Tubeline Bale Wrapper TL1700SR
Hydraulically powered, the TL1700SR can easily switch between round and square bales by moving the secondary drive shaft on either of the appropriate stub shafts. Each stub shaft changes the drive ratio to provide the appropriate advancement of the bale. When the carrier arm is placed in the wrapping position, the carrier can be raised or lowered, centering the wrap on the bale to provide even plastic coverage throughout the wrapping process. The TL1700SR is also equipped with Tubelines Offset Twin Wrap Kit which laminates two layers together to form a stronger 2-ply layer of plastic. The offset provides up to a 4 lead increasing the amount of overlap for greater protection.
The wrappers integrated bale mat protects the wrapped bale from being punctured as it is dumped, while the bale bumper ensures the bale lands far enough away from the wrapper so the table can rotate while the next bale is started. After dumping the bale, one of the two integrated knives easily slices through the plastic wrap. An easy to use wrap counter allows you to set the desired number of rotations of wrap per bale and displays the current rotation.
Specifications:
Bale Size (Round): 4ft x 4ft (121cm x 121cm) to 5ft x 5ft 6in (152cm x 167cm)
Bale Size (Square): 3ft High x 3ft Wide Bales up to 7ft Long (91cm High x 91cm Wide Bales up to 213cm Long)
Film Width: 30in (x2) 76.2cm (x2)
Length: 192in (488cm)
Width: 82in (208cm)
Height: 95in (241cm)
Weight: 2,865 lbs. (1300kgs)
HP Required: 13 HP
hitch: Trailer (Clevis)
Drive Type: Hydraulic
Bale Guides: 2
Offset Twin Wrap: Standard
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

TUBELINE ROUND & SQUARE BALE WRAPPER - TL1700SR

Tanco Round Bale Wrapper S100
Tanco has always been synonymous with the development of satellite wrapping systems. The S100 A is the entry model to the renowned S series and delivers many of the great features of the series at an affordable price.
The S100 A is fully automatic with all controls managed through the RDS Expert controller. Bales can be wrapped in the field or the yard with the unique Wrap & Stack feature. Compact and lightweight, this model is also ideally suited for hilly conditions as bale movement is reduced to a minimum during wrapping.
Furthermore, bales can be placed on their flat end with the optional End-Tip kit, ensuring bales do not roll once off-loaded.
Standard Features
Tanco Dual Stretch Aluminium Dispenser with 55% and 70% stretch options built in.
Individually driven pick-up rollers.
Single dispenser.
Telescopic cut and start.
RDS Expert Controller.
Optional Extras
End-Tip Kit, places bales on their end where plastic coverage is greatest and avoids bales rolling.
Ground roller takes the weight of the bale and machine in cases of lighter tractors.
Radio remote control.
6 and 4 metre extension cables.
Specifications
Height in Transport: 22.4m
Transport Width: 1.4m
Transport Length: 2.3m
Weight: 720kgs
Maximum Bale Diameter: 1.5m
Maximum Bale Weight: 1200 kg
Hydraulic Connection: Single Working and Free Return
Oil Pressure: 180 bar/2600psi
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

TANCO ROUND BALE WRAPPER - S100

Static wrapping is considered to be the most reliable and best method, as bales are handled to a minimum after wrapping.
The A200 EH static wrapper ensures that a quality wrap is applied in an even and efficient manner.
The A200 EH Static can either be mounted and powered directly from the tractor or operated as a standalone unit, independently powered.
As a static wrapper the A200 EH also has a convenient Remote Control as standard, which allows the user to operate the wrapper without leaving the cab.
The A200 EH has an upgraded Valve Block resulting in a more efficient hydraulic system, making this wrapper ideally suited for running with low-power Hydraulic Power Packs
Specif actions - A200EH
Height: 2110mm
Width: 1870mm
Length: 2300mm
Weight: 740 kg
Wrapping Table Speed: 30 R.P.M.
Maximum Bale Diameter: 1500mm
Maximum Bale Weight: 1200kg
Capacity: 35 Bales per hour (Apx.)
Pre-Stretcher(s): 1 x 750mm Width; 55 and 70 percent Stretch
Hydraulic Connection: 2 x 1/2" m.c.
Oil Pressure: 150 bar
Oil Amount: 25 lts/min)
Maximum Counter Pressure: 10 bar
Electrical Connection: 12 V DC
Please allow extra for freight
Operational Video: https://youtu.be/TV4j-i8EQ2k
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

