Bigfoot XD Trencher 1200mm dig - 150mm earth chain with crumber bar - 2 inch chain - front mounted.
Price inclusions: 600 to 1200mm dig trencher, chain, standard frame, 2.2m hoses & couplers.
Suits 4.5 tonne to 8 tonne machines.
Tractor requires Hydrostatic / Vario Transmission.
Ideal Use:
- Can be used for pipe laying for irrigation, underground power / communications, road repairs and general construction.
Ideal for excavators up to 8 tonne, skid steer loaders, backhoes, and tractors, the Bigfoot XD Trencher can be used for pipe laying for irrigation, underground power & communications, road repairs, general construction.
An evolution from our Bigfoot Trencher with a greater trench digging depth of up to 1500mm.
Fitted with a patent pending Head Start Crumber system, quality Digga Planetary Drive & Eaton Hydraulic Motor, adjustable skid foot and single spoil removal auger for consistent digging depth.
Our unique design promotes efficient spoil removal and finely crumbled spoil for effective compaction back into the trench.
This provides minimal ground disturbance to surrounding conditions and results in a cleaner finish.
Earth Chain:
Earth Tooth on every Second Station.
Best for soft clean ground with no floaters or tree roots.
Chain sizes available:
- 150mm
- 200mm
- 250mm
- 300mm
Features:
- Head Start Crumber System (patent pending) with steel scraper shoe begin trenching with the crumber down and save time by not having to get out of your machine.
- Adjustable skid foot features 4 preset digging depths. Highly visible and can be seen from the cab. No spotter required..
- Up to 1500mm dig depth & 300mm digging width with a 50.8mm chain 3 different chain options available: Earth, Combo, and Diggatac.
- Standard Flow XD range features a compact, yet powerful Digga planetary drive High flow XD models come with a 6K Eaton hydraulic motor.
- Frame can be side shifted for digging close to permanent structures.
Specifications:
- Cutting Width: 150 / 200 /250 / 300 mm
- Foot Depth Presets:600 / 800 / 1000/ 1200 mm
- Recommended Flow (lpm) 60-115
- Motor Size: 2K Bell EATON
- Max Pressure - Do not exceed 240 bar @ 60 lpm
- Max Flow - Do not exceed 95 lpm @ 200 bar
- Max Continuous Power 25 Kw (34 hp)
- Length: 2532 mm
- Horizontal Height: 777 mm
- Width: 1212 mm
- Weight - With a 150mm Combo Chain 405 kg
See photos for more information and specifications.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

DIGGA BIGFOOT XD 1200MM DIG TRENCHER - 150MM EARTH CHAIN WITH CRUMBER BAR

Bigfoot Trencher 600-900mm dig - 100mm earth chain with crumber bar. - 1 5/8 inch chain - front loaded.
Price inclusions: 600 to 900mm dig trencher, chain, standard frame, 2.2m hoses & couplers.
Suits 1.5 tonne to 4.5 tonne machines.
Tractor requires Hydrostatic / Vario Transmission.
A compact yet powerful trencher fitted with a quality Digga Planetary Drive & Eaton Hydraulic Motor, 3 position-adjustable skid foot and single spoil removal auger.
Unique design gives the operator consistent digging depth, efficient spoil removal and finely crumbled spoil for effective compaction back into the trench whilst providing minimal ground disturbance to surrounding conditions and a cleaner job finish.
Ideal Use:
Pipe laying for irrigation, underground power and
communications, road repairs and general construction.
Earth Chain:
Earth Tooth on every Second Station.
An Earth tooth configuration is best suited for soft clean ground with no floaters or tree roots like earth and clay.
Chain sizes available:
- 100mm
- 150mm
- 200mm
Features:
- Head Start Crumber System (patent pending) - start trenching with the crumber in the down position saving time by not having to get out of the machine
- Highly visible foot can be seen from the cab. No spotter required
- Adjustable skid foot features 3 preset digging depths
- Up to 900mm digging depth and 200mm digging width
- 3 different chain options - Earth, Combo, and Diggatac
- Compact, yet powerful Australian Made planetary drive
- Frame can be side shifted to dig close to permanent structures
Specifications:
- Cutting Width: 100mm
- Foot Depth Presets: 600 / 750 / 900 mm
- Hydraulic Flow: 50-95 lpm
- Motor Size: 2K Bell EATON
- Max Pressure - Do not exceed 240 bar @ 60 lpm
- Max Flow - Do not exceed 95 lpm @ 200 bar
- Max Continuous Power 25 Kw (34 hp)
- Length: 1920 mm
- Horizontal Height: 668 mm
- Width: 1212 mm
- Weight - With a 150mm Combo Chain 261 kg
See photos for more information and specifications.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

DIGGA BIGFOOT TRENCHER 900MM DIG- 100MM EARTH CHAIN WITH CRUMBER BAR

Combination of Diggatac Carbine Teeth
and Earth Teeth.

