGHT DUTY HARROW SYSTEMS - (1.52M - 6.09M) WIDTH

Silvan 1.5m (5ft) Heavy Duty Slasher with 100HP gearbox.
Suited to large acreage applications including clearance, firebreaks, private roadsides or where major cutting & cleaning is required.
Features:
- Construction: welded 6mm top deck plate, welded steel side plates with adjustable skids.
- Gearbox: 100HP Series 8, 1:1.93 ratio.
- PTO Shaft Rating: 540RPM
- Head Stock: Collapsible floating hitch.
- Finish: Long lasting galvanized top deck.
- Skids: Adjustable from 50-150mm cutting height.
- Blades: 3 leaf spring steel rotor bar with hardened bushes and 2 Boron step down blades.
- Mounting: Cat. II TPL centre mount attachment.
- Clutch: 8" 2 plate friction clutch.
- Instructions: Operators manual and holder supplied.
- Chain Guards: Front and rear chain guards
Specifications:
- Connection Type: Linkage
- Working Width (mm): 1500
- Overall Width (mm): 1,600
- Cutting Height (mm): 50-150
- Overall Height (mm): 1,020
- Product Weight (kg): 376
Options:
103WRSHC2 - Height Control Wheel (2 recommended for 7' models)
131RSHC2 - Heavy Duty Height Control Wheel
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SILVAN 1.5M (100HP GEARBOX) - INCL ROTOR & CHAIN GUARDS - HEAVY DUTY SLASHER

When it comes to performance the high output Multicut 820 will go way beyond your expectations delivering a massive 8.2 metres of cutting width to effectively eat your way through the greatest of workloads. Couple the Multicut 820 with a powerful tractor of 150HP plus and allow time to roll by as output in excess of 100 hectares per day is easily achievable.
Key to the performance of the machine is the industry leading flat underside deck to maintain mulch quality and consistency of spread over the full cutting area. A six gearbox driveline delivers exceptional power, each with slip clutch protection and a clean cut is delivered by five rotors each carrying three high-lift swinging blades. Extremely robust in construction the Multicut 820 is configured with large wheels, full width walking axles and hydragas suspension to provide a smooth ride.
Features:
Reinforced mega strength deck structure
Built in shock absorbs
Hydragas suspension
Full width walking axle
Heavy duty axle links
Heavy duty implement tyres
Full width front & rear safety chains
Full length side skids
Hydraulic wing lift & support
Premium long lift shaft drive
Dual stand legs
Swivel towing eye
Universal drawbar for high or low towing
Adjustable levelling tie bars
Slip clutch protection
111HP rotor box
Anti-scalp disc
Heavy duty winged updraught blades
250HP splitter box
Integrated seal protector
Includes carrier & hardware for easy fitting of starcut
Specifications:
Machine weight (with front and rear single chain guards): 4,330kg / 9,546lbs
Hitch: Multi-positional drawbar
Cutting width: 8.06m / 26' 5"
Working machine width: 8.26m / 27' 1"
Transport machine width: 2.81m / 9' 3"
Maximum working length: 6.33m / 20' 9"
Transport length: 6.07m / 19' 11"
Deck height (underside of deck to skid): 0.24m / 10"
Transport height: 3.78m / 12' 5"
Cutting height: 25mm 210mm (1" - 1/16")
Cutting capacity: 100mm / 4"
Recommended tractor hp: 150hp / 112kW
Wing working angles: 45 degrees up / 15 degrees down
Power take-off speed: 1,000rpm
Gearbox (splitter): Cast iron housing
Gearbox (rotor gearboxes (x5)): Cast iron housing
Input shaft: 1 - 3/4" Z20 SFT 10 tractor end
Gearbox oil capacity (splitter gearbox): 2.7L / 4.7 pints
Gearbox oil capacity (centre + inner rotor gearboxes): 3.5L / 6.2 pints
Gearbox oil capacity (outer rotor gearboxes (x4)): 2.1L / 3.7 pints
Deck construction: All welded construction
Deck material thickness: 5mm (3/16")
Side skirt material thickness: 6mm (4/16")
Skid construction: Replaceable bolt on skid shoes
Anti-scalp dish (outer wing rotors): 6mm (1/4") round pan with blade holder bar
Blades (x15): 12mm (1/2") 30 carbon boron hardened and tempered. Free swinging high lift low friction. Handed.
Blade bolts: M24 C/W shank grade 8.8
Blade tip speed (1,000rpm): 79mps / 15551fpm
Driveline: ASAE Category 4
Driveline protection: 2/4-way slip clutches on rotor gearboxes. Overrun on input shaft
Tailwheel mount assemblies: Tubular welded walking axles
Tailwheels (x8): 7 - 12 pneumatic tyre with steel hub
Front & guards: Single chain guards on each deck
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