TANCO A200EH STATIC ROUND BALE WRAPPER

The Tanco VariWrap System is our most advanced and versatile wrapping system to date. Incorporating 25 years of experience the VariWrap System delivers the highest levels of performance and reliability.
The VariWrap sees the introduction of Proportional Hydraulic Control. This allows for incremental speed adjustment, ensuring a smooth and more consistent wrapping operation.
This VariWraps smooth operation is managed through a Single Hydraulic Block, resulting in less vibration and longer life.
Specifications:
Height: 2360mm.
Width: 1400mm.
Length: 2230mm.
Weight: 835kgs.
Wrapping Arm Speed (Recommended): 28 R.P.M.
Wrapping Arm Speed (max): 32 R.P.M.
Maximum Bale Diameter: 1.500mm.
Maximum Bale Weight: 1200 kg.
Pre-Stretcher(s): 1 x 750mm Width; 55 and 70 percent Stretch.
Hydraulic Connection: Single Working + Free Return.
Oil Pressure: 180 bar.
Maximum Counter Pressure: 10 bar.
Electrical Connection: 12V DC.
Features:
Twin Drive Motors.
Fully Automatic Operation.
Single Dispenser.
Direct Gear Drive to Satellite Arms.
Ultra Reliable Telescopic Cut & Start.
RDS Expert Controller.
Unique Dual Stretch Aluminium Dispenser (55 and 70 percent).
Options:
End-Tip Kit.
Ground Roller Kit.
Film Break Sensor.
Radio Remote Control Kit.
Dispenser Gear 33 percent.
Hydraulic Pressure Filter.
Load Sensing Kit.
4x Film Roll Holders.
Universal Adaptor for Loader Mounting.
Brackets Available for all modern Tractors & Loaders.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE

TANCO VARIWRAP ROUND BALE WRAPPER

The A100 EH round bale wrapper is an extremely compact, robust and efficient machine, perfect for farmers and contractors. The A100 EH model has a fully automatic wrapping control system.
It incorporates the use of the RDS Electronic Controller and optional Radio Remote Control. This allows the user to select from a range of operating modes and control the wrapper from the comfort of the tractor cab.
The A-Series central pivot encloses a Gear Driven turn-table and an integrated Rotary Coupling. This powers the extremely reliable Hydraulic "Cut & Start."
The centre Shaft is Compact and extremely durable. By being low to the ground, Tanco have eliminated the need for an Off-Load Ramp
Specifications - A100EH
Height: 2410mm
Width: 2760mm
Length: 4100mm
Weight: 1460kgs
Wrapping Table Speed (Recommended): 28 R.P.M.
Wrapping Table Speed (max): 30 R.P.M.
Maximum Bale Diameter: 1500 mm
Maximum Bale Weight: 1200kg
Pre-Stretcher(s): 1 x 750mm Width; 55 & 70% Stretch
Hydraulic Connection: 2 x 1/2" m.c.
Oil Pressure: 150 bar
Oil Amount: 25lts/min
Maximum Counter Pressure: 10 bar
Electrical Connection: 12 V DC
Operational Video: https://youtu.be/t_-cToMsBQE
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