Cut through hard soil, roots, soft shale, and rocky ground.

DIGGA BIGFOOT XD TRENCHER 900MM DIG - 150MM COMBO CHAIN WITH CRUMBER BAR

Bigfoot Trencher 600-900mm dig - 100mm Diggatac (Tungsten carbide) chain with crumber bar. - 1 5/8 inch chain - front mounted.
Suits 1.5 tonne to 4.5 tonne machines.
Tractor requires Hydrostatic / Vario Transmission.
Price inclusions: 600 to 900mm dig trencher, chain, standard frame, 2.2m hoses & couplers.
A compact yet powerful trencher fitted with a quality Digga Planetary Drive & Eaton Hydraulic Motor, 3 position-adjustable skid foot and single spoil removal auger.
Unique design gives the operator consistent digging depth, efficient spoil removal and finely crumbled spoil for effective compaction back into the trench whilst providing minimal ground disturbance to surrounding conditions and a cleaner job finish.
Ideal Use:
Pipe laying for irrigation, underground power and
communications, road repairs and general construction.
Multi-purpose combination chain:
Get the best from both worlds with a multipurpose chain configuration.
Diggatac for hard ground conditions:
100% Diggatac Carbine Tooth
The DIGGATAC tungsten carbide chain configuration provides extended tooth life and reduced vibration, particularly when starting in tough conditions such as rocky hard shale, asphalt or frozen ground.
Best used in hard or frozen ground conditions and asphalt.
Chain sizes available:
- 100mm
- 150mm
- 200mm
Features:
- Head Start Crumber System (patent pending) - start trenching with the crumber in the down position saving time by not having to get out of the machine
- Highly visible foot can be seen from the cab. No spotter required
- Adjustable skid foot features 3 preset digging depths
- Up to 900mm digging depth and 200mm digging width
- 3 different chain options - Earth, Combo, and Diggatac
- Compact, yet powerful Australian Made planetary drive
- Frame can be side shifted to dig close to permanent structures
Specifications:
- Cutting Width: 100mm
- Foot Depth Presets: 600 / 750 / 900 mm
- Hydraulic Flow: 50-95 lpm
- Motor Size: 2K Bell EATON
- Max Pressure - Do not exceed 240 bar @ 60 lpm
- Max Flow - Do not exceed 95 lpm @ 200 bar
- Max Continuous Power 25 Kw (34 hp)
- Length: 1920 mm
- Horizontal Height: 668 mm
- Width: 1212 mm
- Weight - With a 150mm Combo Chain 261 kg
See photos for more information and specifications.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

DIGGA BIGFOOT TRENCHER 900MM DIG - 100MM TUNGSTEN CARBIDE (DIGGATAC) CHAIN WITH CRUMBER BAR

Bigfoot Trencher 600-900mm dig - 100mm Combo chain with crumber bar. - 1 5/8 inch chain - front mounted.
Suits 1.5 tonne to 4.5 tonne machines.
Tractor requires Hydrostatic / Vario Transmission.
Price inclusions: 600 to 900mm dig trencher, chain, standard frame, 2.2m hoses & couplers.
A compact yet powerful trencher fitted with a quality Digga Planetary Drive & Eaton Hydraulic Motor, 3 position-adjustable skid foot and single spoil removal auger.
Unique design gives the operator consistent digging depth, efficient spoil removal and finely crumbled spoil for effective compaction back into the trench whilst providing minimal ground disturbance to surrounding conditions and a cleaner job finish.
Multi-purpose Combination chain:
Combination of Diggatac Carbine Teeth
and Earth Teeth.
Cut through hard soil, roots, soft shale, and rocky ground.
Ideal Use:
Pipe laying for irrigation, underground power and
communications, road repairs and general construction.
Multi-purpose combination chain:
Get the best from both worlds with a multipurpose chain configuration.
Chain sizes available:
- 100mm
- 150mm
- 200mm
Features:
- Head Start Crumber System (patent pending) - start trenching with the crumber in the down position saving time by not having to get out of the machine
- Highly visible foot can be seen from the cab. No spotter required
- Adjustable skid foot features 3 preset digging depths
- Up to 900mm digging depth and 200mm digging width
- 3 different chain options - Earth, Combo, and Diggatac
- Compact, yet powerful Australian Made planetary drive
- Frame can be side shifted to dig close to permanent structures
Specifications:
- Cutting Width: 100mm
- Foot Depth Presets: 600 / 750 / 900 mm
- Hydraulic Flow: 50-95 lpm
- Motor Size: 2K Bell EATON
- Max Pressure - Do not exceed 240 bar @ 60 lpm
- Max Flow - Do not exceed 95 lpm @ 200 bar
- Max Continuous Power 25 Kw (34 hp)
- Length: 1920 mm
- Horizontal Height: 668 mm
- Width: 1212 mm
- Weight - With a 150mm Combo Chain 261 kg
See photos for more information and specifications.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