FIELDQUIP MULTICUT 820 FLEX WING SLASHER (MIN 150HP)

Drawbar Clevis. Hole Diameter: M16 x 1.5mm.
Suits tractor models shown in images.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SPAREX DRAWBAR CLEVIS (HOLE DIA = M16 X 1.5MM)

Counterweights are important in maintaining the stability of the tractor when using front end loaders. With a front end loader fitted onto a tractor, the centre of gravity shifts forward. The centre of gravity is further amplified when the loader lifts a load thus putting pressure on the tyres, axle and rims.

To eliminate such risks, a 3 point linkage should be used. The counterweight is hooked up with a 3 point linkage set behind the rear axle. This is the best method to improve stability and it reduces the amount of pressure placed on the tyres, axle and rims.

BURDER 500KG CONCRETE COUNTER WEIGHT (3PL) - CAT 2

Top Link Ball (Cat. 3/2).
Specifications shown in images.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SPAREX TOP LINK BALL (CAT 3/2) (ID: 1'', OD: 2 3/8'', WIDTH: 2 1/16'')

Swather / Tedder Tine.
Specifications shown in images.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

GRANGE & WALTER SWATHER / TEDDER TINE - 550MM LENGTH - REPLACEMENT FOR SIP

Cow Lifter Hip Shoof Quick-Lift Complete.
Quick-Lift is Shoof's new quick-release cow lifter. Lightweight and easy to use, Quick-Lift features large, 50mm-o.d. pipe making it a more comfortable fit on the cow.
Quick-Lift is simply slipped onto the pin bones and ratcheted tight with a few quick strokes on the ratchet lever.
If the cow needs to be released quickly, the ratchet lever is simply pulled down and the clamp instantly opens. Quick, easy, no fuss.
No handle to lose, or spindle to damage or bend. Replacement ratchet assembly is available (complete with strap) and is easily fitted.
This is a great device.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

SHOOF COW LIFTER QUICK-LIFT COMPLETE

Find Farm Machinery For Sale in Coopers Plains. Browse 7607 listings from Farm Supplies Machinery & Equipment.

New & Used Farm Machinery For Sale in Coopers Plains

Farm Supplies Machinery & Equipment

Sale Price

ROTECH RURAL 25NB BOLT-ON SPRING HOOK LATCH 500MM- BSCL500

JOHN BERENDS STUMP JUMP CHISEL PLOUGHS 5'9" (1.75M) WIDTH - 0192

AUGER TORQUE MT600 TRENCHER SUIT EXCAVATORS / MINI LOADERS

JOHN BERENDS 2.4M S-TINE (16 TINES) HEAVY DUTY CULTIVATOR (WITH CRUMBLER) - MIN 48HP

MURRAY SERIES 05 PASTURELAND LIGHT DUTY HARROW SYSTEMS - (1.52M - 6.09M) WIDTH

SILVAN 1.5M (100HP GEARBOX) - INCL ROTOR & CHAIN GUARDS - HEAVY DUTY SLASHER

FIELDQUIP MULTICUT 820 FLEX WING SLASHER (MIN 150HP)

SPAREX DRAWBAR CLEVIS (HOLE DIA = M16 X 1.5MM)

BURDER 500KG CONCRETE COUNTER WEIGHT (3PL) - CAT 2

SPAREX TOP LINK BALL (CAT 3/2) (ID: 1'', OD: 2 3/8'', WIDTH: 2 1/16'')

GRANGE & WALTER SWATHER / TEDDER TINE - 550MM LENGTH - REPLACEMENT FOR SIP

SHOOF COW LIFTER QUICK-LIFT COMPLETE

Farm Supplies Machinery & Equipment

Dealer Address