TANCO A100 EH, ROUND BALE WRAPPER , SELF LOAD, MAX BALE 1.5 METRE

Product of Canada, The TL1000R is a valuable addition to any hay producers arsenal. Easy to maintain and even easier to use, the TL1000R uses tractor hydraulics to spin and rotate the bale ensuring its completely wrapped every time.
To keep 4ft and 5ft bales centred the TL1000R is equipped with adjustable bale guides. It also features a wrap counter to ensure you get the right amount of wraps on each bale.
Add some value to your operation with a new Individual Bale Wrapper from Tubeline.
TL1000R Specifications:
Bale Size: 4ft x 4ft to 5ft x 5ft 6in
Film Width: 30in
Length: 104in
Width: 80in
Height: 84in
Weight: 1,600 lbs.
HP Required: 30 HP
Three Point Hitch: Category II
Drive Type: Hydraulic
Bale Guides: Adjustable (4ft or 5ft)
Operational Video: https://youtu.be/B78qiiijnU0
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

TUBELINE ROUND BALE WRAPPER

The 1814S is an extremely compact and efficient square and round bale wrapper. It is ideal for contractors who wish to wrap at the point of stacking. The wrapper is fully automatic and can be operated via radio remote control from the tractor cab. While wrapping, the operator can stack wrapped silage bales and prepare loading the next bale. This agricultural wrapping machine is also very versatile. The bale wrapper has hydraulically adjustable rollers which can be quickly changed to fit bale sizes of 0.6m to 1.4m in height to a maximum of 1.9m in length.
The height levels are also independently hydraulically adjustable at the front and rear to ensure a sturdy position. The stand alone machine has a twin bale wrap sequence.
Machine Levelling: The level of the machine can be hydraulically adjusted at the front and rear to ensure bales are level while wrapping.
Radio Remote Control: The wrapper is fully automatic and can be operated via radio remote control from the tractor cab, allowing a single operator to load, wrap and stack bales.
Offload Conveyor: An optional off-load conveyor is available, allowing for more manageable bale handling. Bales can be placed on their flat end with the optional End-Tip kit, where plastic concentration is greatest, reducing the risk of damage to the bale and also ensuring bales do not roll once off-loaded.
Wrap Arm Unfold & Fold: Tancos patented system for unfolding and folding multiple wrap arms into a single cut and hold system has made it possible for 3 point linkage wrappers, which are lighter and more compact than their trailed counterparts, to reach the highest levels of performance and bale count.
Telescopic Cut & Start: A patented system, the telescopic Cut & Start extends to three times its resting state extending and then retracting to gather the film into a single strand. Once gathered and held, only then is the film cut, resulting in an ultra-reliable system you can have confidence in.
Variable Speed Hydraulics: The use of proportional hydraulics means hydraulic functions, such as wrap arm speed, can be variably adjusted to ramp up and down ensuring a smoother and more consistent wrapping operation, resulting in less vibration and longer machine life.
RDS Expert Controller: The Expert Plus controller has a larger screen for faster data input and read-out.
Features:
Film Break Sensors.
Tanco Dual Stretch Aluminium Dispenser with 55% & 70% stretch options built-in.
Individually driven pick-up rollers.
Telescopic Cut & Start.
RDS Expert Plus Controller.
Specifications:
Transport Length: 3.42m
Transport Width: 2.44m
Height In Transport: 3.40m
Weight: 2,550kg
Wheel Dimensions: 480 / 45-17
Wrapping Arm Speed (Recommended): 25 rev. per minute
Wrapping Arm Speed (max): 30 rev. per minute
Wheel Size: 19/45-17
Maximum Bale Size: 1.20mx1.20mx1.90m
Maximum Bale Weight: 1,500 kg
Capacity: Approx. 50 bales per hour
Pre-Stretcher(s): 750 mm
Oil Pressure: 175 bar / 50 litres/minute
Electrical Connection: 12 V DC
Options:
End-Tip Kit - Places bales on their end where plastic coverage is greatest and avoids bales rolling.
Ground Roller - Takes the weight of the bale and machine in cases of lighter tractors.
Radio Remote Control - 6 and 4.5 meter extension cables for use with telehandlers.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.

TANCO STATIC SQUARE AND ROUND BALE WRAPPER