DIGGA BIGFOOT TRENCHER 900MM DIG,100MM COMBO CHAIN WITH CRUMBER BAR

Bigfoot XD Trencher 1200mm dig - 150mm earth chain with crumber bar - 2 inch chain - front mounted.
Price inclusions: 600 to 1200mm dig trencher, chain, standard frame, 2.2m hoses & couplers.
Suits 4.5 tonne to 8 tonne machines.
Tractor requires Hydrostatic / Vario Transmission.
Ideal Use:
- Can be used for pipe laying for irrigation, underground power / communications, road repairs and general construction.
Ideal for excavators up to 8 tonne, skid steer loaders, backhoes, and tractors, the Bigfoot XD Trencher can be used for pipe laying for irrigation, underground power & communications, road repairs, general construction.
An evolution from our Bigfoot Trencher with a greater trench digging depth of up to 1500mm.
Fitted with a patent pending Head Start Crumber system, quality Digga Planetary Drive & Eaton Hydraulic Motor, adjustable skid foot and single spoil removal auger for consistent digging depth.
Our unique design promotes efficient spoil removal and finely crumbled spoil for effective compaction back into the trench.
This provides minimal ground disturbance to surrounding conditions and results in a cleaner finish.
Combination chain:
Combination of Diggatac Carbine Teeth
and Earth Teeth.
Get the best from both worlds with a multipurpose chain configuration. Cut through hard soil, roots, soft shale, and rocky ground.
Chain sizes available:
- 150mm
- 200mm
- 250mm
- 300mm
Features:
- Head Start Crumber System (patent pending) with steel scraper shoe begin trenching with the crumber down and save time by not having to get out of your machine.
- Adjustable skid foot features 4 preset digging depths. Highly visible and can be seen from the cab. No spotter required..
- Up to 1500mm dig depth & 300mm digging width with a 50.8mm chain 3 different chain options available: Earth, Combo, and Diggatac.
- Standard Flow XD range features a compact, yet powerful Digga planetary drive High flow XD models come with a 6K Eaton hydraulic motor.
- Frame can be side shifted for digging close to permanent structures.
Specifications:
- Cutting Width: 150 / 200 /250 / 300 mm
- Foot Depth Presets:600 / 800 / 1000/ 1200 mm
- Recommended Flow (lpm) 60-115
- Motor Size: 2K Bell EATON
- Max Pressure - Do not exceed 240 bar @ 60 lpm
- Max Flow - Do not exceed 95 lpm @ 200 bar
- Max Continuous Power 25 Kw (34 hp)
- Length: 2532 mm
- Horizontal Height: 777 mm
- Width: 1212 mm
- Weight - With a 150mm Combo Chain 405 kg
See photos for more information and specifications.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

DIGGA BIGFOOT XD 1200MM DIG TRENCHER - 150MM COMBO CHAIN WITH CRUMBER BAR

Bigfoot XD Trencher 1200mm dig - 150mm Diggatac (Tungsten Carbide) chain with crumber bar - 2 inch chain - front mounted.
Price inclusions: 600 to 1200mm dig trencher, chain, standard frame, 2.2m hoses & couplers.
Suits 4.5 tonne to 8 tonne machines.
Tractor requires Hydrostatic / Vario Transmission.
Ideal Use:
- Can be used for pipe laying for irrigation, underground power / communications, road repairs and general construction.
Ideal for excavators up to 8 tonne, skid steer loaders, backhoes, and tractors, the Bigfoot XD Trencher can be used for pipe laying for irrigation, underground power & communications, road repairs, general construction.
An evolution from our Bigfoot Trencher with a greater trench digging depth of up to 1500mm.
Fitted with a patent pending Head Start Crumber system, quality Digga Planetary Drive & Eaton Hydraulic Motor, adjustable skid foot and single spoil removal auger for consistent digging depth.
Our unique design promotes efficient spoil removal and finely crumbled spoil for effective compaction back into the trench.
This provides minimal ground disturbance to surrounding conditions and results in a cleaner finish.
Diggatac chain:
100% Diggatac Carbine Tooth.
The Diggatac tungsten carbide chain configuration provides extended tooth life and reduced vibration, particularly when starting in tough conditions such as rocky hard shale, asphalt or frozen ground.
Chain sizes available:
- 150mm
- 200mm
- 250mm
- 300mm
Features:
- Head Start Crumber System (patent pending) with steel scraper shoe begin trenching with the crumber down and save time by not having to get out of your machine.
- Adjustable skid foot features 4 preset digging depths. Highly visible and can be seen from the cab. No spotter required..
- Up to 1500mm dig depth & 300mm digging width with a 50.8mm chain 3 different chain options available: Earth, Combo, and Diggatac.
- Standard Flow XD range features a compact, yet powerful Digga planetary drive High flow XD models come with a 6K Eaton hydraulic motor.
- Frame can be side shifted for digging close to permanent structures.
Specifications:
- Cutting Width: 150 / 200 /250 / 300 mm
- Foot Depth Presets:600 / 800 / 1000/ 1200 mm
- Recommended Flow (lpm) 60-115
- Motor Size: 2K Bell EATON
- Max Pressure - Do not exceed 240 bar @ 60 lpm
- Max Flow - Do not exceed 95 lpm @ 200 bar
- Max Continuous Power 25 Kw (34 hp)
- Length: 2532 mm
- Horizontal Height: 777 mm
- Width: 1212 mm
- Weight - With a 150mm Combo Chain 405 kg
See photos for more information and specifications.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

DIGGA BIGFOOT XD 1200MM DIG TRENCHER - 150MM TUNGSTEN CARBIDE (DIGGATAC) CHAIN WITH CRUMBER BAR

Bigfoot XD Trencher 900mm dig - 150mm Diggatac (Tungsten Carbide) chain with crumber bar. - 2 inch chain - Front mounted.
Price inclusions: 450 to 900mm dig trencher, chain, standard frame, 2.2m hoses & couplers.
Suits 4.5 tonne to 8 tonne machines.
Tractor requires Hydrostatic / Vario Transmission.
Ideal for excavators up to 8 tonne, skid steer loaders, backhoes, and tractors, the Bigfoot XD Trencher can be used for pipe laying for irrigation, underground power & communications, road repairs, general construction.
An evolution from our Bigfoot Trencher with a greater trench digging depth of up to 1500mm.
Fitted with a patent pending Head Start Crumber system, quality Digga Planetary Drive & Eaton Hydraulic Motor, adjustable skid foot and single spoil removal auger for consistent digging depth.
Our unique design promotes efficient spoil removal and finely crumbled spoil for effective compaction back into the trench.
This provides minimal ground disturbance to surrounding conditions and results in a cleaner finish.
Diggatac for hard ground conditions:
100% Diggatac Carbine Tooth.
The DIGGATAC tungsten carbide chain configuration provides extended tooth life and reduced vibration, particularly when starting in tough conditions such as rocky hard shale, asphalt or frozen ground.
Ideal Use:
- Can be used for pipe laying for irrigation, underground power / communications, road repairs and general construction.
Chain sizes available:
- 150mm
- 200mm
- 250mm
- 300mm
Features:
- Head Start Crumber System (patent pending) with steel scraper shoe begin trenching with the crumber down and save time by not having to get out of your machine
- Adjustable skid foot features 4 preset digging depths. Highly visible and can be seen from the cab. No spotter required
- Up to 1500mm dig depth & 300mm digging width with a 50.8mm chain 3 different chain options available: Earth, Combo, and Diggatac
- Standard Flow XD range features a compact, yet powerful Digga planetary drive High flow XD models come with a 6K Eaton hydraulic motor
- Frame can be side shifted for digging close to permanent structures
Ideal Use:
- Can be used for pipe laying for irrigation, underground power / communications, road repairs and general construction.
Specifications:
- Cutting Width: 150 / 200 /250 / 300 mm
- Foot Depth Presets: 450 / 600 / 750 / 900 mm
- Recommended Flow (lpm) 60-115
- Motor Size: 2K Bell EATON
- Max Pressure - Do not exceed 240 bar @ 60 lpm
- Max Flow - Do not exceed 95 lpm @ 200 bar
- Max Continuous Power 25 Kw (34 hp)
- Length: 2225 mm
- Horizontal Height: 777 mm
- Width: 1212 mm
- Weight - With a 150mm Combo Chain 388 kg
See photos for more information and specifications.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

DIGGA BIGFOOT XD TRENCHER 900MM DIG - 150MM TUNGSTEN CARBIDE (DIGGATAC) CHAIN WITH CRUMBER BAR

Bigfoot XD Trencher 900mm dig - 150mm earth chain with crumber bar. - 2 inch chain - Front mounted.
Price inclusions: 450 to 900mm dig trencher, chain, standard frame, 2.2m hoses & couplers.
Suits 4.5 tonne to 8 tonne machines.
Tractor requires Hydrostatic / Vario Transmission.
Ideal for excavators up to 8 tonne, skid steer loaders, backhoes, and tractors, the Bigfoot XD Trencher can be used for pipe laying for irrigation, underground power & communications, road repairs, general construction.
An evolution from our Bigfoot Trencher with a greater trench digging depth of up to 1500mm.
Fitted with a patent pending Head Start Crumber system, quality Digga Planetary Drive & Eaton Hydraulic Motor, adjustable skid foot and single spoil removal auger for consistent digging depth.
Our unique design promotes efficient spoil removal and finely crumbled spoil for effective compaction back into the trench.
This provides minimal ground disturbance to surrounding conditions and results in a cleaner finish.
Earth Chain:
Earth Tooth on every Second Station.
An EARTH tooth configuration is best suited for soft clean ground with no floaters or tree roots like earth and clay.
Chain sizes available:
- 150mm
- 200mm
- 250mm
- 300mm
Features:
- Head Start Crumber System (patent pending) with steel scraper shoe begin trenching with the crumber down and save time by not having to get out of your machine
- Adjustable skid foot features 4 preset digging depths. Highly visible and can be seen from the cab. No spotter required
- Up to 1500mm dig depth & 300mm digging width with a 50.8mm chain 3 different chain options available: Earth, Combo, and Diggatac
- Standard Flow XD range features a compact, yet powerful Digga planetary drive High flow XD models come with a 6K Eaton hydraulic motor
- Frame can be side shifted for digging close to permanent structures
Ideal Use:
- Can be used for pipe laying for irrigation, underground power / communications, road repairs and general construction.
Specifications:
- Cutting Width: 150 / 200 /250 / 300 mm
- Foot Depth Presets: 450 / 600 / 750 / 900 mm
- Recommended Flow (lpm) 60-115
- Motor Size: 2K Bell EATON
- Max Pressure - Do not exceed 240 bar @ 60 lpm
- Max Flow - Do not exceed 95 lpm @ 200 bar
- Max Continuous Power 25 Kw (34 hp)
- Length: 2225 mm
- Horizontal Height: 777 mm
- Width: 1212 mm
- Weight - With a 150mm Combo Chain 388 kg
See photos for more information and specifications.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

DIGGA BIGFOOT XD TRENCHER 900MM DIG - 150MM EARTH CHAIN WITH CRUMBER BAR

Find Trenchers For Sale from Farm Supplies Machinery & Equipment.

New & Used Trenchers For Sale in Australia

Farm Supplies Machinery & Equipment

Sale Price

DIGGA BIGFOOT XD 1200MM DIG TRENCHER - 150MM EARTH CHAIN WITH CRUMBER BAR

DIGGA BIGFOOT TRENCHER 900MM DIG- 100MM EARTH CHAIN WITH CRUMBER BAR

DIGGA BIGFOOT XD TRENCHER 900MM DIG - 150MM COMBO CHAIN WITH CRUMBER BAR

DIGGA BIGFOOT TRENCHER 900MM DIG - 100MM TUNGSTEN CARBIDE (DIGGATAC) CHAIN WITH CRUMBER BAR

DIGGA BIGFOOT TRENCHER 900MM DIG,100MM COMBO CHAIN WITH CRUMBER BAR

DIGGA BIGFOOT XD 1200MM DIG TRENCHER - 150MM COMBO CHAIN WITH CRUMBER BAR

DIGGA BIGFOOT XD 1200MM DIG TRENCHER - 150MM TUNGSTEN CARBIDE (DIGGATAC) CHAIN WITH CRUMBER BAR

DIGGA BIGFOOT XD TRENCHER 900MM DIG - 150MM TUNGSTEN CARBIDE (DIGGATAC) CHAIN WITH CRUMBER BAR

DIGGA BIGFOOT XD TRENCHER 900MM DIG - 150MM EARTH CHAIN WITH CRUMBER BAR

Farm Supplies Machinery & Equipment

Dealer Address
